TRENDnet TE100-H24R Bedienungsanleitung

TE100-H16R/H24R

16/24 Ports

Fast Ethernet

Stackable Hubs

User’s Guide

Fast Ethernet Stackable Hubs User’s Guide

16/24 Ports

Fast Ethernet

Stackable Hubs

User’s Guide

Rev. 01 (AUG., 1998)

505-1100-004

Printed In Taiwan

RECYCLABLE

Fast Ethernet Stackable Hubs User’s Guide

iii

FCC Warning

This equipment has been tested and found to comply with the lim-

its for a Class A digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable protection

against harmful interference when the equipment is operated in a

commercial environment. This equipment generates, uses, and

can radiate radio frequency energy and, if not installed and used

in accordance with this user’s guide, may cause harmful interfer-

ence to radio communications. Operation of this equipment in a

residential area is likely to cause harmful interference in which

case the user will be required to correct the interference at his own

expense.

CE Mark Warning

This is a Class A product. In a domestic environment, this product

may cause radio interference in which case the user may be re-

quired to take adequate measures.

Fast Ethernet Stackable Hubs User’s Guide

TABLE OF CONTENTS

0ABOUT THIS GUIDE ...........................................................1

Conventions .....................................................................................1

Overview of the User’s Guide..........................................................2

1INTRODUCTION ..................................................................3

Product Description ........................................................................3

Product Features .............................................................................4

2UNPACKING AND SETUP.....................................................5

Unpacking .......................................................................................5

Identifying External Components ..................................................6

Front Panel ......................................................................................6

Rear Panel .......................................................................................7

Installing the Hub...........................................................................9

Installation ......................................................................................9

Rack Mounting ..............................................................................10

3UNDERSTANDING INDICATORS ..........................................11

Hub State Indicators ....................................................................12

100BASE-FX Module Indicators .................................................12

Port State Indicators.....................................................................13

Fast Ethernet Stackable Hubs User’s Guide

4MAKING CONNECTIONS ...................................................15

Hub Cascading/Building a Stack ...............................................15

Connectivity Rules ........................................................................16

Hub to End-Station Connection ...................................................17

Hub-to-Hub Uplink.......................................................................19

100Base-FX Module Installation .................................................20

5CABLES AND CONNECTORS .............................................23

100BASE-TX Ethernet Cable and Connectors ............................23

Crossover Cables ...........................................................................25

6SPECIFICATIONS..............................................................27

General ..........................................................................................27

Hub-to-Hub Cascading.................................................................28

LED Indicators..............................................................................28

Environmental and Physical........................................................28

Fast Ethernet Stackable Hubs User’s Guide

About This Guide

0 ABOUT THIS GUIDE

This guide discusses how to install and use the 16/24 port stack-

able Fast Ethernet Hubs

Conventions

References in this manual to the 16/24 port stackable Fast

Ethernet Hubs are frequently written simply as “hub” or “hubs”

where the text applies to all models. Model names are normally

used only to differentiate between models where necessary.

Unless differentiated by model name, all information applies to all

models.

Fast Ethernet Stackable Hubs User’s Guide

About This Guide

Overview of the User’s Guide

♦ Chapter 1, Introduction. Provides information on

Fast Ethernet networks, and introduces the features

of the 16/24 port stackable Fast Ethernet Hubs.

♦ Chapter 2, Unpacking and Setup. Helps you get

started in setting up the hub.

♦ Chapter 3,Understanding Indicators. Describes all

LED indicators on the hub’s front panel. Understand-

ing these indicators is essential to effectively using

the hub.

♦ Chapter 4, Making Connections. Provides informa-

tion on connecting to the hub’s twisted-pair, stacking

hubs, and linking with other 100BASE-TX hubs.

♦ Appendix A, Cables and Connectors. Provides specifi-

cations on the cables and connectors used with the

hubs.

♦ Appendix B, Specifications. Lists the hub’s specifica-

tions.

Fast Ethernet Stackable Hubs User’s Guide

Introduction

1 INTRODUCTION

This chapter introduces the 16/24 port stackable Fast Ethernet

Hubs, as well as giving some background information about the

technology of the hubs use.

Product Description

Ideal for establishing or enlarging a Fast Ethernet LAN work-

group, the Stackable Fast Ethernet Hub provides port density

options from 16 to 190. The hub is IEEE 802.3u compliant and

falls into the Class II Fast Ethernet hub type. The ports on the

hub are standard RJ-45 connectors for use with Category 5 UTP or

STP cabling.

The hubs in the series, available in 16-port and 24-port models,

can be stacked with up to four hubs in a stack. A stack of four 24-

port hubs gives a total of 96 Fast Ethernet ports. A 16/24 port

stackable Fast Ethernet Hubs stack operates as a Class II Fast

Ethernet repeater, allowing it to be linked to another Class II Fast

Ethernet stack in the same collision domain.

Fast Ethernet Stackable Hubs User’s Guide

Introduction

Product Features

The list below highlights the features and specifications of hubs in

the series.

♦ Compatible with the 802.3u 100BASE-TX, 100BASE-FX

Fast Ethernet Class II repeater standards for inter-

operability with other Fast Ethernet network devices.

♦ Uses Category 5 UTP or STP cabling.

♦ Up to 100 Meters of cable length between any com-

puter and the hub with a maximum of 205 meters of

cable between any two network nodes.

♦ 16 or 24 100Mbps Fast Ethernet ports.

♦ LED indicators for Power, FX Link/Rx, 100M Activity,

100M Collision and 100M Link/Rx.

♦ Scalable stack containing up to 4 units for a total 64

or 96 (depending on model) 100Mbps UTP/STP ports.

♦ Uplink port allows easy linking of two Fast Ethernet

hub stacks to further expand your network.

♦ Standard-size (19”, 1U height), rack mountable

♦ Optional slide-in module: 100BASE-FX (see Chapter

4 : Making Connections).

♦ Automatic voltage selection (100V to 240V, 50~60Hz)
