TRENDnet TE100-SK1 Bedienungsanleitung

The TE100-SK1 is designed as a total solution for connecting

two personal computers to enable them to share files,

printers, fax servers, and/or email. TRENDnet’s TE100-SK1

features a 5-Port 100Base-TX hub and two 10/100Mbps Fast

Ethernet cards. TRENDnet’s network starter kits are specially

designed for home and small office use and can support up to

5 network nodes without expansion. There is enough room on

the hub to add a server, network printer, and a third personal

computer.

TE100-SK1

5-Port 100Base-TX Hub Starter Kit

5-port 100Base-TX

Uplink port for cascading to another 100Base-TX Class II

hub

Port Jabber and auto-partition protection, data collision

detection and handling

Sturdy all metal housing

Preamble regeneration retiming incoming frames

Status LED indicator for hub diagnostics and network

utilization

5 Year Warranty

10/100 Mbps auto-sensing

Supporting 32-bit PCI bus mastering

Plug and Play

Supports multi-tread penetration

Compatible with all major Network Operating Systems

5 Year Warranty

BENEFITSFEATURES

Upgrabable:

Expandable:

Flexible:

Cost Effective:

Reliable:

Add nodes as needed.

Add a server, internet station, network

printer or a third PC without changing

the hub.

Hub is smaller enough to be put

anywhere it is needed.

Buy only the part you need.

5 year or lifetime warranty.

5-port 100Base-T Hub (TE100-H5E)

10/100Mbps Fast Ethernet Adapter for PCI (TE100-PCIW)

TE100-SK1 (11-17-2002)

TRENDnet

TRENDware, USA

What's Next in Networking

PRODUCT INFORMATION

To Order Please Call:

1-888-326-6061

NETWORKING SOLUTIONS

SPECIFICATIONS

TE100-SK1

5-Port 100Base-TX Hub Starter Kit

TE100-SK1

5-Port 100Base-TX Hub Starter Kit

DC Input:

12V, 800mA

Standards:

IEEE 802.3µ 100Base-TX standard

Power Consumption:

10W max

Cabling:

EIA Category 5 STP/UTP

Uplink Port:

Shared port #1 (Slide Switch)

Weight:

600 grams (excluding power adapter)

Dimensions:

160 mm x 120 mm x 30 mm (LxWxH)

Opearting Temperature:

0° - 50° C

Certification:

FCC, UL, C-tick, CE

•

TE100-H5E TE100-PCIW

Standards:

IEEE 802.3 10Base-T, IEEE 802.3µ 100Base-TX

Data Transfer Rate:

10 or 100Mbps /20 or 200Mbps (Full Duplex)

Topology:

Star

Diagnostic LED’s:

ACT, LINK, 100, FDX

•

TE-SK1: 5-Port 10Base-T Hub Ethernet Starter Kit

(2 x TE-PCIWT, 1 x TE-500, 2 x 15' CAT 5 cables)

TE100-SK1: 5-Port 100Base-T Hub Fast Ethernet Starter Kit

(2 x TE100-PCIW, 1 x TE100-H5E, 2 x 15' CAT 5 cables)

TE100-SK2: 4-Port 10/100Mbps Dual Speed Starter Kit

(1 x TE100-PCIWplus, 1x TE100-DX4PCI, 1 x 15' CAT 5 cables)

TE100-SK3: 5-Port 10/100Mbps Switch Fast Ethernet

Network Kit

(2 x TE100-PCIWN, 1x TE100-S55E, 2 x 20' CAT 5 cables)

TE100-SK3plus: 5-Port 10/100Mbps Switch Fast Ethernet

Network Kit

(2 x TE100-PCIWN, 1x TE100-S55Eplus, 2 x 20' CAT 5 cables)

TE100-SK4: 10/100Mbps Switched Fast Ethernet Network Kit

(2 x TE100-PCIWN, 1 x TE100-S5P, 2 x 15" CAT 5 cable)

TRENDnet is a registered treademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this

document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit

____________________

http://www.TRENDNET.com.

TRENDware International, Inc.

3135 Kashiwa Street

Torrance, CA. 90505. USA

Tel: 310-891-1100

Fax: 310-891-1111

Web:

Email: [email protected]

www.TRENDNET.com

ORDERING INFORMATION

TRENDnet
