TRENDnet TEG-S4000i Bedienungsanleitung

TEG-S4000i

4-Slot SNMP Modular Switch

Ethernet / Fast Ethernet / Gigabit Ethernet

User’s Guide

Version 2.0 23-April-2003

Release Note

4 slot modular switch manual

Update Version Progress status Remark QA PM

23/04/2003 V2.0 On checking 1. 10/100 TX (48350) spec. MAC: 4K

Buffer:256Kbytes

2. 2/4/8 100FX (48310 ) spec.

MAC12k, Buffer:5Mbytes

3. Gigabit module (48360) MAC:4K,

Buffer 128 Kbytes

Richard

Table of Content

Introduction

Product Overview

Network Configuration

Connecting to the Network

Web-Based Management

SNMP Management

Product Specifications

Appendix A.

Internet Explorer Setting

Appendix B.

VLAN Setting

Introduction

Welcome to the World of Switching-Network. In modern business

society, communication and information sharing are fundamental to

our lifestyle. Computer networks are one of the fastest means of

communication.

Congratulations on purchasing the Modular Switch. This Modular

Switch is a combination of 4-slot host cabinet and optional 4 kinds of

media modules. A maximum 32 x 10/100Base-TX switched ports

can be achieved using 4 x 8 port 10/100 Base-TX switch modules.

Modular Switch features store-and-forward switching scheme. Every

module has it’s own entry MAC address table to store source

address. The backplane of the Modular Switch can reach up to 10.4

Gbps as to improving network performance.

Figure 1-1 The Modular Switch

Modular Switch with layer 2 management functions, 4 expansion

slots can flexible configure your network. The 4 optional modules

can be 8-Port 10/100 Auto-sensing Intelligent Switch Module,

2/4/8-Port 100 Base-FX Intelligent Fiber Module, Gigabit

1000Base-T Intelligent Switch Modules, and Gigabit

1000Base-SX/LX Intelligent Fiber Modules.

With its build-in Web-based Management, managing and configuring

the Modular Switch becomes easier. From cabinet management to

port-level control and monitoring, you can visually configure and

manage your network via Web Browser. Just click your mouse

instead of typing cryptic command strings. However, the Modular

Switch can also be managed via Telnet, Console, or third-party

SNMP Management.

KeyFeatures

 Conforms to IEEE 802.3, 802.3u, 802.3z, 802.3ab and

802.3x standards

 4 expansion slots to configure flexible network

 One built-in intelligent module with RS-232 console

port ( front side )

 Supports Half-duplex mode for backpressure, and

full-duplex for flow-control

 Store-and-Forward switching architecture for abnormal

packet filtering

 Up to 9.6Gbps Back-plane forwarding rate

 Mac address: 4K for 8 port 10/100 TX and Gigabit

module, 12K for 2/4/8 port fiber module.

 Packet Buffer: 128Kbyts for 8 ports 10/100TX module, 4

Mbytes for 100FX Fiber module, 128KBytes for Gigabit

module

 LED System Power, Diagnostic

8 ports TX module: 10/100Mbps,Link/Active,

Full-duplex/Collision;

2/4/8 ports Fiber module: Link/Active,

Full-duplex/Collision

Gigabit Module: Link, Active, Full duplex, Collision

 Optional different modules including

Gigabit module ( SX/LX ), Gigabit 1000Base-T, 8-port

auto-sensing 10/100Base-TX switch module, 2/4-port

100BaseFX ( ST/SC/MT-RJ/VF-45 ) fiber module, 8-port

100BaseFX ( MT-RJ/VF-45 ) fiber module

Intelligent Module Features

 Web-Based Management

 SNMP Management

 Console and Telnet Management

 IEEE 802.1Q Tagging VLAN ( Up to 4095 VLANs )

 IEEE 802.1d Spanning Tree Protocol ( STP )

 Statistic Address Table for manual address-addition

 Port Trunking supported

 IGMP supported

 Broadcast Storm Filter

 Port Mirror

 Web Browser Security

 Firmware upgradeable trough TFTP

 MIB II and Private MIB supported

 IEEE 802.1p QoS, ToS

 Port Security

Management Methods

The Modular Switch supports following management methods :

 Console and Telnet Management

 Web-based Management

 SNMP Network Management

Console and Telnet Management

Console Management is done through the RS-232 Console Port.

Managing the Modular Switch in this method requires a direct

connection between PC and the Switch. While Telnet management

is done over the network. Once the Switch is on the network, you

can use Telnet to Log in and change the configuration.

Web-based Management

The Modular Switch provides an embedded HTML web site residing

in flash memory. It offers advanced management features and allow

users to manage the Modular Switch from anywhere on the network

through a standard browser such as Microsoft Internet Explorer. For

more information, See Section 5 Web-Based Management.

SNMP Network Management

SNMP ( Simple Network Management Protocol ) provides a means

to monitor and control network device, and to manage configurations,

statistic collection, performance, and security.

Data is passed from SNMP agents, which are hardware & software

processes reporting activity in each network device to the

workstation console used to oversee the network. The agent return

information contained in a MIB ( Management Information Base ),

which is a data structure that defines what is obtainable from the

device and what can be controlled.

Package Contents

Unpack the carton of the Modular Switch and verify them against the

checklist below.

 Modular Switch

 Power Cordially

 Four Rubber Feet

 RS-232 cable

 User Guide

Modular Switch Rubber Feet

Rack-mounted Kit RS-232 cable User Guide

Power Cord Figure 1-2. Package Contents

Compare the contents of your Modular Switch package with the

standard checklist above. If any item is missing or damaged, please

contact your local dealer for service.

Product Overview

This section contains the following topics:

 Physical Description

 Optional Modules

 Installing Optional Modules

 Software Concepts

Physical Description

The physical dimensions of the HomePNA 312M are:

440mmx 227mm x 67mm ( Lx Wx H )

The Modular Switch is a modular unit, and its chassis contains four

slots. All optional models come with the built-in CPU modules. The

LEDs are located on the front panel of the Switch to allow you to

monitor the operation and performance at a glance. All ports can be

used for network configuration. The RS-232 port is used for

Out-of-Band Management.

Front & Rear Panel

The front panel of Modular Switch displayed in Figure 1-1 is shown

with 8-port 10/100Base-TX Module, 4-port 100Base-FX Fiber

Module and Gigabit 1000Base-T and Gigabit SX Fiber Module.

Figure 2-1. Front Panel

The 3-pronged power plug and On/off switched are located at the

Rear Panel of the Modular Switch displayed in Figure 2-2. The

Switch will work with AC in the range 100-240VAC, 50-60Hz.

igure 2-2.

ear Pane

LED Indicators

All LED status indicators are located on the FRONT panel of the

switch. They provide a real-time indication of system and operational

status. The ports for connections to other devices and networks are

also on the front panels.

LED Status Meaning

Power Green Power on

Diag Red Alert and problem notice

Green Device has been connected to the port

Blinks The data is transmitting on the port

LK/ACT

Off No device attached

Yellow Port in full duplex mode

Blinks A collision occurs on the port

FD/COL

Off No device attached or in half duplex mode

Green The Port is in 100Mbps mode

100

( Only for 8

port 10/100M

Switch Module )

Off Not connected or in 10 Mbps mode

Table 2-1. The above table provides descriptions of the LED status and

their meaning.
