TRENDnet TK-1603R Bedienungsanleitung

TK-803R

TK-1603R

Quick Installation Guide

Table of Contents

Version 10.27.2006

English .....................................................................................................

Specifications ............................................................................................

Troubleshooting .........................................................................................

1. Before You Start

2. How to Install .....................................................................................

3. Operation ...........................................................................................

................................................................................

System Requirements

Application

TK-803R/TK-1603R

Quick Installation Guide

Rack mount kit

AC Power Adapter (9V DC, 1A)

PS/2 or USB Keyboard

PS/2 or USB Mouse

VGA Compatible Monitor

KVM cables

Windows 98SE/ME/2000/2003 Server, Linux, and Mac

Package Contents

1. Before You Start

English

8/16 Ports Rack Mount

USB KVM Switch

(TK-803R/TK-1603R)

PC 2PC 4PC 6PC 8

Monitor

USB or PS/2

Mouse

USB or PS/2

Keyboard

PC 1PC 3PC 5PC 7

2. How to Install

English

1. Turn OFF all computers and their

peripherals, and then disconnect all

power cords.

4. Connect the included AC Power

Adapter to the KVM switch and

then to a power outlet.

2. Use the KVM cables to connect

each computer to the KVM switch.

3. Connect the shared PS/2 or USB

keyboard, monitor, and PS/2 or

USB mouse to the KVM switch's

Console Port. (TK-1603R shown)

English

5. Turn ON the connected computers

one-by-one and wait until each

computer's desktop appears.

7. Carefully position the switch onto

the rack. Align the bracket to the

screw holes on the rack, then use

the screws provided with the

equipment rack to mount the

switch.

The KVM Switch can be mounted in an EIA standard-size, 19-inch rack, which

can be placed in a wiring closet with other equipment.

Note: If you would like to mount the KVM switch to a EIA 19” equipment rack,

install the included mounting brackets to the sides of the KVM switch, secure

them with the screws provided, and then mount the KVM switch to the

equipment rack with the hardware provided by the equipment rack

manufacturer.

Rack Mount

6. Attach the mounting brackets to

both sides of the switch and secure

them with the provided screws.

Your installation is now complete.

English

3. Operation

Note: To switch between computers, you can use the front-panel push buttons

or the Hot Key commands.

LED Indicators

Red LED light: KVM cable is

connected and PC is powering the

KVM switch.

Green LED light: Indicates the

selected PC port is active, whether

the computer is turned on or off.

Push Buttons

Press the push buttons to switch

between computers.

Hot-Key Commands

A keyboard hot-key command consists of three keystrokes:

Hot-Key command = ScrLk + ScrLk + Command key(s)

After pressing the ScrLk key, you have 2 seconds to press the ScrLk key again.

You then have another 2 seconds to press a command key. If you do not press

a key within 2 seconds, the switch will exit hot-key mode.

To select a specific PC port:

For TK-803R

Select PC =

For example, to Select Port 1 on the TK-803R you hit the following key

sequence:

Select PC =

For TK-1603R

Select PC =

MAC USERS

Standard PC Keyboard to MAC Keyboard mapping information:

For example, to select Port 1 on the TK-1603R you hit the following key

sequence:

Select PC =

To select port 10 on the TK-1603, hit the following key sequence:

Select PC =

ScrLk ScrLk 1

+ +

ScrLk ScrLk Y

+ +

ScrLk ScrLk 10

+ + +

ScrLk ScrLk YZ

+ + +

ScrLk ScrLk 01

+ + +

English

ScrLk ScrLk C

+ + = CD/DVD drive

eject key

ScrLk ScrLk F10

+ + =

ScrLk ScrLk F11

+ + =

ScrLk ScrLk F12

+ + =

F13

F15

F14

For a list of all the Hot-Key commands, please see the Quick Reference Sheet.

Command Hot-Keys Description

Front-Panel

Buttons

Quick Reference Sheet for TK-803R/TK-1603R

Select PC

Next lower channel

Autoscan

Next higher channel

Autoscan with

Programmable

Delay Time

Autoscan Beep

Sound On/Off

Mouse/Keyboard

Reset KVM

Restore to Factory

Defaults

Define Hotkey

Sequence

(default = ScrLK +

ScrLK)

Stop Autoscan

ScrLk ScrLk

+ +

(Arrow up)

ScrLk ScrLk

+ +

(Arrow down)

ScrLk ScrLk

+ + B

ScrLk ScrLk

+ + END

ScrLk ScrLk

+ + R

ScrLk ScrLk

+ + S

Press any key on keyboard

Select the active PC channel

Press the Push Button

for a specific port to

switch to that port

Select the next lower PC

channel

Autoscan through every

connected channel for quick

screen browsing of each

channel

Select the next higher PC

channel

Autoscan through every

connected channel for quick

screen browsing of each

channel in intervals of X

seconds

Toggle On/Off beep sound

during Autoscan mode.

Resets Mouse/Keyboard

Restore to Factory Defaults

Select the hotkey preceding

sequence among 5 options

Terminate Autoscan activityPress any button

- - -

ScrLk ScrLk Y

+ +

(YZ)= 2-digit channel number

TK-803R

TK-1603R

ScrLk ScrLk YZ

+ + +

Y = Scroll Lock, Caps Lock, Esc, F12 or

Num Lock

ScrLk ScrLk HY

+ + +

(X) = 0~9

1 = 10 seconds

2 = 20 seconds

3 = 30 seconds

4 = 40 seconds

5 = 50 seconds

6 = 60 seconds

7 = 70 seconds

8 = 80 seconds

9 = 90 seconds

0 = 100 seconds

ScrLk ScrLk SX

+ + +

English

Note: If you have defined a different hotkey preceding sequence key (e.g. Caps

Lock, Esc, F12), press that button instead of scroll lock. For example, if you

want to turn off beep and have defined the hotkey preceding sequence key as

F12, press F12 + F12 + B.

Port Selection: Push Button and Hot-Key Commands

Keyboard State:

Power:

Saved and restored

LED Segment: Per Port : PC Link (Green) ; PC Active (Red)

Management: TK-803R: 8 computers

TK-1603R: 16 computers

Console Port Connectors:

1 x USB keyboard Type A

1 x USB mouse Type A

1 x PS/2 keyboard 6-pin mini din female

1 x PS/2 mouse 6-pin mini din female

1 x VGA HDB 15-pin female

PC Port Connectors:

(all female)

TK-803R: 8 x VGA HDB 15-pin

TK-1603R: 16 x VGA HDB 15-pin

VGA Resolution: 2048 x 1536

Specifications

Weight: TK-803R : 1.84 kg (4.05 lbs)

TK-1603R : 2.04 kg (4.5 lbs)

0ºC ~ 40ºC (32ºF ~104ºF)Operating Temperature:

-20ºC ~ 60ºC (-4ºF ~ 140ºF)Storage Temperature:

0%~90%, Non-Condensing

Humidity:

FCC and CECertifications:

Auto-Scan Intervals: 10 ~ 100 seconds

PS/2 Interface Power

USB Interface Power

External AC Power Adapter : 9V DC, 1A

Size (19" Rack mount):

Dimensions:

1RU

405 x 163 x 44 mm (15.94 x 6.42 x 1.74 in.)

Troubleshooting

Q1:

A1:

Q2:

A2:

Q3:

A3:

Q4:

A4:

Q5:

A5:

Q6:

A6:

Do I need to use the included external AC adapter?

It is recommended that you use the included external AC adapter with the

TK-803R/TK-1603R KVM switch.

I have the KVM switch connected properly, but my USB keyboard and mouse

don't work.

First, make sure your USB port is working properly by testing it with your other

USB devices. Second, once you confirm that the USB port is functional, please

reboot your computers, and try to use the KVM switch again. Third, if your

computer is running Windows 98SE, you may need to download and install the

USB hot fix. Please go to this link for download and installation instructions:

http://support.microsoft.com/kb/q240075. Once the hot fix is installed, follow the

installation instructions in Section 2.

Can I connect or disconnect the KVM cables while the computers are turned

on?

Yes, you can connect or disconnect the KVM cables while the computers are

turned on, because the interface is Hot-Pluggable.

Yes, the KVM switch will restore the keyboard settings when switching

between computers. (i.e.: Caps Lock, Num Lock, etc.)

Go to Section 3 Operation for more information.

If you still encounter problems or have any questions regarding the TK-803R/

TK-1603R please contact TRENDnet's Technical Support Department.

Will the KVM switch restore the keyboard settings when switching between

computers?

How do I switch from one computer to another with the KVM switch?

You can switch PCs by pressing the push button on the KVM switch or by

using the Hot-Key commands.

How to upgrade new firmware to my KVM switch?

Please go to the TRENDnet website (www.trendnet.com) to check if there is a

new firmware available for your KVM switch and follow the installation procedure

to perform the update.
