TRENDnet TK-204UK - DVI USB KVM Switch Bedienungsanleitung

kvm

The 2-Port DVI USB KVM Switch with Audio Kit (TK-204UK) allows you

to control 2 computers with one set of console controls featuring high

definition Digital Video Image (DVI) technology. Manage 2 computers

that have DVI and USB ports at the touch of a button with one set of

USB keyboard, USB mouse, DVI monitor, microphone and speakers.

Enjoy DVI quality images from both of your computers. No need for

additional cabling, all required cables are included. Listen to music on

one computer while working on the other. With Hot-Plug, Auto-Scan and

Hot-Key operating features, this versatile device is the perfect choice for

managing 2 computers.

TK-204UK(1.0R)

Port DVI USB KVM Switch with Audio Kit

TK-204UK

rev:04.17.2008

• 2-port compact desktop DVI USB KVM switch with audio and mic

• USB console support for USB keyboard, mouse and high-speed USB devices

• Audio and microphone switching for uninterrupted multimedia experience across multi-platforms

• USB 2.0/1.1 specification compliant USB interface power

• Independent simultaneous switching of both PC and audio and mic channel

• Multi-platform support for PCs and Macintosh G3/G4, iMAC

• Hot-plugging PCs for maintenance without powering down the KVM switch or PCs

• Switching software client for easy software switching on Windows and Mac platform

• User definable hotkeys additional universal port switching hotkey – ScrollLock + ScrollLock – for non-Windows OS on PC platform.

• Channel selection by push button, keyboard hotkeys and switching software client (for Windows/Mac)

• USB interface power LED indicators for easy status monitoring

• Digital video resolution 1920 x 1200

• 2-Year Warranty

FEATURES

PC Selection

PC Port Connector

Console Port Connector

Cable

Keyboard/Mouse Emulation

VGA Resolution

Power

LED

Dimensions

• DVI-I & DVI-D Compliant

• 2 x USB type B

• Push button, hotkeys, switching software (for Windows/Mac)

• 2 x (green – PC1 / blue – Pc2)

• 154 × 65.5 × 27 mm

• 2 x DVI-I (integrated with audio&mic)

• 2 x USB Type A (keyboard & mouse & USB 2.0/1.1 Devices)

• 1 x 3.5mm mic jack

• PS/2

• 5V DC, 2A external power adapter

• 1920 x 1200 (digital)

• 1x DVI 15-pin female

• 1 x 3.5mm audio jack

• 2 x detachable DVI/audio and mic combo cable 2 x USB cable

Interface

Hardware

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

RELATED PRODUCTS

PACKAGE CONTENTS

TK-204K 4-Port Rack Mount DVI KVM Switch w/ Audio

• Multi-Language User’s Guide

• TK-204UK

• 2 sets of DVI-I Dual Link Cables

ORDERING INFORMATION

To Order Please Call:

1-888-326-6061

NETWORKING SOLUTIONS

SPECIFICATIONS

• Power Adapter (9V DC, 1A)

Weight

Humidity

Certifications

• 520g (18.4 oz.)

• 0 ~ 90%RH, Non-Condensing

• FCC, CE

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web:

Email: [email protected]

www.trendnet.com

TK-204UK(1.0R)

Port DVI USB KVM Switch with Audio Kit

Temperature • Operating: 0 ~ 40C (32 ~104 F) • Storage: -20 ~ 60C (-4 ~ 140 F)

PC 1 PC 2

2-Port DVI USB KVM Switch

with Audio Kit

(TK-204UK)

Monitor

USB

Keyboard

USB

Mouse

Microphone

Speakers

KVM USB DVI

TK-423K

TK-409K 4-Port USB KVM Switch Kit w/Audio

4-Port USB/PS/2 KVM Switch Kit w/ Audio
