TRENDnet TEW-636APB Bedienungsanleitung

The Wireless N Hot Spot Access Point creates a high speed wireless n

network with up to 12x the speed and 6x the coverage of wireless g.

Provide a seamless wireless experience in which multiple users can

access live media, download data intensive files, play games and talk

Online without wireless lag.

Advanced antenna technology (MIMO) delivers superior range and

eliminates dead spots. Wi-Fi Protected Setup (WPS) allows users to

securely synchronize wireless peripheral devices at the touch of a

button. A quick and intuitive installation process, remote management

capabilities and a 3-year warranty make this product well suited for your

most demanding networking needs.

TEW-636APB (V1.0R)

300Mbps Wireless N Hot Spot Access Point

TEW-636APB

rev:08.15.2008

• Wi-Fi Compliant with IEEE 802.11g and IEEE 802.11b Standards

• High-Speed up to 300Mbps Data Rate using IEEE 802.11n (draft) connection

• Built-in 3 Detachable External Antennas (MIMO Technology) to support high speed performance and great coverage

• Support for Wireless multimedia (WMM)

• Access Point Mode and Wireless Distribution System (WDS) feature

• Wireless Protected Setup (WPS) for effortless installation

• Supports 64/128-bit WEP(Hex) WPA/WPA2 and WPA-PSK/WPA2-PSK Encryption

• Advanced wireless protection (EAP-MD5, EAP-TLS, EAP-TTLS, PEAP)

• Support for 802.1x and RADIUS authentication

• Supports MAC Address Filter (up to 16 entries) and SSID Broadcast Control

• Access Control list for wireless client support

• Built-in DHCP Server and Client and Time Server support

• Flash Memory for Firmware Upgrade and Easy Management via Web Browser (HTTP)

• Configuration file backup and restore feature

• Compliant with Windows 2000/XP/2003 Server/Vista, Linux and Mac OS

• Coverage up to 150 meters (500ft.) Indoor (depends on the environment)

• Coverage up to 400 meters (1300ft.) Outdoor (depends on the environment)

• Easy to use Web based configuration

• 3-Year Warranty

FEATURES

wireless

Data Rate

Security

Output Power

Channels

• 802.11n: BPSK, QPSK, 16QAM, with OFDM

• 802.11b: 11Mbps, 5.5Mbps, 2Mbps, and 1Mbps

• 802.11n (Draft 2.0): Up to 300Mbps

• 802.11b: 18dBm (Typical)

• 1~ 11 (US), 1~13 (EU)

Certification

Humidity

Temperature

Hardware

SPECIFICATIONS

Standards

Reset Button

Config Button

Dimension (L x W x H)

Power Adapter

• 1 x 10/100Mbps Auto-MDIX LAN Port

• Wired: IEEE 802.3 (10Base-T), IEEE 802.3u (100Base-TX)

• Reserved For WPS Function Use

• 12V DC, 1A External Power Adapter

Interface

• 320g (0.7 lbs)

• Operation: 0°~ 40°C (32°F~ 104°F) • Storage: -20°~ 60°C (-4°F~140° F)

• 2.412 ~ 2.462 GHz (FCC)

• Max. 90% (Non-Condensing)

• CE, FCC

• 180 x 122 x 30 mm (6.8 x 4.6 x 1.1 inches)

• Reset To Factory Default Settings

• Wireless: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n (draft 2.0)

Weight

TEW-636APB

rev:08.15.2008

LED Indicator • WPS, Power, WLAN, Status

• Encryption: Hardware AES/TKIP, 64/128-bit WEP (Hex)

Receiving Sensitivity • 802.11b: -84dBm (Typical) @ 11mpbs

• 802.11g: -72dBm (Typical) @ 54Mbps

TEW-636APB (V1.0R)

Wireless N Hot Spot Access Point

Wireless

Frequency

Module Technique

• 2.412 ~ 2.472 GHz (ETSI)

• 802.11g: 54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 9Mbps and 6Mbps

• 802.1X/EAP: WPA/WPA2/802.1X authenticator

• WPA: WPA-PSK/WPA2-PSK, WPA-enterprise, WPA2-Enterprise

• SSID Broadcast Control

• 802.11g: 15dBm (Typical)

• 802.11n (Draft 2.0: 14dBm (Typical) with HT20 & HT40

• 802.11n (Draft 2.0) : -70dBm (Typical) with HT20 & HT40

• OFDM; 802.11b: CCK (11 Mbps, 5.5 Mbps), DQPSK (2Mbps), DBPSK (1 Mbps)

• CSMA/CA with ACK

Media Access Protocol

• 3 x 2dBi detachable dipole antennas

Antenna

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

RELATED PRODUCTS

TEW-621PC

TEW-623PI Wireless N PCI Adapter

Wireless N PC Card

• Power Adapter (12V DC, 1A)

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web:

Email: [email protected]

www.trendnet.com

TEW-624UB 300Mbps Wireless N USB 2.0 Adapter

Wireless N Hot Spot Access Point

10/100Mbps

300Mbps

300Mbps Wireless N

HotSpot Access Point

(TEW-636APB)

Workstation with 300Mbps

Wireless N PCI Adapter

(TEW-623PI)

Notebook with 300Mbps

Wireless N PC Card

(TEW-621PC)

4-Port Gigabit Firewall Router

(TWG-BRF114)

Workstation with 300Mbps

Wireless N USB Adapter

(TEW-624UB)

Cable/DSL

Modem

Internet

TEW-636APB (V1.0R)
