TRENDnet WAP-200A Bedienungsanleitung

11g High Power Wireless AP/Bridge

WAP-200A

User Manual

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the interference by one of the

following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that

to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause undesired operation.

FCC Caution: Any changes or modifications not expressly approved by the party responsible for

compliance could void the user's authority to operate this equipment.

IMPORTANT NOTE:

FCC Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled

environment. This equipment should be installed and operated with minimum distance 20cm

between the radiator & your body.

This transmitter must not be co-located or operating in conjunction with any other antenna or

transmitter.

U-MEDIA declares that WAP -200A ( FCC ID: SI5WAP200A ) is limited in CH1~CH11 for 2.4

GHz by specified firmware controlled in U.S.A.

This publication, including all photographs, illustrations and software, is protected under interna-

tained herein, may be reproduced without written consent of the author.

Trademark recognition

All product names used in this manual are the properties of their respective owners and are

acknowledged.

Table of Contents

Getting Started with the WAP-200A.................................3

Package Contents .............................................4

Minimum System Requirements ................................. 4

Wireless LAN Networking ..........................................5

Introduction.....................................................9

Features......................................................9

Hardware Overview ...............................................10

Rear Panel...................................................10

LEDs.........................................................11

Installation Considerations ..................................12

Getting Started ..............................................12

Using the Configuration Menu.....................................13

Information..................................................14

Stations.....................................................16

Wireless.....................................................17

WDS......................................................... 20

Security.....................................................21

Access.......................................................23

Admin........................................................25

Advanced.....................................................27

Glossary........................................................29

Getting Started with the WAP-200A

Congratulations on purchasing the WAP-200A! This manual provides information for setting up

and configuring the WAP-200A. This manual is intended for both home users and professionals.

The following conventions are used in this manual:

THE NOTE SYMBOL INDICATES ADDITIONAL INFORMATION ON THE

TOPIC AT HAND.

THE TIP SYMBOL INDICATES HELPFULL INFORMATION AND TIPS TO

IMPROVE YOUR NETWORK EXPERIENCE.

THE CAUTION SYMBOL ALERTS YOU TO SITUATIONS THAT MAY

DEGRADE YOUR NETWORKING EXPERIENCE OR COMPROMISE

LIKE NOTES AND TIPS, THE IMPORTANT SYMBOL INDICATES

INFORMATION THAT CAN IMPROVE NETWORKING. THIS INFORMATION

SHOULD NOT BE OVERLOOKED.

Package Contents

zWAP-200A Wireless AP/Bridge

zCAT-5 Ethernet Cable ( the WAP-200A’s Ethernet ports is Auto-MDIX)

zPower Adapter (5.0V, 2A)

zCD-ROM with Manual

zQuick Installation Guide

Using a power supply with a different voltage than the one included with your

product will cause damage and void the warranty for this product.

Minimum System Requirements

zComputers with Windows, Macintosh, or Linux-based operating systems with an installed

Ethernet adapter and CD-ROM.

zInternet Explorer Version 6.0 or Netscape Navigator Version 7.0 and Above

Wireless LAN Networking

This section provides background information on wireless LAN networking technology. Consult

the “Glossary” for definitions of the terminology used in this section.

THE INFORMATION IN THIS SECTION IS FOR YOUR REFERENCE. CHANGING

NETWORK SETTINGS AND PARTICULARLY SECURITY SETTTINGS SHOULD ONLY

BE DONE BY AN AUTHORIZED ADMINISTRATOR.

Transmission Rate (Transfer Rate)

The WAP-200A provides various transmission (data) rate options for you to select. Options

include Best (Auto), 1 Mbps, 2 Mbps, 5.5 Mbps, 11 Mbps, 6 Mbps, 9 Mbps, 12 Mbps, 18 Mbps, 22

Mbps, 24 Mbps, 36 Mbps, 48 Mbps and 54 Mbps. In most networking scenarios, the factory

default Best (Auto) setting proves the most efficient. This setting allows your WAP-200A to

operate at the maximum transmission (data) rate. When the communication quality drops below a

certain level, the WAP-200A automatically switches to a lower transmission (data) rate.

Transmission at lower data speeds is usually more reliable. However, when the communication

quality improves again, the WAP-200A gradually increases the transmission (data) rate again until it

reaches the highest available transmission rate.

Types of Wireless Networks

Wireless LAN networking works in either of the two modes: ad-hoc and infrastructure. In infra-

structure mode, wireless devices communicate to a wired LAN via access points. Each access

point and its wireless devices are known as a Basic Service Set (BSS).An Extended Service Set

(ESS) is two or more BSSs in the same subnet. In ad hoc mode (also known as peer-to-peer

mode), wireless devices communicate with each other directly and do not use an access point.

This is an Independent BSS (IBSS).

To connect to a wired network within a coverage area using access points, set the WAP-200A

operation mode to Infrastructure (BSS). To set up an independent wireless workgroup without an

access point, use Ad-hoc (IBSS) mode.

AD-HOC (IBSS) NETWORK

Ad-hoc mode does not require an access point or a wired network. Two or more wireless stations

communicate directly to each other. An ad-hoc network may sometimes be referred to as an

Independent Basic Service Set (IBSS).

To set up an ad-hoc network, configure all the stations in ad-hoc mode. Use the same SSID and

channel for each station.

When a number of wireless stations are connected using a single access point, you have a Basic

Service Set (BSS).

In the ESS diagram below, communication is done through the access points, which relay data

packets to other wireless stations or devices connected to the wired network. Wireless stations

can then access resources, such as a printer, on the wired network.

In an ESS environment, users are able to move from one access point to another without losing the

connection. In the diagram below, when the user moves from BSS (1) to BSS (2) the WAP-200A

automatically switches to the channel used in BSS (2).

Roaming in an ESS network diagram

Introduction

The WAP-200A Wireless AP/Bridge is an 802.11g high-gain, wireless AP that supports high-speed

wireless networking at home, at work or in public places.

The 802.11g standard is backwards compatible with 802.11b products. This means that you do not

need to change your entire network to maintain connectivity. You may sacrifice some of 802.11g’s

speed when you mix 802.11b and 802.11g devices, but you will not lose the ability to communicate

when you incorporate the 802.11g standard into your 802.11b network. You may choose to slowly

change your network by gradually replacing the 802.11b devices with 802.11g devices.

Hardware Overview

At Real Panel

DC-IN

The DC power input connector is a single jack socket to supply power to the WAP-200A.

Please use the Power Adapter provided on the WAP-200A package.

Auto MDI/MDIX LAN Ports

This port automatically senses the cable type when connecting to Router.

Reset Button

Pressing the reset button restores the AP to its original factory default settings.

LEDs

zPWR

ON: Power ON

OFF: Power OFF

zSYS
