TEW-432BRP
H/W: v.D1.0R
Quick Installation Guide
English ...............................................................................................................................................................................................................
Troubleshooting .................................................................................................................................................................................................
1. Before You Start
2. Install Router ..............................................................................................................................................................................................
3. Replacing an existing router ......................................................................................................................................................................
4. Adding the router behind an existing router ..............................................................................................................................................
.........................................................................................................................................................................................
Table of Contents
1
1
5
2
9
7
Version 02.13.2009
System Requirements
?TEW-432BRP
?Easy Go CD-ROM
?Quick Installation Guide
?RJ-45 Cat.5 Cable
?AC Power Adapter (7.5V, 1A)
Package Contents
?Web Browser: Internet Explorer (5.0 or above)
?Computer with Network adapter installed
?Broadband Internet
?Installed Cable or DSL modem
Important! DO NOT connect the router until instructed to do so. Follow the steps below before you insert the Easy-
Go CD-ROM into your computer's CD-ROM Drive.
Cable/DSL Modem
Internet
1. Verify that you have a direct
connection from your Cable or DSL
modem to your computer. Also verify
that you are connected to the Internet
by browsing to a website, such as
http://www.trendnet.com.
1
English
1. Before You Start
Note: If you do not check “No thanks, I already know how to
connect my computers and devices and set up printer and file
sharing”, a third party software program, Network Magic will
install. This program is not required to be installed in order to
get onto the Internet.
4. Choose the desired language
from the dropdown list. Click
No, thanks. I already know
how to connect my
computers and devices
and set up printer and file
sharing and then click Next.
Warning!!: DO NOT plug the cable or DSL modem power
supply into the TEW-432BRP.
2. Install Router
1. Connect the antenna to the
TEW-432BRP. 5. Click Next.
3. Click Start Installation.
2. Insert the Easy Go CD-ROM
in your computer's CD-ROM
Drive and then click Install
Router.
7. Turn off or unplug power to
your cable or DSL modem.
Then click Next.
8. Unplug the existing Ethernet
cable from your cable or DSL
modem and plug it into
yellow port number 1 on the
TEW-432BRP. Then click
Next.
6. If this screen appears, go to
3. Replacing an Existing
Router or 4.Adding the
Router Behind an Existing
Router. If not, please
continue to step 7.
2
English
3
Version 03.05.2008
12. Reconnect the power
supply to your cable or DSL
modem. Wait 30 seconds
then click Next.
14. Please wait while the
TRENDnet Router Setup
configures your router.
15. Enter a password for your
router. By default, the
password is admin. Click
Next.
16. Enter a unique network
name (SSID) for your
wireless network and then
click Next. The network
name (SSID) identifies your
wireless network.
9. Connect the included power
supply from an available
outlet to the TEW-432BRP.
10. Please wait while the
TEW- 432BRP is being
configured.
11. Connect one end of the
included grey Ethernet cable
to the grey port labeled
WAN on the back of your
new router. Connect the
other end of the cable to
your cable or DSL modem.
Then click Next.
13. If this window appears, your
Internet connection requires
a user name and password.
Enter your DSL Account
Name and Password. Then
click Next.
3
English
4
English
17. Select the desired level of
security, enter a security key
or keep the randomly
generated security key and
then click Next. It is
recommended that you use
Most secure (WPA). If your
wireless adapter does not
support WPA, please select
Secure (WEP) instead.
20. Please wait while the
TRENDnet Router Setup
configures your router.
18. Click Next.
19. Click OK.
Version 03.05.2008
21. Click Next.
23. Select Exit TRENDnet
Router Setup and then
click Finish.
24. Open up your browser and
type in a URL (e.g.
www.trendnet.com) to see if
you are online.
Your installation is now complete.
For detailed information regarding the TEW-432BRP
configuration and advanced settings, please refer to the User's
Guide included on the Easy Go Installation CD-ROM or
TRENDnet's website at www.trendnet.com
22. Click Next.
5
English
Version 03.05.2008
6. Connect the included power
supply from an available
outlet to the TEW-432BRP.
7. Please wait while the router
is being configured.
2. Turn off or unplug power to
your cable or DSL modem.
Then click Next.
3. Unplug the power cable from
your old router and remove
its power supply from the
outlet.
4. Disconnect the Ethernet
cable from the port labeled
“WAN” or “Internet” on the
back of your old router. Plug
this cable into the grey port
labeled “WAN” on the
TEW-432BRP. Then click
Next.
1. Select Yes, I am replacing
my existing router with a
new router and then click
Next.
5. Disconnect all remaining
Ethernet cables from the
back of your old router and
plug them into the yellow
ports on the TEW-432BRP.
Warning! DO NOT plug the cable or DSL modem power
supply into the TEW-432BRP.
3. Replacing an existing router
8. Reconnect the power supply
to your cable or DSL modem.
Wait 30 seconds then click
Next.
6
English
Version 03.05.2008
10. Select the type of Internet
Service, and then click
Next. Follow the wizard
instructions for configuring
the Internet. Please verify
your settings with your
Internet Service Provider.
11. Please wait while the
TRENDnet Router Setup
configures your router.
12. Enter a password for your
router. By default, the
password is admin. Click
Next
9. Please wait while the
TRENDnet Router Setup
configures your router.
14. Select the desired level of
security, enter a security key
or keep the randomly
generated security key and
then click Next. It is
recommended that you use
Most secure (WPA). If your
wireless adapter does not
support WPA, please select
Secure (WEP) instead.
15. Click Next.
16. Click OK.
13. Enter a unique network
name (SSID) for your
wireless network and then
click Next. The network
name (SSID) identifies your
wireless network.
7
English
Version 03.05.2008
18. Click Next.
21. Open up your browser and
type in a URL (e.g.
www.trendnet.com) to see
if you are online.
17. Please wait while the
TRENDnet Router Setup
configures your router.
2. Find the Ethernet cable that
goes from your computer to
your old router. Unplug this
cable from your old router
and connect it to yellow port
number 1 on your new
TRENDnet router. Then click
Next.
3. Connect the included power
supply from an available
outlet to the TEW-432BRP.
1. Select No, I want to connect
my new router to my
existing router and use
both of them and then click
Next.
19. Click Next.
20. Select Exit TRENDnet
Router Setup and then
click Finish.
4. Adding the router behind
an existing router
Warning! DO NOT plug the cable or DSL modem power
supply into the TEW-432BRP.
4. Connect one end of the
included grey Ethernet cable
to the grey port labeled WAN
on the back of your new
router. Connect the other end
of the cable to one of the
LAN ports on your old router.
Then click Next.
8
English
11. Click Finish.
10. Click Next.
5. Enter a password for your
router. By default, password
is admin. Click Next.
6. When the wireless network
then click Next.
screen appears, enter a
unique network name and
8. Click Next.
7. Select the desired level of
security, enter a security key
or keep the randomly
generated security key and
then click Next. It is
recommended that you use
Most secure (WPA). If your
wireless adapter does not
support WPA, please select
Secure (WEP) instead.
9. Click OK.
12. Open up your browser and
type in a URL (e.g.
www.trendnet.com) to see
if you are online.
Register Your Product
To ensure the highest level of customer service and support, please
take a moment to register your product Online at:
www.trendnet.com/register
Thank you for choosing TRENDnet
