The Wireless N Home Router delivers the highest level of security,

12x the speed and 4x the range of wireless g products. Install the

product in minutes with Easy-Go installation and seamlessly stream

live media, download files, play games and talk Online all at the

same time and with no wireless lag.

The latest in wireless encryption and a secure firewall provide the

ultimate in wired and wireless security. Advanced MIMO antenna

technology delivers superior range and eliminates dead spots. A

quick and intuitive installation process, remote man-agement

capabilities and a 3-year warranty make this product well suited for

your most demanding networking needs.

TEW-632BRP

Wireless N Home Router

TEW-632BRP

rev:09.13.2007

• Wi-Fi compliant with IEEE 802.11n (draft 2.0) and IEEE 802.11b/g standards

• 4 x 10/100Mbps Auto-MDIX LAN port and 1 x 10/100Mbps WAN port (Internet)

• Supports Cable/DSL modems with Dynamic IP, Static IP, PPPoE, PPTP, L2TP & BigPond connection types

• High-speed up to 300Mbps data rate using IEEE 802.11n connection

• 2 external antennas support high speed performance and great coverage with MIMO technology

• Firewall features Network Address Translation (NAT)

• Support Wi-Fi Protected Setup (WPS) for easy connection

• Universal Plug and Play (UPnP) and Application Level Gateway support for internet applications such as email, FTP, gaming,

remote desktop, Net Meeting, telnet and more

• Provides additional security of enable/disable wireless SSID, Internet Access Control (MAC Address, Domain & IP Filtering)

• Easy management via web browser and remote management

• Supports 64/128-bit WEP, WPA/WPA2 and WPA-PSK/WPA2-PSK

• Works with Windows 95/98/NT/2000/XP/2003 Server/Vista, Linux and Mac OS

• Coverage up to 100 meters (330ft.) indoor;(depends on the environment)

• Coverage up to 300 meters (980ft.) outdoor;(depends on the environment)

• 3- year warranty

FEATURES

** Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual data throughput and coverage will cary

depending on interference, network traffic, building materials and other conditions.

Wireless N Home Router

TEW-632BRP

Power Consumption

Internet Access Control

LED Indicator

Dimensions (LxWxH)

Weight

Temperature

• Max. 90% (Non-Condensing)

• 7W

• Operating: 0° ~ 40° C (32° ~ 104° F)

• Power, LAN1~LAN4, WAN, WLAN

• 5V DC, 2.5A external power adapter

• 195 x 120 x 30 mm (7.7 x 4.7 x 1.1 inches)

• 335g (11.8oz)

• CE, FCC

Humidity

Emissions

Hardware

SPECIFICATIONS

Power Adapter

• Storage: -20° ~ 60° C (-4° ~ 140° F)

Standards

LAN

Connection Type

• 1 x 10/100Mbps Auto-MDIX port (internet)

• Wired: IEEE 802.3 (10Base-T), IEEE 802.3u (100Base-TX)

• Dynamic IP, Static (Fixed) IP, PPPoE, PPTP, L2TP, BigPond

WAN

• 4 x 10/100Mbps Auto-MDIX ports

• Wireless: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n (draft 2.0)

TEW-632BRP

rev:09.13.2007

WPS Button • WPS configuration

DMZ

DNS

• UPnP IGD 1.0 Compliant

• DMZ host & Virtual Servers

• Static or WAN assigned DNS servers; 3 verified services for DDNS

UPnP

Logging • 5 types event logging

• Email report logging report

• MAC Address Filter, Domain/URL Filter, Protocol/IP Filter

Frequency

Media Access Protocol

Data Rate

Receiving Sensitivity

Output Power

Security

Channels

• 2 x 2dBi fixed dipole antenna

• 2412~2484MHz ISM band

• 802.11b: 17dBm (typical)

• 1~11 (US), 1~13 (EU)

• CSMA/CA with ACK

• 802.11b: -85dBm (typical) @ 11Mpbs

• 802.11b: 11Mbps, 5.5Mbps, 2Mbps, and 1Mbps

Wireless

Antenna

• 802.11n (draft 2.0) : up to 300Mbps

• WEP(HEX/ASCII): 64/128-bit

• 802.11n: -62dBm (typical) @ 300Mbps

• 802.11g: -68dBm (typical) @ 54Mbps

• 802.11n: 13dBm (typical)

• 802.11g: 13dBm (typical)

• Enable/Disable SSID

• 802.11g: 54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 9Mbps and 6Mbps

• WPA(AES/TKIP): WPA/WPA2, WPA-PSK/WPA2-PSK

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

RELATED PRODUCTS

TEW-630APB

TEW-621PC

TEW-623PI 300Mbps Wireless N-Draft PCI Adapter

300Mbps Wireless N-Draft Access Point

300Mbps Wireless N-Draft PC Card

• Power Adapter (5V DC, 2.5A)

• 1.5 meters (5 ft) Cat. 5 Ethernet cable

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web:

Email: [email protected]

www.trendnet.com

Wireless N Home Router

TEW-632BRP

TEW-624UB 300Mbps Wireless N USB 2.0 Adapter

DATA

Wireless N Home Router

(TEW-632BRP)

300Mbps, share multimedia throughout the house
