TRENDnet TEW-731BR Bedienungsanleitung

300Mbps Wireless N Home Router

TEW-731BR (V1.0R)

TRENDnet’s 300Mbps Wireless N Home Router, model TEW-731BR,

provides enhanced 300Mbps wireless n speed and coverage to share

ﬁ les, play games, and stream video wirelessly.

Advanced encryption protects your wireless network, Access Control

tools help block unwanted Websites and unknown users, and

embedded GREENnet technology reduces power consumption by up to

50%.

Advanced Multiple Input Multiple Output (MIMO) antenna technology

reduces wireless dead spots. Wi-Fi Protected Setup (WPS)

connects other WPS supported wireless adapters at the touch of a

button. WMM® Quality of Service (QoS) technology prioritizes gam-

ing, Internet calls, and video streams. LEDs on the front of the router

convey device status. Network wired devices to the four Fast Ethernet

ports on the back of the router.

FEATURES

• 4 x 10/100Mbps Auto-MDIX LAN ports

• 1 x 10/100Mbps Auto-MDIX WAN port (Internet)

• One touch wireless connection to wireless clients using the WPS button

• Wi-Fi compliant with IEEE 802.11n and IEEE 802.11b/g standards

• High-speed data rates of up to 300Mbps with IEEE 802.11n*

• GREENnet technology reduces power consumption by up to 50%

• Compatible with most popular cable/DSL Internet service providers using Dynamic/Static IP, PPPoE, PPTP and L2TP protocols

• 2 ﬁ xed external antennas support high speed performance and great coverage with MIMO technology

• Firewall features Network Address Translation (NAT)

• Virtual server and Application Level Gateway (ALG) services for special Internet applications

• Universal Plug and Play (UPnP) for auto discovery and support for device conﬁ guration of Internet applications

• Dynamic DNS Client for dynamic Internet IP resolution

• Provides additional security with Internet Access Control (MAC Address, Domain, and IP Filtering)

• Static and Dynamic RIP V1/2 routing support

• Easy setup via Web browser using Internet Explorer 6.0 or above, Firefox 2.0 or above, Chrome, Opera, Safari

• Advanced wireless security of up to WPA2-RADIUS

• Wi-Fi Multimedia (WMM) Quality of Service (QoS) data prioritization

• Indoor coverage up to 100 meters (330ft.)* depending on the environment

• Outdoor coverage up to 300 meters (980ft.)* depending on the environment

• 3- year limited warranty

*Maximum wireless signal rates are referenced from IEEE 802.11 theoretical speciﬁ cations. Actual data throughput and coverage

will vary depending on interference, network trafﬁ c, building materials and other conditions.

TEW-731BR

rev: 09.23.2011

300Mbps Wireless N Home Router

TEW-731BR (V1.0R)

TEW-731BR

rev: 09.23.2011

SPECIFICATIONS

HARDWARE

Standards • IEEE 802.3 (10BASE-T), IEEE 802.3u (100BASE-TX), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3az

WAN • 1 x 10/100Mbps Auto-MDIX port (Internet)

LAN • 4 x 10/100Mbps Auto-MDIX ports

WPS Button • Enables Wi-Fi Protected Setup (WPS) function (Hold for 3 seconds)

Power Switch • On/Off power switch

Connection Type • Dynamic IP, Static (ﬁ xed) IP, PPPoE, PPTP, L2TP

Supported Web Browsers • Internet Explorer 6.0 or above, Firefox 2.0 or above, Chrome, Opera, Safari

Internet Access Control • MAC Address Filter, Domain/URL Filter, Protocol/IP Filter, Virtual Server, DMZ host, UPnP, PPTP/L2TP/IPsec VPN

pass through

Management/ Monitoring • Local/remote conﬁ guration, upgrade ﬁ rmware, Backup/Restore conﬁ guration via Web browser, Internal System Log,

Syslog, E-Mail Logging, SNMPv1/v2c, Ping Test Tool, Dynamic DNS

Routing • Static and Dynamic RIPv1/2

LED Indicators • Power, Status, LAN1~LAN4, WAN, WLAN

Power • Input: 100~240V AC, 50~60Hz

• Output: 5V DC, 1A

Power Consumption • 3.0 Watts (max)

Dimension (L x W x H) • 158 x 109 x 34 mm (6.2 x 4.3 x 1.3 in)

Weight • 210 g (7.4oz)

Temperature • Operation: 0°~ 40°C (32°F~ 104°F)

• Storage: -10°~ 70°C (14°F~158°F)

Humidity • Max. 90% (non-condensing)

Certiﬁ cations • CE, FCC

WIRELESS

Frequency • 2.412~2.484GHz band

Antenna • 2 x 2dBi ﬁ xed dipole antennas

Modulation • 802.11b: CCK (11 and 5.5Mbps), DQPSK (2Mbps), DBPSK (1Mbps)

• 802.11g: OFDM with BPSK, QPSK and 16/64-QAM

• 802.11n: BPSK, QPSK, 16QAM, 64QAM with OFDM

Media Access Protocol • CSMA/CA with ACK

Data Rate • 802.11b: Up to 11Mbps

• 802.11g: Up to 54Mbps

• 802.11n: Up to 300Mbps

Security • 64/128-bit WEP (HEX/ASCII), WPA/WPA2-RADIUS, WPA/WPA2-PSK

Output Power • 802.11b: 15dBm (typical) @ 11Mbps

• 802.11g: 15dBm (typical) @ 54Mbps

• 802.11n: 13dBm (typical) @ 300Mbps

Receiving Sensitivity • 802.11b: -85dBm (typical) @ 11Mbps

• 802.11g: -68dBm (typical) @ 54Mbps

• 802.11n: -62dBm (typical) @ 300Mbps

Channels • 1~ 11 (FCC), 1~13 (ETSI)

CONTACT INFORMATION

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web: www.trendnet.com

Email: [email protected]

1-888-326-6061

PACKAGE CONTENTS

TEW-731BR

Multi-Language Quick Installation Guide

CD-ROM (User’s Guide)

Power adapter (5V DC, 1A)

Network cable (1.5 m / 5 ft.)

RELATED PRODUCTS

TEW-647GA 300Mbps Wireless N Gaming Adapter

TEW-640MB 300Mbps Wireless N 4-Port Media Bridge

TEW-624UB 300Mbps Wireless N USB Adapter

NETWORKING SOLUTIONS

300Mbps Wireless N Home Router

TEW-731BR (V1.0R)

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet products and is subject to change at any time,
