TRENDnet TEW-633GR - Wireless Router Bedienungsanleitung

The 300Mbps Wireless N Gigabit Gaming Router incorporates the

latest wireless and Gigabit networking technology to increase

speed, range, security and reliability. The router provides

unsurpassed gaming and network experience and performance.

Advanced antenna and 802.11 N technology increases wireless

data range and coverage. Enjoy lag-free gaming and file transfers

on your wired Gigabit computers via the built-in Gigabit switch. This

router features a powerful firewall and advanced wireless encryption

for secured transmissions. Quality of Service (QoS) prioritization

provides a seamless gaming and multimedia streaming experience.

Increased speed, throughput and range make it the perfect solution

to fulfill your gaming needs.

** Maximum wireless signal rates are referenced from IEEE 802.11

theoretical specifications. Actual data throughput and coverage will

cary depending on interference, network traffic, building materials

and other conditions.

TEW-633GR

Wireless N Gigabit Router

TEW-633GR

rev:08.15.2007

• Wi-Fi compliant with IEEE 802.11n and IEEE 802.11b/g standards

• 4 x 10/100/1000Mbps Auto-MDIX Gigabit LAN port and 1 x 10/100/1000Mbps Gigabit WAN port (Internet)

• Supports Cable/DSL modems with Dynamic IP, Static IP, PPPoE, PPTP, L2TP & BigPond connection types

• High-speed up to 300Mbps data rate using IEEE 802.11n connection

• Built-in 3 external antennas support high speed performance and great coverage

• Firewall features Network Address Translation (NAT), and Stateful Packet Inspection (SPI) protects against DoS attacks

• Traffic control with virtual servers, special applications, gaming services & Ubicom StreamEngine™ feature

• UPnP (Universal Plug & Play) and ALGs support for internet applications such as email, FTP, gaming, remote desktop, Net

Meeting, telnet, and more

• Provides additional security of enable/disable wireless SSID, internet access control (services, URL & MAC filtering)

• Supports multiple and concurrent IPSec, L2TP and PPTP VPN pass-through sessions

• Supports Static Routing – RIPv1 announcer

• Easy management via web browser (IE 6.0 or above, Firefox, Opera, Netscape) and remote management

• Supports 64/128-bit WEP(for 11b/g), WPA/WPA2 and WPA-PSK/WPA2-PSK

• Compliant with Windows 95/98/NT/2000/XP/2003 server/Vista, Linux and Mac OS

• Coverage up to 150 meters (500ft.) indoor(depends on the environment)

• Coverage up to 400 meters (1300ft.) outdoor(depends on the environment)

• 3 year warranty

FEATURES

Wireless N Gigabit Router

TEW-633GR

DMZ

DNS

Power Consumption

Internet Access Control

LED Indicator

Dimensions (LxWxH)

Weight

Temperature

• UPnP IGD Compliant

• Enable/Disable control support

• DMZ Host, 24 Configurable Virtual Servers & Game Servers

• Max. 90% (Non-Condensing)

• Static or WAN assigned DNS Servers

• 779mA

• Policy based parental control; Time based internet access; Port range/service filtering; Dynamic URL filtering; Internet domain

restriction; 32 user defined schedules, 24 MAC Address Filter Entries

• Operating: 0° ~ 40° C (32° ~ 104° F)

• Power, LAN1~LAN4, WAN, WLAN

• 12V DC, 1A External Power Adapter

• 150 x 162 x 25 mm (5.9 x 6.4 x 1 inches)

• 335g (11.8oz)

• CE, FCC

Humidity

Emissions

UPnP

Multicast Stream

Hardware

SPECIFICATIONS

Power Adapter

• Storage: -20° ~ 60° C (-4° ~ 140° F)

Standards

LAN

Slide Switch

NAT Firewall

Connection Type

• 1 x 10/100/1000Mbps Auto-MDIX gigabit port (Internet)

• Wired: IEEE 802.3 (10Base-T), IEEE 802.3u (100Base-TX), IEEE 802.3ab (1000Base-T)

• Turn On/Off Wireless LAN

• Dynamic IP, Static (Fixed) IP, PPPoE, PPTP, L2TP, BigPond

WAN

• IP Ranges, Port Ranges & Schedule

• Pre-Defined Game Hosting Configurations

• Cyber Attack Protection – Verified Against Over 2000 Attacks

• UP to 24 Rules

• Port triggering for 24 special applications

• ALG support (enable/disable support) – PPTP, IPSec, RTP/RTSP, AOL, FTP, ICMP, WMP/MMS, NetMeeting, SIP, MSN

Messenger, Wake on LAN

• 3K configurable NAT entries; Restricted NAPT

• 4 x 10/100/1000Mbps Auto-MDIX gigabit port

• Wireless: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n (draft 2.0)

SPI Firewall

TEW-633GR

rev:08.15.2007

WPS Button • Enable WPS function (PIN setup)

• 10 verified services for DDNS

Logging • 3 types & 3 severities event logging; up to 1K entries

• Email report logging on schedule or log full

Frequency

Media Access Protocol

Data Rate (auto fallback)

Receiving Sensitivity

Output Power

Security

Channels

• 3 x 4dBi Fixed Dipole Antenna

• 2.412 ~ 2.462 GHz (FCC)

• 802.11b: 18dBm (typical)

• 1~11 (US), 1~13 (EU)

• CSMA/CA with ACK

• 802.11b: -84dBm (typical) @ 11Mbps

• 802.11b: 11Mbps, 5.5Mbps, 2Mbps, and 1Mbps

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

RELATED PRODUCTS

TEW-630APB

TEW-621PC

TEW-623PI 300Mbps Wireless N-Draft PCI Adapter

300Mbps Wireless N-Draft Access Point

300Mbps Wireless N-Draft PC Card

• Power Adapter (12V DC, 1A)

• RJ-45 Cable (1.5m)

• Encryption: Hardware AES/TKIP, 64/128-bit WEP (Hex/Passpharse, for 11b/g)

• 802.11n (draft 2.0) : -70dBm (typical) with HT20 or HT40

• 802.11g: -72dBm (typical) @ 54Mbps

• 802.11n (draft 2.0): 6dBm (typical) with HT20 or HT40

• 802.11g: 15dBm (typical)

• WPA: WPA/WPA2, WPA-PSK/WPA2-PSK (AES-11b/g/n, TKIP-11b/g)

• WPS: support PIN and PBC

• 802.11g: 54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 9Mbps and 6Mbps

• 2.412 ~ 2.472 GHz (ETSI)

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web:

Email: [email protected]

www.trendnet.com

Wireless N Gigabit Router

TEW-633GR

TEW-624UB 300Mbps Wireless N USB 2.0 Adapter

300Mbps, share multimedia throughout the house Gigabit

Cable/DSL Modem

Game Console with Fast Ethernet

or Gigabit Connection

Workstations with

Gigabit PCI Adapter

(TEG-PCITXR)

Wireless N Gigabit Router

(TEW-633GR)

Notebook with

Gigabit PC Card

(TEG-PCBUSR)

Internet/

Game Servers

• 802.1X/EAP: EAP-TLE,EAP-TTLE/MSCHAPv2, PEAPv0/EAP-MSCHAPv2, PEAPv1/EAP-GTC

• SSID broadcast control
