Tripp Lite BP48V60-3UNAFTA Bedienungsanleitung

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: BP48V60-3UNAFTA

External Battery Pack for UPS System - NAFTA assembled version of BP48V60RT-3U

Highlights

Extends runtime of select compatible Tripp Lite UPS Systems with 48VDC

external battery connector

Provides daisy-chain capability

Simple installation; 3U rackmount, tower and stack adaptable

Description

BP48V60-3UNAFTA rack/tower external battery pack offers extended battery runtime when used in conjunction with compatible Tripp Lite systems.

Multi-use form factor supports configuration in stacking, upright tower and rackmount applications using only 3 rack spaces (3U). Includes heavy

gauge cabling with high current DC connector for simple installation. Additional output connector allows multiple BP48V60-3UNAFTA battery packs to

be daisy-chained to the UPS for even longer extended run operation.

COMPATIBLE UPS SYSTEMS - SM2200RMNAFTA, SM3000RMNAFTA, and other Tripp Lite UPS systems that specify the use of this battery pack.

Applications

Ideal means of lengthening the battery runtime provided by compatible Tripp Lite UPS systems. Battery pack may be ordered at time of

original UPS purchase or sourced at a later date to extend runtime performance if site power conditions deteriorate and longer battery

runtime is desired.

Package Includes

BP48V60-3UNAFTA external battery pack

Mounting hardware

Warranty information

Instruction manual

Features

Offers extended-run UPS operation when used in conjunction with compatible Tripp Lite UPS systems

Supports stacking or rackmount installation using only 3 rack spaces (3U)

Includes heavy gauge cabling with high current DC connectors for simple installation

Additional output connector allows multiple BP48V60RT3U battery packs to be daisy-chained to the UPS for even longer extended run

operation

Specifications

BATTERY

Expandable battery runtime Blue 2-point battery connector

DC system voltage (VDC) 48

Connects to UPS via Blue 2-point battery connector

Typical battery lifespan 4-6 years typical (North America)

PHYSICAL

Shipping weight (lbs) 200.6

Shipping weight (kg) 91.1

Unit Dimensions (HWD/in) 5.25 x 17.5 x 25

Unit Dimensions (HWD/cm) 13.3 x 44.4 x 63.5

Shipping Dimensions

(HWD/in)

11.25 x 23 x 31.5

Shipping Dimensions

(HWD/cm)

28.6 x 58.4 x 80

Unit weight (lbs) 163.1

Unit weight (kg) 74

Material of construction Steel

Form factors supported 3U rack/tower

ENVIRONMENTAL

Operating Temperature 32-104 degrees F / 0-40 degrees C

WARRANTY

Product Warranty Period

(U.S. & Canada)

2-year limited warranty

Product Warranty Period

(International)

1-year limited warranty

Product Warranty Period

(Mexico)

1-year limited warranty

Product Warranty Period

(Puerto Rico)

1-year limited warranty

Optional Coverage 3 year, 5 year, next day and on-site warranty coverage available

Related Items

Optional Products

Product Type Related Model Description Qty.

Extended Warranties WEXT3-BP48V60 3-Year Extended Warranty - For BP48V60RT3U and

BP48V60RT3UTAA Battery Packs

Extended Warranties WEXT5-BP48V60 5-Year Extended Warranty - For BP48V60RT3U and

PB48V60RT3UTAA Battery Packs

Rackmount/Wallmount Kits 2POSTRMKITWM Enables 2-Post Rackmount or Wallmount Installation of Select

Rackmount UPS Systems

Tower Stands 2-9USTAND Enables Tower Placement of Rackmount UPS Systems 1

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=3542.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
