Tripp Lite BP72V15-2U Bedienungsanleitung

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: BP72V15-2U

BP72V15-2U - External Battery Pack for UPS System

Highlights

Extends runtime of select compatible Tripp Lite UPS Systems with 72VDC

black 3-point external battery connector

Simple installation; 2U rackmount, tower and stack adaptable

Description

BP72V15-2U rack/tower external battery pack offers extended battery runtime when used in conjunction with compatible Tripp Lite systems.

Multi-use form factor supports configuration in stacking, upright tower and rackmount applications using only 2 rack spaces (2U). Upright tower

configuration supported with optional 2-9USTAND accessory. Includes heavy gauge cabling with high current DC connector for simple installation.

COMPATIBLE UPS SYSTEMS - SU3000RTXL2U, SU3000RTXL3U, SU3000RTXL3UHV, SU3000RTXR3U, SU3000RTXR3UHW,

SUINT3000RTXL2U, SUINT3000RTXL3U, SU3000XL and other Tripp Lite UPS systems that specify the use of this battery pack.

Package Includes

BP72V15-2U external battery pack

Mounting hardware

Warranty information

Instruction manual

Features

Offers extended-run UPS operation when used in conjunction with compatible Tripp Lite UPS systems

Supports stacking or rackmount installation using only 2 rack spaces (2U)

Supports upright tower installation with optional 2-9USTAND accessory

Includes heavy gauge cabling with high current DC connectors for simple installation

Specifications

BATTERY

Expandable battery

runtime

No, a max quantity of ONE BP72V15-2U can be connected to the host UPS system. If additional battery packs are

to be connected, use an expandable model, like BP72V28RT-3U

DC system voltage

(VDC)

Connects to UPS via DC connector

Typical battery lifespan 4-6 years typical (North America)

PHYSICAL

Shipping weight (lbs) 120

Shipping weight (kg) 54.5

Unit Dimensions

(HWD/in)

3.5 x 17.5 x 20.75

Unit Dimensions

(HWD/cm)

8.9 x 52.7 x 52.7

Shipping Dimensions

(HWD/in)

10 x 28.5 x 26.5

Shipping Dimensions

(HWD/cm)

25.4 x 72.4 x 67.3

Unit weight (lbs) 72.4

Unit weight (kg) 32.9

Material of construction Steel

Form factors supported 2U rack/tower

WARRANTY

Product Warranty

Period (U.S. & Canada)

2-year limited warranty

Product Warranty

Period (International)

1-year limited warranty

Product Warranty

Period (Mexico)

1-year limited warranty

Product Warranty

Period (Puerto Rico)

1-year limited warranty

Related Items

Optional Products

Product Type Related Model Description Qty.

Extended Warranties WEXT3-BP72V 3-Year Extended Warranty - For All 72V Battery Packs 1

Extended Warranties WEXT5-BP72V 5-Year Extended Warranty - For All 72V Battery Packs 1

Rackmount/Wallmount Kits 2POSTRMKITWM Enables 2-Post Rackmount or Wallmount Installation of Select

Rackmount UPS Systems

Tower Stands 2-9USTAND Enables Tower Placement of Rackmount UPS Systems 1

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=3019.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
