Model #: BP48V48RT4U

Shallow-Depth External Battery Pack For UPS Systems

Highlights

Extends runtime of select compatible Tripp Lite UPS Systems with 48 VDC

external battery connector

Shallow-depth rackmount case design is ideal for extended runtime

applications in wiring closets

Daisy-chain capability supports the connection of multiple external battery

packs

Simple 4U rackmount installation

Description

BP48V48RT4U shallow-depth rackmount external battery pack offers extended battery runtime when used in conjunction with compatible Tripp Lite

UPS systems. Supports configuration in rackmount applications using only 4 rack spaces (4U). Includes heavy gauge cabling with high current DC

connector for simple installation. Additional output connector allows multiple BP48V48RT4U battery packs to be daisy-chained to the UPS for even

longer extended run operation. Includes hardware for 2-post rackmount installation and supports optional 4-post rackmount installation with addition

of 4POSTRAILKIT accessory kit. Ideal for installation in wiring closet applications.

COMPATIBLE UPS SYSTEMS - SMART1500CRMXL, SMART2200CRMXL, SMART3000CRMXL, and other Tripp Lite UPS systems that specify

the use of this battery pack. (Note: BP48V48RT4U, SMART2200CRMXL and SMART3000CRMXL include hardware for 2-post rackmount

installation; most other rackmount UPS systems and battery packs include hardware for 4-post rackmount installation.)

Applications

Ideal means of lengthening the battery runtime provided by compatible Tripp Lite UPS systems. Ideal for wiring closet applications.

Additional battery packs may be ordered at time of original UPS purchase or sourced at a later date to extend runtime performance if site

power conditions deteriorate and longer battery runtime is desired.

Package Includes

BP48V48RT4U External Battery Pack

2-Post Rackmount Hardware

Owner's Manual with Warranty Information

Features

Offers extended-run UPS operation when used in conjunction with compatible Tripp Lite UPS systems

Shallow-depth design (16.75 inch depth) allows for ease of installation in wiring closets

Supports rackmount installation using only 4 rack spaces (4U)

Set of input/output connectors allows multiple BP48V48RT4U battery packs to be daisy-chained to the UPS for even longer extended run

operation

Includes heavy-gauge cabling with high-current DC connectors for simple installation

Specifications

OUTPUT

Overload protection 180A DC output fuse system

BATTERY

Expandable battery runtime Includes a second input/output connector to daisy-chain multiple BP48V48RT4U battery packs

DC system voltage (VDC) 48

Connects to UPS via Attached 20.5 inch cabling with UPS specific DC connector (52.1 cm length, 4 gauge cable)

Typical battery lifespan 4-6 years typical (North America)

PHYSICAL

Shipping weight (lbs) 169.8

Shipping weight (kg) 76.4

Unit Dimensions (HWD/in) 7 x 17.3 x 16.75

Unit Dimensions (HWD/cm) 17.78 x 44 x 42.5

Shipping Dimensions

(HWD/in)

14.4 x 25.2 x 22.8

Shipping Dimensions

(HWD/cm)

36.6 x 64 x 58

Unit weight (lbs) 143.3

Unit weight (kg) 64.5

Material of construction Black steel cabinet

Form factors supported 4U rack/tower

WARRANTY

Product Warranty Period

(U.S. & Canada)

2-year limited warranty

Product Warranty Period

(International)

1-year limited warranty

Product Warranty Period

(Mexico)

1-year limited warranty

Product Warranty Period

(Puerto Rico)

1-year limited warranty

Optional Coverage 3 year, 5 year, next day, on-site warranty coverage available

Related Items

Optional Products

Product Type Related Model Description Qty.

Extended Warranties WEXT3-BP48V48 3-Year Extended Warranty - For BP48V48RT4U 1

Extended Warranties WEXT5-BP48V48 5-Year Extended Warranty - For BP48V48RT4U 1

Rackmount/Wallmount Kits 4POSTRAILKIT Enables 4-Post Rackmount Installation of Select Rackmount UPS

Systems

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=3810.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
