InterServe 90
System Board Manual
D5AA00040
April 1999
Errata
The System Board Manual from the manufacturer of the system board
reflects a wrong jumper setting for dual-floppy operation. In this
manual, jumper JP4 is listed as being open for dual-floppy support.
The correct setting is as follows:
JP4 Pins 1-2
Dual-floppy support Closed
Single-floppy support Open
TyanS1832DL
Tiger 100
Motherboard User’s Manual
Revision 2.10
Copyright © Tyan Computer Corporation, 1998. All rights reserved. No part of this
manual may be reproduced or translated without prior written consent from Tyan
Computer Corp.
All registered and unregistered trademarks and company names contained in this
manual are property of their respective companies including, but not limited to the
following.
AMI BIOS is a trademark of American Megatrend Incorporated.
Windows is a trademark of Microsoft Corporation.
IBM, PC, AT, PS/2 are trademarks of IBM Corporation.
INTEL, Pentium II, Celeron, Xeon are trademarks of Intel Corporation.
S1832 Tiger 100 is a trademark of TYAN Computer Corporation.
Information contained in this publication has been carefully checked for accuracy and
reliability. In no event will Tyan Computer be held liable for any direct or indirect,
incidental or consequential damage, loss of use, loss of data, or other malady resulting
from errors or inaccuracies of information contained in this manual. The information
contained in this document is subject to change without notice.
PRINTED IN USA.
Table of Contents
1. Introduction...........................................................................4
Overview........................................................................4
Icons.............................................................................. 5
Hardware Specifications/Features................................... 6
Software Specifications...................................................8
Technical Support...........................................................8
Returning Merchandise for Service................................9
2. Board Installation..............................................................10
Unpacking....................................................................10
Installation....................................................................10
Setting Jumpers.............................................................24
3. Onboard Resource Settings..............................................26
Quick Reference for Jumpers........................................26
Map of Motherboard Jumpers....................................... 27
Soft Power Connector.................................................. 31
Speaker Connector Installation...................................... 31
Hardware Reset Switch Connector Installation...............31
External SMI............................................................... 32
Chassis Intrusion Alarm Connector................................ 32
CMOS RTC.................................................................32
Flash EEPROM........................................................... 32
Hardware CMOS & Password Reset............................33
RAM Installation.......................................................... 33
Cache Memory.............................................................34
Frequently Asked Questions..........................................35
4. BIOS Configuration...........................................................38
Main Setup...................................................................39
Advanced CMOS Setup................................................44
Chipset Setup............................................................... 49
Power Management Setup............................................ 55
PnP/PCI Setup.............................................................59
Peripheral Setup........................................................... 64
Supervisor and User Security.........................................68
Language Utility........................................................... 69
Flash Writer Utility........................................................69
5. System Resources.............................................................70
Beep Codes................................................................. 70
Troubleshooting System Problems..................................71
Displayed Error Messages............................................ 72
Appendix 1 - CPU Retention Module Options.....................74
Appendix 2 - Glossary........................................................... 76
http://www.tyan.com
4
Chapter 1
Introduction
Overview
The S1832DL Tiger 100 is a quality, high performance mainboard designed for
dual Intel Pentium II microprocessors. This mainboard utilizes the Intel 440BX
AGPset and can support CPU speeds of 233MHz through 450MHz, and host
bus speeds of 66MHz to 100MHz.
TheS1832DLmainboard,with built-inAGP slot,provides highperformance
capabilities that are ideal for a wide range of demanding applications such as
CAD, CAM, CAE, desktop publishing, 3D animation, and video production.
This integrated system board achieves high reliability with numerous features
and yet is small enough to be supported in an ATX form factor. Some of the
features included are onboard dual channel PCI PIO, Bus Master IDE and
UltraDMA/33, onboard floppy controller, and onboard high speed I/O.
Flexibility and expandability have been designed into the Tiger 100. With I/O
and drive controller support built onboard, the one AGP slot, five PCI and two
ISA slots (one shared, seven usable slots) are free for numerous add-on
expansion cards.
Remember to take a look at TYAN Computer’s web site located at
chapter 1
Introduction
http://www.tyan.com
5
INTRO
http://www.tyan.com. There you can find information on all of TYAN’s
products along with FAQs, distributors list, drivers, and BIOS setting explana-
tions.
Icons
In order to help you navigate this manual and set up your system, we have
added several icons to our format.
This icon alerts you to particularly important details regarding the
setup or maintenance of your system. This icon often appears
next to information that may keep you from damaging your board
or system. While we will often point out the most vital para-
graphs in a chapter, you should always read every word in the text. Failing to
do so can lead to exasperation and expense.
Wherever possible, we have included step-by-step instructions
for setting up your system, which are indicated by this icon.
However, it is in your best interest to read an entire section (and
perhaps the entire manual) before you begin to fiddle with your motherboard.
While we have alerted you to potential dangers in several places
in the manual with this icon, these warnings should not be
regarded as the whole of your safety regimen. Never forget that
computers are electrical devices, and are capable of delivering a shock. Prevent
damage to yourself and to your board: always ensure that your system is
turned off and unplugged whenever you are working with it, and that you are
equipped with a static safety device.
!
important!
procedure
1.
2.
3.
warning
http://www.tyan.com
6
Chapter 1
Introduction
HardwareSpecifications/Features
Processor Information •Two SEC slots (Slot One type).
•66to 100MHzBIOS selectablebus
support.
•PentiumII233-450MHz.
•Supports Celeron CPU (single only).
Chipset Information •Intel440BXAGPset.
•IntelPIIX4econtroller.
•National 309 Super I/O chipset.
Voltage and Power •ATX power supply connector.
Information •+12Vpower source for DC fan
onboard.
•3.3VDRAM support.
•Utilizes GTL+ bus to reduce power
consumption and EMI.
Main Memory •Up to 1024MB onboard.
•Four 168-pin DIMM sockets.
•Supports100MHz SDRAM with
SPD.
System Management •NationalLM79 and LM75
ASICs with onboard alarm for
monitoring temperature, supply
voltages, and fan speed.
•System Manager software
•Chassis intrusion detection capable.
Expansion Slots •One32-bitAGPslot.
•Five 32-bit PCI Bus Master slots.
•Two 16-bit ISA slots.
•One shared, seven usable slots.
http://www.tyan.com
7
INTRO
Physical Dimensions •ATX design.
•12inches x9.8 inches.
•Requires Intel Venus compatible I/O
shield.
BIOS Information •AMI Plug and Play flash BIOS.
•DeepGreen,EnergyStar, ACPI,
Year 2000, and PC98 compliant.
•Soft power-down, multiple boot
options.
•Win98/NT5ready,DMI 2.0
compliant.
•PCI2.1, APM 1.1 compliant.
Disk Drive & System I/O •TwoPCIbus mastering EIDE
channels.
•SupportsEIDECD-ROMs.
•PIO Mode 3 & 4 (up to 17MB/sec
DTR).
•UltraDMA/33 bus mastering mode
(up to 33MB/sec DTR).
•Support for two floppy drives (up to
2.88MB).
•Twoserialports (16550 UARTs).
•OneECP/EPPparallelport.
•One IR (InfraRed) I/O interface port.
•TwoUSB rev 1.2 (universal serial
bus) connectors.
•One PS/2 mouse connector.
•One PS/2 keyboard connector.
http://www.tyan.com
8
Chapter 1
Introduction
SoftwareSpecifications
OS •Operates with MS-DOS, Windows
3.x,Windowsfor WorkGroup3.x,
Windows 95, Windows 98, Windows
NT, OS/2, Novell Netware,andSCOUnix.
Information presented in this publication has been carefully checked for
reliability. However, no responsibility is assumed for inaccuracies. The
information contained in this document is subject to change without notice.
Technical Support
If a problem arises with your system, you should turn to your dealer for help
first. Your system has most likely been configured by them, and they should
have the best idea of what hardware and software your system contains.
Hence, they should be of the most assistance. Further, if you purchased your
system from a dealer near to you, you can actually bring your system in to
them to have it serviced, instead of attempting to do so yourself (which can
have expensive consequences).
If your dealer is unable to assist you,
1) try our web page: http://www.tyan.com
2) user newsgroup: alt.comp.periphs.mainboard.tyan
3) technical support phone line: (510) 440-8808
