TYAN THUNDER 2 ATX Bedienungsanleitung
Notice for the USA
Compliance Information Statement (Declaration of Conformity Proce-
dure) DoC
FCC Part 15: This Device complies with Part 15 of the FCC Rules.
Operation is subject to the following conditions:
1) this device may not cause harmful interference, and
2) this device must accept any interference received including interfer-
ence that may cause undesired operation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged
to try one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Plug the equipment into an outlet on a circuit different from
that of the receiver.
•Consult the dealer or an experienced radio/television
technician for help.
Notice for Canada
This apparatus complies with the Class B limits for radio interference
as specified in the Canadian Department of Communications Radio
Interference Regulations.
Cet appareil est conforme aux normes de Classe B d’ interference
radio tel que spécifié par le Ministére Canadien des Communications
dans les réglements d’interférence radio.
Notice for Europe (CE Mark)
This product is in conformity with the Council Directive 89/336/EEC,
92/31/EEC (EMC).
Table of Contents
1. Introduction....................................................................... 4
Overview..................................................................... 4
Icons........................................................................... 5
Hardware Specifications/Features................................. 6
Software Specifications.................................................9
Technical Support......................................................... 9
Returning Merchandise for Service................................10
2. Board Installation.............................................................. 12
Unpacking....................................................................12
Installation....................................................................13
Setting Jumpers............................................................ 13
3. Onboard Resource Settings.............................................. 14
Quick References for Jumpers...................................... 14
Map of Motherboard Jumpers....................................... 15
Soft Power Connector...................................................19
Sleep Button Connector.................................................19
Speaker Connector Installation...................................... 19
External SMI................................................................19
Hardware Reset Switch Connector Installation...............20
CMOS RTC.................................................................20
Flash EEPROM........................................................... 21
Hardware CMOS & Password Reset............................21
DRAM Installation....................................................... 21
Installing the CPU........................................................ 23
Peripheral Device Installation........................................ 28
Connecting the Power Supply........................................ 28
Frequently Asked Questions.......................................... 30
4. BIOS Configuration...........................................................32
Standard Setup............................................................. 32
BIOS Features Setup....................................................34
Advanced Setup........................................................... 35
Chipset Setup............................................................... 40
Power Management Setup............................................ 49
PCI/PnP Setup............................................................. 52
Peripheral Setup........................................................... 55
Flash Writer Utility........................................................58
5. System Resources............................................................. 60
POST Checkpoint Codes.............................................. 60
Beep Codes................................................................. 68
Troubleshooting System Problems..................................69
Displayed Error Messages............................................ 70
Additional Manuals....................................................... 72
4
Overview
The Thunder 2 (S1696DLUA) is a quality, high performance
motherboard designed for Intel’s latest generation of Pentium II
microprocessors. This motherboard utilizes Intel’s 440LX AGP series
chipset (also called AGPset) and supports Pentium II CPU speeds of
233MHz to 300MHz.
The Thunder 2 mainboard with built-in AGP slot provides high perfor-
mance capabilities that are ideal for a wide range of demanding appli-
cations such as CAD, CAM, CAE, desktop publishing, 3D animation,
and video production. The Thunder 2 is suitable as a powerful worksta-
tion, internet, intranet, file, network, and database server. The Thunder
2’s superior dual processor technology increases performance and
productivity drastically for multi-processor enabled operating systems
such as Microsoft Windows NT, Novell Netware SMP, and SCO Unix.
This integrated system board achieves high reliability with numerous
features. Some of the features included are onboard dual channel PCI
UltraDMA 33, built-in Adaptec AIC7895 two channel ultra-wide SCSI
and a third narrow SCSI, built-in Yamaha 16-bit OPL3-SA3 and OPL4-
Chapter 1
chapter 1
Introduction
5
INTRO
ML wavetable and 3D sound chips, onboard floppy controller, and
onboard high speed I/O.
The Thunder 2 board is built to be both flexible and expandable. With
I/O and drive controller support built onboard, the four 32-bit PCI BUS
Master and two ISA slots (one shared, six usable) are available for
add-on expansion cards.
Icons
In order to help you navigate this manual and set up your system, we
have added several icons to our format.
This icon alerts you to particularly important details regarding
the setup or maintenance of your system. This icon often
appears next to information that may keep you from damag-
ing your board or system. While we will often point out the most vital
paragraphs in a chapter, you should always read every word in the text.
Failing to do so can lead to exasperation and expense.
Wherever possible, we have included step-by-step instructions
for setting up your system, which are indicated by this icon.
However, it is in your best interest to read an entire section
(and perhaps the entire manual) before you begin to alter the settings
on your motherboard.
While we have alerted you to potential dangers in several
places in this manual with this icon, these warnings should not
be regarded as the whole of your safety regimen. Never
forget that computers are electrical devices, and are capable of deliver-
ing a burn or shock. Prevent damage to yourself and to your board:
always ensure that your system is turned off and unplugged whenever
you are working with it, and that you are equipped with a static safety
device.
!
6
HardwareSpecifications/Features
Processor Information sPentium II 233-300 MHz.
sTwo SEC slots (Slot One).
s2 VRM components installed
onboard.
s3 onboard CPU fan connectors.
sIntel MPS v1.4 compliant.
Chipset Information sIntel 440LX AGPset.
sIntel 82371AB(PIIX4).
sIntel 82093 I/O APIC chip.
Voltage and Power sATX power supply connector.
Information s+12 V power source for DC fan
onboard.
s3.3V DRAM support.
sUtilizes GTL+ BUS, reducing power
consumption and EMI.
sPower recovery after interrupt.
sBulit-in overload protection that
automatically shuts down the system
in case of power surge.
Main Memory sUp to 1024MB EDO or 512MB
SDRAM onboard.
sFour 168-pin DIMM slots.
sEDO or SDRAM support.
sECC support.
System Management sWake-on LAN 3-pin connector for
remote booting by Network
Administrator.
sOnboard National LM75 chip for
CPU temperature sensing.
Chapter 1
7
sOnboard National LM78 thermal
control chip for heat, fan, and voltage.
Reports to the operating system for
system monitoring. LANdesk
compatible.
sIntel LANDesk Client Manager
software, and/or Intel LANDesk
Server Manager software (with LM78
installed).
Expansion Slots sOne AGP slot for 3D graphics card
(supports 1x and 2x).
sFour 32-bit PCI BUS Master slots.
sTwo 16-bit ISA slots.
sOne shared, six usable.
Physical Dimensions sIntel ATX design.
s9.75 x 12 inches.
sDouble-row ATX connectors.
BIOS Information sAMI Plug and Play flash BIOS.
sDeep Green and Energy Star
compliant.
sACPI, Year 2000, and PC97/98
ready; PCI 2.1 compliant.
sSoft power-down, multiple boot
options.
sWin98 Ready, DMI 2.0 compliant.
sSupport for easy BIOS upgrades with
flash EEPROM chip.
IDE Disk Drive & sTwo PCI BUS Mastering EIDE
System I/O channels.
sSupports EIDE CD-ROMs.
sPIO Mode 3 & 4 (up to 17MB/sec
DTR).
INTRO
8
Chapter 1
sUltraDMA 33 BUS Mastering Mode
(up to 33MB/sec DTR).
sTwo floppy drives (up to 2.88MB).
sTwo ATX serial ports (16550
UARTs).
sOne ATX ECP/EPP parallel port.
sOne IR (InfraRed) I/O interface
port.
sTwo USB rev 1.2 (universal serial
BUS) ports.
sOne ATX PS/2 mouse port.
sOne ATX PS/2 keyboard connector.
SCSI Disk Controller sOnboard two channel Adaptec AIC-
7895 Ultra-Wide SCSI controller
(equivalent to Adaptec 3940AUW).
sTwo Ultra-Wide channels with
synchronous 40MB/s DTR. Connect
up to fifteen 16-bit devices per
channel (thirty devices total). Up to
seven of the fifteen devices can be 8-
bit devices.
sOne Narrow channel with 20MB/s
DTR.
sBuilt-in RISC sequencer automates
SCSI protocol. Supports 32-bit BUS
master DMA transfer.
sRAID 0, 1, and 5 function built-in
with optional RAIDport card installed.
Sound Chip Information sOnboard Yamaha OPL3-SA3
advanced 16-bit FM-synthesizer.
sOnboard Yahama OPL4-ML
advanced wavetable with General
MIDI and MPU401 support.
s44 voice wavetable synthesis in 1MB
of wavetable ROM.
9
sSound Blaster Pro and Windows
Sound System compatible.
sPlug and Play with full duplex
operation.
sBuilt-in 3D stereo sound and power
management.
sOne game joystick port, one line-
input, speaker output, and one
microphone input.
SoftwareSpecifications
Operating System sOperates with MS-DOS, Windows
3.x, Windows for WorkGroups 3.x,
Windows 95, Windows NT, OS/2,
Novell Netware, Solaris, and SCO
Unix.
Technical Support
If a problem arises with your system, you should first turn to your
dealer for help. Your system has most likely been configured by them,
and they should have the best idea of what hardware and software your
system contains. Hence, they should be able to be of the most assis-
tance. Further, if you purchased your system from a dealer near to you,
you can actually bring your system in to them to have it serviced,
instead of attempting to yourself (which can have expensive conse-
quences).
If your dealer is unable to assist you:
Try our web page – http:// www.tyan.com,
or user newsgroup – alt.comp.periphs.mainboard.tyan.
INTRO
10
Chapter 1
ReturningMerchandiseforService
During the warranty period, contact your distributor or system vendor
FIRST for any product problems. This warranty only covers normal
customer use and does not cover damages incurred during shipping or
failure due to the alteration, misuse, abuse, or improper maintenance of
products.
For Resellers Only:
A receipt or copy of your invoice marked with the date of purchase is
required before any warranty service can be rendered. You can obtain
service by calling the manufacturer for a Return Merchandise Authori-
zation (RMA) number. The RMA number should be prominently
displayed on the outside of the shipping carton and the package should
be mailed prepaid, or hand-carried to the manufacturer. Shipping and
handling charges will be applied for all orders that must be mailed when
service is complete.
Trademarks
AMI BIOS/Flash are trademarks of American Megatrend Inc.
Windows is a trademark of Microsoft Corporation.
IBM, PC, AT, PS/2 are trademarks of IBM Corporation.
INTEL, Pentium II are trademarks of Intel Corporation.
S1696DLUA Thunder 2 is a trademark of TYAN Computer
Corporation.
All other trademarks are the property of their respective companies.
Disclaimer
Information presented in this publication has been carefully checked
for reliability. However, no responsibility is assumed for inaccuracies.
The information contained in this document is subject to change
without notice.
Dieses Handbuch passt für folgende Modelle
1
Inhaltsverzeichnis
Andere TYAN Hauptplatine Handbücher
TYAN
TYAN THUNDER K7 Bedienungsanleitung
TYAN
TYAN TAHOE 2 ATX Bedienungsanleitung
TYAN
TYAN THUNDERBOLT Bedienungsanleitung
TYAN
TYAN S1570 AT Bedienungsanleitung
TYAN
TYAN S5535 Bedienungsanleitung
TYAN
TYAN TIGER I7501X Bedienungsanleitung
TYAN
TYAN Trinity 100AT S1590 Bedienungsanleitung
TYAN
TYAN Single S1662S Bedienungsanleitung
TYAN
TYAN Tiger i7322 S5351 Bedienungsanleitung
TYAN
TYAN TOMCAT H1000S Bedienungsanleitung
TYAN
TYAN TIGER I7501X Bedienungsanleitung
TYAN
TYAN TIGER I7501S Bedienungsanleitung
TYAN
TYAN THUNDER 2400 Bedienungsanleitung
TYAN
TYAN Tempest i5400XL Bedienungsanleitung
TYAN
TYAN THUNDER K8QW Bedienungsanleitung
TYAN
TYAN THUNDER 2400 Bedienungsanleitung
TYAN
TYAN S1832DL Bedienungsanleitung
TYAN
TYAN TOMCAT I7210 Bedienungsanleitung
TYAN
TYAN Thunder K8W S2885 Bedienungsanleitung
TYAN
TYAN S1830 TSUNAMI AT Bedienungsanleitung
Beliebte Hauptplatine Handbücher anderer Marken
Telit Wireless Solutions
Telit Wireless Solutions SL869-3DR Bedienungsanleitung
Gigabyte
Gigabyte GA-9IVDT Bedienungsanleitung
Texas Instruments
Texas Instruments ADS8372EVM Bedienungsanleitung
Commell
Commell MS-C73 Bedienungsanleitung
IBT Technologies
IBT Technologies MB860 Bedienungsanleitung
Nvidia
Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung
