0110 IH-2508PAGE 1 OF 2

1-800-295-5510

uline.com

ADJUSTABLE PALLET

STAND

H-2508

SAFETY INSTRUCTIONS

INSTALLATION INSTRUCTIONS

WARNING! Follow these safety instructions to

avoid any personal injuries.

1. Raise and lower the pallet stand only from side with

lifting handles and handle bar.

2. Do not raise or lower the pallet stand while loaded.

3. Do not stand on the pallet stand.

4. Do not crawl under the pallet stand at any time.

5. Keep hands, feet, and foreign objects out from

underneath pallet stand.

6. Do not exceed maximum loading capacity of 5,000

pounds.

7. Insure pallet stand is evenly loaded for safety.

8. Visually check that the top of the scissor leg is

securely in lock notch.

9. Make sure all operator safety labels are in place.

Spring must be installed prior to use of the Pallet Stand.

NOTE: For spring installation two people are

recommended.

1. Handle bar has three settings. The Middle, or neutral

setting, is for storage only. The Left setting is for

moving the stand from the storage position into the

ﬁrst position only or vice versa. The Right setting is for

is for moving the stand from the ﬁrst position to the

second or third position and vice versa.

2. Move handle bar securely into the Left setting.

3. Lift stand from the storage position into the ﬁrst

operating position using a lift handle and

handle bar.

NOTE: Be sure the unit is locked into position

before proceeding on to the next step.

4. Slide the handle bar from the Left into the Right

setting.

5. Lift stand from the ﬁrst operating position to the third

operating position.

NOTE: Be sure the unit is locked into position

before proceeding on to the next step.

6. The unit should be in the third operating position

(raised all the way). Attach springs to washers that

are located in-between the scissor legs, just above

the pivot point.

0110 IH-2508PAGE 2 OF 2

OPERATING INSTRUCTIONS

WARNING LABELS

WARRANTY

1. The Adjustable Pallet Stand has three operating

heights at 19", 28" and 33". The unit collapses down

to 9" for storage only.

2. To raise the stand from the storage position into the

ﬁrst operating position, slide the handle bar from

the Middle setting to the Left setting. Grip one lifting

handle and the handle bar and lift the stand until it

locks into the ﬁrst operating position.

3. To raise the stand from the ﬁrst operating position

to a higher operating position, slide the handle bar

into the Right setting. Grip one lifting handle and the

handle bar and lift the stand until it locks into the

desired operating position.

4. To lower the stand into the ﬁrst operating position,

slide the handle bar into the Right setting. Grip

one lifting handle and slightly raise the platform to

unlock it’s position. Grip the handle bar and lower

the stand into the ﬁrst operating position.

5. To lower the stand into the storage position from the

ﬁrst operating position, slide the handle bar to the

Left setting. Grip one lifting handle and slightly raise

the platform to unlock it’s position. Grip the handle

bar and lower the stand into the storage position.

1. WARNING! To adjust height engage handle bar

and lift on either lifting handle to engage positive

locking device.

2. WARNING! Grip here.

3. WARNING! Keep clear of pinch point.

This product is warranted for 90 DAYS from date of

purchase to be free of manufacturing defects in

material and workmanship. The manufacturer’s

obligation hereunder is limited to repairing such

products during the warranty period, provided the

product is sent prepaid back to the factory.

This warranty does not cover normal wear of parts or

damage resulting from any of the following: negligent

use or misuse of the product, use or application contrary

to installation instructions, or disassembly, repair or

alteration by any person prior to authorization from a

factory representative.

LIFTING HANDLE

HANDLE BAR

LIFTING HANDLE
