Uniden FP105 Bedienungsanleitung

OPERATING GUIDE

Caller Display with

VIP Speaker phone

FP105

INTRODUCTION

Welcome

TO YOUR NEW PHONE

Congratulations on the purchase of your Uniden FP105 Telephone

The FP105 has been designed and engineered to exacting standards for

reliability, long life and outstanding performance.

To obtain the full benefit from your new telephone, please read this Operating

Guide thoroughly.

For your future reference, please fill in the panel below and attach your

Purchase Receipt / Sales Docket.

Serial No: Date of Purchase:

(found on the bottom of the product box)

Name and Address of Dealer:

WELCOME

Contents

CONTENTS

Important Safety Instructions

Contents

Introduction / Welcome

Included in Package

Features 6

Controls and functions 11

Installing your phone 11

Wall mounting

Using your phone

Placing a telephone call

Redial

Receiving a telephone call

CONTENTS

OF YOUR OPERATING GUIDE

Important Information

Handset cord connection

Connecting the power

Adjusting the ringer volume control

Adjusting the ringer tone control

Adjusting the handset volume control

Mute

Placing a call on hold

Speaker phone

Adjusting the speaker phone volume control

Storing one-touch speed dial numbers 17

Memory dial numbers

Pause

Dialing stored numbers

Chain dialing

Call timer

LCD backlight display

Editing a stored one-touch speed dial memory

Deleting one speed dial memory

Deleting all speed dial memories

Memory storage card

Contents

CONTENTS

OF YOUR OPERATING GUIDE

Using the pre-programmed feature buttons - SMARTPHONE 20

Call Minder 20

Call Diversion 20

Call Return 21

Call Back 21

Call Waiting 21

Suspend Call Waiting 21

Using Caller Display 22

New call notification 22

New call review 22

Caller Display summary 23

Call review 23

Deleting a call from the call history 24

Deleting all calls from the call history 24

Speed dialing from the Caller Display list 24

Transferring a Caller Display number to a speed dial memory 24

Display messages 25

26Special features - VIP

Setting a VIP call 26

Reviewing VIP calls 26

Speed dialing from the VIP list 26

Resetting a VIP call 27

Deleting a VIP call 27

Name matching 27

Advanced user options menu 28

Setting the LCD contrast 28

Setting the time and date 28

Setting VIP alert on / off 28

Setting the stutter dial tone detect on / off 28

Troubleshooting 29

Specifications / Warranty 30

33 memory Caller Display 22

Important Information

IMPORTANT SAFETY INSTRUCTIONS

When using your telephone equipment, these basic safety precautions should always be followed to

reduce the risk of fire, electrical shock, and injury to persons:

1) Read and understand all instructions.

2) Follow all warnings and instructions marked on the product.

3) Unplug this product from the wall outlet before cleaning, and use a dry cloth, without liquid or

aerosol cleaners.

4) Do not use this product near water; for example, near a bath tub,wash bowl, kitchen sink or

laundry

tub, in a wet basement or near a swimming pool.

5) Do not place this product on an unstable cart, stand or table. The telephone may fall, causing

serious damage to the unit.

6) This product should be operated only from the type of power source indicated on themarking

label. If you are not sure of the type of power supply to your home, consult your dealer or local

power company.

7) Do not allow anything to rest on the power cord. Do not locate this product where the cord will

be damaged by persons walking on it.

8) Do not overload wall outlets and extension cords, as this can result in the risk of fire or electrical

shock.

This unit is not waterproof. To reduce the risk of fire, electrical shock or damage,

DO NOT expose this product to rain, water or any other liquid or moisture.

Important Information

Immediately disconnect this equipment should it become physically damaged,

and arrangefor its disposal or repair.

This telephone has been designed to conform to local regulations, and you can connect

it to most telephone lines, however you must not connect your phone to any of the

following:

IMPORTANT INFORMATION

CARING FOR YOUR TELEPHONE

•Clean your telephone using a soft damp cloth.

•DO NOT use solvents, detergents, sprays, abrasive pads, scouring powder

or otherproducts that may damage your telephone.

•DO NOT place the telephone in direct sunlight.

•DO NOT use in extreme humidity.

The exclamation point within an equilateral triangle is intended to alert the

user to thepresence of important operation, maintenance and service

instructions in the literature accompanying this product.

IMPORTANT NOTES

3. This equipment shall not be used in any manner which could constitute a nuisance

to other Telecom customers.

PLEASE READ BEFORE USE AND SAVE THESE INSTRUCTIONS

•Coin operated systems

•Party-line systems

•Most electronic key phone systems

Each device that you connect draws power from the phone line. We refer to the power

drawn as the device’s Ringer Equivalence Number (REN or RN). This number is shown

on the bottom of your telephone. If you are using more than one phone or other device

on the line, add up all theRN’s. If the total is more than three, your phones may not ring.

The grant of a Telepermit for any item of terminal equipment indicates only that

Telecom has accepted that the item complies with minimum conditions for

connection to its network. It indicates no endorsement of the product by Telecom,

nor does it provide any sort of warranty. Above all, it provides no assurance that

any item will work correctly in all respects with another item of Telepermitted

equipment of a different make or model, nor does it imply that any product is

compatible with all of Telecom's network services.

Features

FEATURES

Telephone

•LCD with backlight

•Hands-free speaker phone

•12 one-touch speed dial

•32 digit memory per speed dial

•7 Pre-programmed feature buttons

•Hearing aid compatible

•Call Waiting compatible

•Redial, Flash and Pause

•Mute

Caller Display

•33 memory Caller Display

•24 digits and 16 characters per record

•Advanced Caller Display review functions

•VIP alert – 3 different ringer tones

•Name matching

•

•Call timer

•Wall mountable

Adjustable ringer volume control

•Adjustable handset volume control

•Adjustable ringer tone control

•Adjustable speaker phone volume control

Included in your package

Quick start guide

NOTE

TIP

INCLUDED IN YOUR PACKAGE

Base Unit Handset Curly Cord

Telephone line cord AC Adaptor Back-up Battery

Memory storage card

Registration card Operating guide

If any of these items are missing or damaged, contact

the place of purchase.

To get the most from your purchase, please read this

Operating Guide thoroughly. Also be sure to complete

the Product Registration Form.

2 x Wall mounting

screws and plugs Wall mounting bracket

Controls and functions

CONTROLS AND FUNCTIONS

new call LED

12 one-touch speed dial buttons

memory storage card

handset retainer tab

new call counter

numeric line

alpha line

date

10 call waiting icon

7 Telecom Service buttons

envelope icon

LCD screen

VIP on icon

VIP call icon

low battery icon

message waiting

time

Caller Display delete button

<< Scroll left button

>> Scroll right button

Caller Display mode button

message waiting LED

hold / speaker LED

Controls and Functions

dial button

store button

cancel button

redial / pause button

hold button

speaker phone button

mute button

memory storage

instructions draw

handset volume control

speaker volume control

battery cover located

underneath phone.

AC adaptor power socket

telephone line socket

ringer tone control

ringer volume control

37 reset button
