MX-6000 TWO WAY TOUCH SCREEN

This remote control was Custom Programmed for you by:

For questions about your Custom Programming call:

Custom Programming of a complex home theater and/or

a multi-room system is one of the most challenging tasks

within an audio/video installation. It involves an intimate

knowledge of how the components interact and exact

details on the proper sequences of control.

Only a Complete Control dealer has the requisite

experience and training to quickly and effectively cus-

tomize a remote control for true automated operation.

Congratulations on your choice!

The information in this manual is copyright protected. No part of this manual may

be copied or reproduced in any form without prior written consent from Universal

Remote Control, Inc.

UNIVERSAL REMOTE CONTROL, INC. SHALL NOT BE LIABLE FOR OPERATIONAL,

TECHNICAL OR EDITORIAL ERRORS/OMISSIONS MADE IN THIS MANUAL.

The information in this manual may be subject to change without prior notice.

Complete Control is a registered trademark of Universal Remote Control, Inc.

Entertainment Made Simple is a trademark of Universal Remote Control, Inc.

All other brand or product names are trademarks or registered trademarks of their

respective companies or organizations.

500 Mamaroneck Avenue, Harrison, NY 10528

Phone: (914) 835-4484 Fax: (914) 835-4532

OCE-0026G(MX-6000)_REV04.QXD 2/22/11 10:17 AM Page 2

Page 3

MX-6000 TWO WAY TOUCH SCREEN

Table of Contents

Introduction 4

Connecting the Battery Pack 5

Using the Charging Base 5

Two Way via WiFi 5

Optional RF “No Rules” Operation 6

Operating Your System 7

Using Two Way Personal Server Features 8

Displaying the Settings Screen 11

Sleep Settings 11

Brightness 11

Button Light 11

Vibrate/Sound 12

Date and time 12

Power Settings 12

System 12

Pickup Settings 13

Network 13

Calibration 13

Factory Default 13

Exit 13

USA Limited Warranty Statement 14

Information to the End User 15

Maintaining Your MX-6000 16

Specifications 16

OCE-0026G(MX-6000)_REV04.QXD 2/22/11 10:17 AM Page 3

Page 4

MX-6000 TWO WAY TOUCH SCREEN

Congratulations

You’ve purchased a unique synthesis

of hardware and software engineer-

ing, the Complete Control MX-6000.

The twin goals of the design team

were to improve the elegance and

usability of touch screens through the

physical design while providing a

new standard in brightness, clarity

and animation for the touch screen

itself.

Easy Operation

By assigning the important home theater operational buttons to the

natural resting place of the end users thumbs, the MX-6000

achieves a new standard in use and comfort.

Automatic Backlighting

The integral motion sensor detects any movement of the touch

screen and automatically backlights the screen. You do not have to

press any button to display the screen. Any movement of the MX-

6000 renews the backlighting. To adjust the backlighting, see page

11.

Programming the MX-6000

To fully automate an audio/video system and integrate two way

automation of servers etc. the programmer must have a detailed

knowledge of each component, LAN configuration, WiFi optimiza-

tion and how the system is connected and operated. Only a trained

and certified professional audio/video installer can install an MX-

6000 automation system in a timely and efficient manner.

Integrated Stylus

Stowed away in the top right hand corner storage slot, is a custom

made stylus for your convenience.

OCE-0026G(MX-6000)_REV04.QXD 2/22/11 10:17 AM Page 4

Page 5

MX-6000 TWO WAY TOUCH SCREEN

Connecting the Battery Pack

Unlock the rear cover by pressing down on the two locking tabs

and sliding the battery cover forward.

Remove the cover. For shipment from the factory, the battery is left

out of the MX-6000. Place the battery into the battery compart-

ment, making sure you align the contacts on the battery to the con-

tacts on the MX-6000. The battery will snap into place when

aligned properly.

Replace the cover and snap it into place.

Using the Charging Base

Plug the 6V DC adapter into a power outlet and into the back of

the charging base.

Gently place the MX-6000

into the cradle of the charging

base. It automatically aligns

itself to the contacts on the

charging base.

The Status light should imme-

diately light. Red indicates

that it is charging. Blue shows

that it is fully charged. There is

no harm in leaving the MX-

6000 on its charging base

whenever it is not in use.

Two Way via WiFi

To use the MX-6000 with any two way companion product, the

MX-6000 must be configured by your installer to be part of a LAN

(local area network) via a WiFi b/g access point or router. This is

not user configurable. If you have any questions, consult with your

custom installer.

Red indicates charging, Blue that the remote is fully

charged.

OCE-0026G(MX-6000)_REV04.QXD 2/22/11 10:17 AM Page 5

Page 6

MX-6000 TWO WAY TOUCH SCREEN

Optional RF “No Rules” Operation

In combination with an MSC-400 Master System Controller, or an

RF Base Station, the MX-6000 can control your system without

being in line-of-sight of the equipment.

The MSC-400 enhances the capabilities of the MX-6000 by storing

and issuing Smart Macros to your main system components. It is

triggered by RF Smart Macro commands via RF (radio frequency).

In addition, your MX-6000 can control components in secondary

rooms and systems via MRF-350 or MRF-260 RF base stations.

4. Self-adhesive “Flashers” affix to the

Infrared sensors on the front panels of

your components. Uniquely, all

Complete Control base stations can also

connect to components with rear panel

IR Inputs via adjustable IR Line

Outputs. The MSC-400 offers RS-232

control via rear panel connections as

well.

3. The MSC-400 can control IR, RS232 and Relay con-

trolled devices.

1. The MX-6000 sends radio

waves in every direction, so

you don’t have to point the

remote anymore!

2. The RFX-250 RF Sensor can be

freely positioned for optimal recep-

tion.

OCE-0026G(MX-6000)_REV04.QXD 2/22/11 10:17 AM Page 6

Page 7

MX-6000 TWO WAY TOUCH SCREEN

Operating Your System

The MX-6000’s main pages display the activities and devices in

your system. Press the main page button to see what your choices

are. Large systems may have more than one page. Press either of

the Page buttons if you don’t see all your devices.

Gently press any screen button with your finger to select an activi-

ty or a device. The screen will change to a display of the buttons

you need for that activity/device. The Page buttons may reveal

addi-

tional buttons for some devices and activities.

When you would like to control another device, press the main

page button and select a new device from the main page.

The Volume and

Mute buttons are

always available

regardless of what

screen is displayed.

The screen buttons are

labeled dynamically and

make commonly used func-

tions easy to find by feel.

The Page buttons

display additional

pages of controls.

The combination Scroll Wheel and 4

way cursor buttons enable you to both

scroll lists of artists, albums or songs

from your Music Server or to navigate

on screen guides and menus with ease.

Stylus

storage

slot

The main page but-

ton in the upper left

always displays the

main menu pages.

OCE-0026G(MX-6000)_REV04.QXD 2/22/11 10:17 AM Page 7

Page 8

MX-6000 TWO WAY TOUCH SCREEN

Using Two Way Personal Server Features

Step 1 – Insert an iPod into the PSX-1. The

Universal Remote Control screen appears on the

iPod. This means it’s connected to the dock and

ready for use with the MX-6000 remote control.

Step 2 – Select the dock you want to listen to

from the Main page of your MX-6000.

Step 3 – If the system has just been turned on, you may see the mes-

sage, “Connecting to iPod

Dock”. Once the MX-6000 has

connected to the iPod Dock, the

iPod menu screen appears. If the

iPod is already playing, the

“Now playing screen” appears.

Step 4 – When you browse for

new content, operate the MX-6000 as you would the iPod. Press the

Menu button, then place your thumb on the scroll wheel and rotate

to navigate, then press the “OK” button to make your selection. The

iPod Now Playing Screen appears after a selection is made.

Rotate the Scroll wheel

to navigate.

Press the Menu button

to display iPod menus.

Press the OK button

to select content.

OCE-0026G(MX-6000)_REV04.QXD 2/22/11 10:17 AM Page 8

Page 9

MX-6000 TWO WAY TOUCH SCREEN

Shortcuts:

The “Shortcuts” button makes nav-

igating your iPod easier than ever

before. Touch any button to jump

directly to that menu. Example:

Touch the “Artists” button to jump

directly to the Artists menu.

Shuffle:

The “Shuffle” button opens an

expanded menu of shuffle

options. Touch any of the choices

to enjoy your music in a

random order.

Your unique personal server features are accessed from the left side

of the screen of your MX-6000. Simply tap the feature you want:

Shortcuts to finding playlists,

albums, artists, etc. without

using the Menu button.

Shuffle exactly what you

want (this album, this artist,

this genre, etc.)

More from this artist, this

album, this genre, even this

composer...

Jukebox lets you build and

manage your own playlist

without accessing your PC.

OCE-0026G(MX-6000)_REV04.QXD 2/22/11 10:17 AM Page 9

Page 10

MX-6000 TWO WAY TOUCH SCREEN

Using the Alpha Search Feature:

The “search” button appears in

the upper right whenever you are

looking at a Menu or Jukebox

screen. Once you click on Search,

an alphabetical keyboard appears.

Simply type in what you’d like to

search for and touch “Go”.

The 1, 2, 3 icon opens the numeric keypad screen.

The qwerty keyboard icon toggles between a qwerty style key-

board and a simple a,b,c keyboard.

The “Go Back” icon takes you back to the menu screen.

Play More From:

The ”Play More From” button

opens up a menu of choices to

add to your current selection. By

touching the “More from this

Artist” button, all the additional

songs, from the current Artist, will

be added to the song queue.

Jukebox:

The “Jukebox” button opens a

menu of choices allowing you to

create a jukebox playlist in real

time. Touch the “add song to

Jukebox” icon or “add album to

jukebox” to add the currently

playing song or album to the

jukebox. To play the jukebox, touch the “play jukebox” icon. To edit

the jukebox, touch the “view jukebox” icon. Note: the Jukebox

playlist is cleared when the iPod is replaced or in the event of a

power failure.

Edit Jukebox:

Songs can be moved up,

down or deleted from the jukebox

list by using the control keys on

the right of the “view jukebox”

screen. To exit from the “View

Jukebox” screen, touch either the”

Go Back” button or the “Now

Playing” icon.

OCE-0026G(MX-6000)_REV04.QXD 2/22/11 10:17 AM Page 10

Andere Handbücher für MX-6000 -

Inhaltsverzeichnis

Andere Universal Remote Control Fernbedienung Handbücher

Universal Remote Control

Universal Remote Control Easy Clicker UR2-211 Bedienungsanleitung

Universal Remote Control

Universal Remote Control UR3-SR Bedienungsanleitung

Universal Remote Control

Universal Remote Control INSIGHT M2067BX3 Bedienungsanleitung

Universal Remote Control

Universal Remote Control Easy Clicker UR2-211 Bedienungsanleitung

Universal Remote Control

Universal Remote Control UR5U-8520 Bedienungsanleitung

Universal Remote Control

Universal Remote Control CABLEVISION UR2-CBL-CV04 Bedienungsanleitung

Universal Remote Control

Universal Remote Control UR4U-MDVR2 Bedienungsanleitung

Universal Remote Control

Universal Remote Control RF10 MASTERCONTROL Bedienungsanleitung

Universal Remote Control

Universal Remote Control CLIKR-5 UR5U-8500 Bedienungsanleitung

Universal Remote Control

Universal Remote Control PHAZR-5 Bedienungsanleitung

Universal Remote Control

Universal Remote Control MX-500TM Bedienungsanleitung

Universal Remote Control

Universal Remote Control CLIKR-5 UR5U-8500 Bedienungsanleitung

Universal Remote Control

Universal Remote Control R7 - SPECS SHEET Bedienungsanleitung

Universal Remote Control

Universal Remote Control Easy Clicker UR3-SR3 Bedienungsanleitung

Universal Remote Control

Universal Remote Control Complete Control MX-980 Betriebsanleitung

Universal Remote Control

Universal Remote Control UR2-DTA Bedienungsanleitung

Universal Remote Control

Universal Remote Control Easy Clicker UR2-211 Bedienungsanleitung

Universal Remote Control

Universal Remote Control URC-SR3 Bedienungsanleitung

Universal Remote Control

Universal Remote Control Easy Clicker UR3L-SR4 Bedienungsanleitung

Universal Remote Control

Universal Remote Control CLIKR-5 UR5U-8800L Bedienungsanleitung

Universal Remote Control

Universal Remote Control 8 IN 1 Bedienungsanleitung

Universal Remote Control

Universal Remote Control UCR22B-7 Bedienungsanleitung

Universal Remote Control

Universal Remote Control UR5L-9000L Bedienungsanleitung

Universal Remote Control

Universal Remote Control Easy Clicker UR3-SR3 Bedienungsanleitung

Beliebte Fernbedienung Handbücher anderer Marken

Panasonic

Panasonic EUR7622KB0 Bedienungsanleitung

Bang & Olufsen

Bang & Olufsen Beo4 Bedienungsanleitung

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Bedienungsanleitung

Multiplex

Multiplex PROFI TX 9 Bedienungsanleitung

One Remote

One Remote RMB4 Bedienungsanleitung

FUTABA

FUTABA 9ZAP - PART2 Bedienungsanleitung

HR Matic

HR Matic HR MULTI 3 Bedienungsanleitung

Yamaha

Yamaha ACC-GNRST-30-20 Bedienungsanleitung

EisSound

EisSound KBSOUND Bedienungsanleitung

Marantz

Marantz RC101 Bedienungsanleitung

Conrad

Conrad FS20 TC6 Bedienungsanleitung

Anritsu

Anritsu MP1777A Bedienungsanleitung

Niles

Niles WVC100 Fehlerbehebungshandbuch

RCA

RCA RCU1300 Bedienungsanleitung

Bang & Olufsen

Bang & Olufsen BEO6 Bedienungsanleitung

GE 94901 Bedienungsanleitung

Onbon

Onbon YQ1-75 Bedienungsanleitung

FUTABA

FUTABA R7108SB Montageanleitung
