Urban Barn 215511 Bedienungsanleitung

USE AND CARE GUIDE

KILLIAN FLOOR LAMP #215511

Table of Contents

Safety Information ....................................................................................................................................... 2

Pre-Installation ............................................................................................................................................ 3

Planning Installation ............................................................................................................................. 3

Package Contents .................................................................................................................................. 3

Assembly ..............................................................................................................................................4, 5, 6

Care and Cleaning ....................................................................................................................................... 7

Troubleshooting ........................................................................................................................................... 7

Safety Information

Consult a qualified electrician with any

electrical questions you may have.

Pre-Installation

PLANNING INSTALLATION

Read all instructions before assembly.

To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet

or cardboard. Inspect each part for defects that may have occurred during shipping.

Keep your receipt and these instructions for proof of purchase.

PACKAGE CONTENTS

LED bulb

Socket ring

Arm assembly

DGlass shade

Part Description Quantity

FPole-A 1

NOTE: This lamp requires the use of one 120V, 60Hz, 6-Watt Edison LED bulb (included)

or one 120V, 60Hz, 100-Watt max, medium-base type A bulb (not included).

Do not exceed the recommended wattage.

Pole-B

Pole-C

Base

IPole-D

Part Description Quantity

KWrench 1

C Acrylic spacer 1

Assembly instructions

1. Unpack the lamp & assemble poles (I &H)

Carefully organize and place all parts on a

smooth, flat surface. line up all of the parts

according to the assembly diagram.

Screw the pole-d (I) to top of the base (J).

Screw the pole-c (H) to top of the pole-d (I).

2. Assemble the poles (G & F)

Screw the pole-b (G) to top of the pole-c (H).

Screw the pole-a (F) to top of the pole-b (G).

Assembly instructions (continued)

3. Assemble the arm assembly

Pull the excess power cord through

the base (J).

Screw the arm assembly (E) to top

of the pole-a (F).

IMPORTANT NOTE: Please make sure the

arm and socket face front as shown, if the

arm and socket are not face front, adjust the

arm and socket face front as shown, and then

use the wrench (K) (included) to tighten the

nut from bottom of the base (J).

4. Assemble the glass shade

Remove the socket rings (B) and acrylic

spacers (C) from sockets by unscrewing the

socket rings (B).

Place a glass shade (D) over each socket, then

secure with a acrylic spacer (C) and a socket

ring (B).

Arm

Socket

5. Install the bulb

Prior to installing the bulb, inspect socket for silica packet. If packet is present,

then remove and throw away. Do not expose it to children or pets.

Install one 120V, 60Hz, 6-Watt Edison LED bulb (A) (included) or one 120V,

60Hz, 100-Watt max, medium-base type A bulb (not included) into the socket of

the light lamp.

Plug cord into an outlet and turn on at the switch.

Assembly instructions (continued)

Switch

Socket

Care and Cleaning

Clean the lamp with a soft, dry cloth. Do not use any cleaners with chemicals, solvents, or harsh abrasives.

Troubleshooting

Possible Cause

The bulb is burned out.

The power is off.

The circuit breaker is off.

There is an exposed wire.

There are too many items on

one circuit.

Discontinue use of the lamp.

Unplug other items on the circuit.

Ensure that the circuit breaker

is set in the on position.

Ensure that the power supply

is turned on.

Replace the light bulb.

Solution

The bulb will not light.

The fuse blows or a

circuit breaker trips when

the light is turned on.

Problem

Did not insert plug into power

outlet.

Ensure that the plug is fully and

properly inserted into the power

outlet.

Important safety instructions

This portable lamp has a polarized plug (one blade is wider than the other) as a feature to reduce the risk

of electric shock. This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the

outlet, reverse the plug. If it still does not fit, contact a qualified electrician. never use with an extension cord

unless plug can be fully inserted. Do not alter the plug.
