INSTALLATION MANUAL

RECESSED HANGING EMERGENCY EXIT LIGHT

VT-521

SAFETY:

• Installaon of this luminaire should only be carried out by a qualiﬁed electrician or

competent person to the current IEE Wiring Regulaons (BS7671)

• Please isolate mains prior to installaon/maintenance

• Check the total load on the circuit, including when this luminaire is ﬁed, does not

exceed the rang of the circuit cable, fuse or circuit breaker

• Please note the IP (Ingress of Protecon) rang of this luminaire when deciding the

locaon for Installaon

• This product is Class II double insulated

• This product is non-dimmable

INSTALLATION:

• Provide power to the required point of installaon,

• Cut a suitable aperture in the ceiling as per the cut-out details in Fig 1 ensuring that it

does not infringe with electrical cables, water/gas pipes or ceiling joists

• Connect the baery to the inverter via the plug and socket provided

• Connect the live and neutral to the push ﬁt terminals on the PCB of the inverter (Fig 3)

• Remove 2 screws on top of the ﬁng (see Fig 2)

Fig1

Fig2

Remove screws

Cable entry point

WARNING:

• This product must be disconnected from the circuit if subjected to any high voltage or

insulaon resistance tesng. Irreparable damage will occur if this instrucon is not

followed

• Recommended roune test procedure in accordance with BS5266

• Daily check – check that the status GREEN LED indicator is illuminated

• Monthly funconal test – simulate a mains supply failure for approx. 30 secs by

operaon of key switch or switching oﬀ a circuit breaker. Ensure normal supply is

restored aer test and the indicator status LED is illuminated

• Twice yearly conduct a one hour duraon test - simulate a mains supply failure for one

hour connuous test by operaon of key switch or switching oﬀ circuit breaker. Ensure

normal supply is restored aer test and the indicator status LED is illuminated

• Annual full three hour duraon test - conduct a three hour connuous duraon test.

Simulate a mains supply failure for three hour connuous test by operaon of key switch

or switching oﬀ circuit breaker. Ensure normal supply is restored aer test and the

indicator status LED is illuminated

• If the luminaire fails any of the above tests, please contact a qualiﬁed electrician.

Fig 3

Live (brown)

Neutral (blue)

LS

N

L

L

GENERAL:

The LEDs ﬁed in this product are non-replaceable. The unit should be recycled in the

correct manner when it reaches the end of its life. Check local authories for where

facilies exist.

Clean with a so dry cloth only, do not use aggressive cleaning products or solvents

which may damage the ﬁng.

GUARANTEE

• This product is only guaranteed against defects in manufacture.

• The warranty is valid for two years from date of purchase.

• The warranty does not cover damage caused by improper installaon or abnormal wear

caused.

• The manufacturer does not warrant damage to surfaces resulng from improper

removal Or installaon.

In case of any query/issue with the product you can reach out to us at [email protected]
