Installation Instructions for the 4005-2B Street Light Package
1. Warning: Before attempting to install units, please ensure power to the outlet box
is off.
2. Carefully unpack and identify all parts, referring to the parts list included with your
package.
3. Use four bolts, four nuts, and four washers to install the base into the ground.
5. Firmly attach the outlet wire from the lamp fixture to the main power supply.
7. Install light bulb.
a. Note: the bulb must not exceed wattage specified on fixture label.
8. Replace lamp access cover or lamp glass cover, using the screws provided.
9. Turn on the power.
Disclaimer: All electrical connections must be in accordance with local codes or the
national electrical code. If you are unfamiliar with the installation method and the
connection of electrical wire, please contact a qualified, licensed electrician to assist
you.
View installation diagram on next page.
4. Install the post onto thebase.
6. Attach the fixture to the pole.
r �
SCREW
:B
