Venstar ColorTouch Bedienungsanleitung

Quick Start &

Setup Guide

Thank You

Congratulations and thank you for purchasing

your new Venstar ColorTouch Wi-Fi thermostat.

This guide is intended to help you install and

setup the basic features of the ColorTouch

Thermostat. For a full owners manual and

installation guide, visit venstar.com. There you

will also ﬁnd installation and setup videos along

with videos highlighting many features of the

ColorTouch thermostat. The videos can be

found in the Venstar TV video series area.

Compatibility

Venstar ColorTouch® Wi-Fi Thermostat is designed to work with 24V

systems requiring both the R & C wires. This includes gas, electric, oil,

forced air, variable speed, heat pump and radiant heat. It can control:

•Heating:one,twoandthreestages(W1,W2,W3)

•Cooling:oneandtwostages(Y1,Y2)

•Heatpump:withauxiliaryandemergencyheat(Y,W1,O/B)

•Fan(G)

•Power(C,R)

•Humidiﬁerordehumidiﬁer(HUM,DEHUM)

•Dualfuelsystems(heatpumpwithfurnace)

•Whole-homehumidiﬁersanddehumidiﬁers

WiFi Network

& Password

Screw Driver Pencil

Leve

liers

Hammer or Drill

(3/16" or 7/ 32" drill bits)

Thermostat Thermostat

Base

Drywall Anchors

and Screws

This Quick Start

Manual

W3/AUX

W1/O/B

SENSOR

Contents

Necessary Tools

Step 1 - PowerOCurrentSystem

1) Gotoyourhome’scircuitbreakerpanel

and switch the furnace and air conditioner

breakerso.

2) Toconﬁrmpoweriso,adjustthe

temperature on your current thermostat.

If the system does not respond

accordingly, power has probably been

successfullyshuto.

WARNING: Failure to follow this step can result in personal

injuryand/ordeathfromshockandelectrocution.

Step 2 - Remove Faceplate

Removethefaceplateofcurrentsystem.Mostfaceplatessnap-oor

feature small screws that will need to be removed.

Side View

Wall Thermostat

WARNING: If you see large thick

electrical wires, wire nuts, or if your

systemislabeled120Vor240VDO

NOTPROCEED.THISTHERMOSTAT

ISNOTCOMPATIBLEWITHTHESE

SYSTEMS

WARNING: Failure to follow this step

canresultinpersonalinjuryand/or

death from shock and electrocution.

Step 3 - Beforeyougoanyfurther

Determine what your existing wiring and equipment situation is

before you disconnect any wires. If you are unsure of what type of

system you have, you may need to seek professional support.

A. IfyouhaveaHeating only systemwithoutAirConditioning,the

VenstarColorTouchthermostatwillrequire3wires.These3wires

are:R(24Vac),C(24Vac)andW(Heat).MostHeatingonlysystems

useverysimplethermostatsthatonlyrequire2wirestheR(24Vac)

andW(Heat).TheColorTouchthermostatrequires3wirestothe

thermostat.InthiscaseanAdd-A-Wireaccessorywillnotwork

anditwillbenecessarytoinstallanotherwirefortheC(24Vac)

connection.

B. Ifyouhaveasingle stage fossil fuel heater with air conditioning,

the Venstar ColorTouch will require 5 wires for independent fan

control.TheyareR(24Vac),C(24Vac),W(Heat),Y(Cooling),andG

(Fan).Youmayconnectonly4 wires, as instructed below, to the

ColorTouch but will give up independent fan control. The fan will

stilloperatewithaHeatingorCoolingdemand.

• If there are only 4 wires present that are connected to the existing

thermostat, there are at least 3 options available to connect the

Venstar ColorTouch thermostat, they are:

1. Usethe4wiresasinstructedbelowandnotethatthefanwill

onlyoperatewithaHeatingorCoolingdemand.

2. PullnewthermostatwirefromtheHVACequipmenttothe

thermostat so that there are at least 5 wires available.

3. PurchaseandinstallaVenstarAdd-A-Wireaccessory

(ACC-0410).

C. If you have a multi stage HVAC system comprised of a fossil fuel

heater with air conditioning the Venstar ColorTouch will require

the5wiresmentionedabove(R,C,W,Y,andG)plusanadditional

wireforeachadditionalstageofHeatingorCooling.Youmay

reduce the 5 wire requirement to 4 if you give up independent fan

control,orusetheoptionalaccessory;Add-A-Wire.

D. Ifyouhaveaheat pump without aux heat the Venstar ColorTouch

willrequire5wires:R(24Vac),C(24Vac),W1/O/B(reversingvalve),

Y(1ststagecompressor),andG(fan).Ifthereareonly4wires

presentthatareconnectedtotheexistingthermostat,thereare

atleast3optionsavailabletoconnecttheVenstarColorTouch

thermostat, they are:

1. Usethe4wiresasinstructedbelowandnotethatthefanwill

onlyoperatewithaHeatingorCoolingdemand.

2. PullnewthermostatwirefromtheHVACequipmenttothe

thermostat so that there are at least 5 wires available.

3. PurchaseandinstallaVenstarAdd-A-Wireaccessory(ACC-0410).

E. Ifyouhaveaheat pump with aux heat the Venstar ColorTouch will

require6wires:R(24Vac),C(24Vac),W1/O/B(reversingvalve),Y(1st

stagecompressor),W2(AuxHeat)andG(fan).Ifthereareonly5

wirespresentthatareconnectedtotheexistingthermostat,there

areatleast3optionsavailabletoconnecttheVenstarColorTouch

thermostat, they are:

1. Usethe5wiresasinstructedbelowandnotethatthefanwill

onlyoperatewithaHeatingorCoolingdemand.

2. PullnewthermostatwirefromtheHVACequipmenttothe

thermostat so that there are at least 6 wires available.

3. PurchaseandinstallaVenstarAdd-A-Wireaccessory(ACC-0410).

MAKING 4 WIRES WORK when 5 are required

(without the optional Add-A-Wire accessory)

• If you have an all-electric heat system with air conditioning, this

method is not an option. You must either pull new wire or use the

optional Add-A-Wire accessory (ACC-0410).

• If you have a single stage fossil fuel heater with air conditioning,

and you would like install the Venstar ColorTouch using only 4 wires,

follow the directions below. You will need a screwdriver along with a

3” or 4” long piece of thermostat wire to use as a jumper.

1. Makesurethepowerisoasstep1onpage4instructsyou.

2. Followstep4onpage9“LabelandDisconnectWires”atthe

thermostat.Pleasenotethecolorandthecorrespondingwire

designatorwitheachcolor.AnexampleistheRwireisredandthe

Wwireiswhiteandsoon.Youwillneedthisforthenextstepat

theHVACequipment.

3. Attheequipmentendofthethermostatwires,locatethe

terminals that the wires are attached to.

 A. Removethe“Gwire”fromtheterminalmarkedG.

 B. Placethe“Gwire”onterminalC.

 C. PlaceoneendofthejumperonterminalG.

 D. PlacetheotherendofthejumperonterminalY.

  Pleasenotethattherewillbemorethan1wireonterminalY.

4. Connect the wires to the terminals on the ColorTouch backplate

takingcaretomakesurethateachwirefromtheHVACequipment

is connected to the same terminal designation on the ColorTouch

backplate.Forexample:the“Cwire”fromtheHVACequipment

shouldbeconnectedtothe“C”terminalofthethermostat.The

“R”wireontheequipmentterminalshouldbeconnectedtothe

“R”terminalontheColorTouchbackplate,andsoon.

MAKING 5 WIRES WORK when 6 are required

(without the optional Add-A-Wire accessory)

• If you have an all-electric heat system with air conditioning, this

method is not an option. You must either pull new wire or use the

optional Add-A-Wire accessory (ACC-0410).

• If you have a multi stage system that requires 6 wires, and you

would like install the Venstar ColorTouch using only 5 wires, follow

the directions below. You will need a screwdriver along with a 3” or

4” long piece of thermostat wire to use as a jumper.

1. Makesurethepowerisoasstep1onpage6instructsyou.

2. Followstep4onpage9“LabelandDisconnectWires”atthe

thermostat.Pleasenotethecolorandthecorrespondingwire

designatorwitheachcolor.AnexampleistheRwireisredandthe

Wwireiswhiteandsoon.Youwillneedthisforthenextstepat

theHVACequipment.

3. Attheequipmentendofthethermostatwires,locatethe

terminals that the wires are attached to.

 A. Removethe“Gwire”fromtheterminalmarkedG.

 B. Placethe“Gwire”onterminalC.

 C. PlaceoneendofthejumperonterminalG.

 D. PlacetheotherendofthejumperonterminalY.

  Pleasenotethattherewillbemorethan1wireonterminalY.

E. ConnectthewirestotheterminalsontheColorTouch

backplate taking care to make sure that each wire from the

HVACequipmentisconnectedtothesameterminalonthe

ColorTouchbackplate.Forexample:the“Cwire”fromthe

HVACequipmentisconnectedtothe“C”terminalofthe

thermostat and so on.

Step 4 - Label&DisconnectWires

1) Onebyone,applyalabel

designated to each wire

you disconnect from

your current thermostat.

TIP:Beforedisconnectinganywires,

take a photo of your current wire

conﬁguration with your mobile device.

Wire from the Install on the

old thermostat Function new thermostat Wire

terminal marked connector marked Color

 GorF Fan G

 Y1,Y Cooling/Compressor Y1

 W1,W Heating W1/0/B

 Rh,R,M,Vr,A Power R

C Common C

 O/B Rev.Valve W1/O/B*

 W2 2ndStageHeat W2

 Y2 2ndStageCooling Y2

 W3 3rdStageHeat W3

 OUT- OutdoorSensor SENSOR

 OUT+ OutdoorSensor SENSOR

*O/BisusedifyoursystemisaHeatPump.

NOTE:Iftheterminaldesignationsonyouroldthermostatdonotmatch

those on the new thermostat refer to sample wiring diagrams in the

full user’s manual at venstar.com in the support section.
