Carbon Mobile 5

Quick Start Guide

Getting started

Device will power up

Your terminal will start up and load

the Payment screen. If your device

connects via mobile data with a

SIM, you’re good to go! You can

start processing transactions. If

not, you will need to connect your

device to Wi-Fi

Turn your device on

Press and hold the power button

Connect to Wi-Fi

Swipe down from the Notication

bar at the top of the screen and

tap and hold the Wi-Fi icon

Find your network

Select your network from the

available networks list

Set up your

passcodes

For your security, the refund

functionality on your CM5 is

protected by passcodes. To set up

your passcodes, call our Technical

Helpdesk on 0800 EFTPOS

(0800 338 767, option 2).

NOTE: You must be the listed

authority on your Eftpos NZ

account to set up passcodes.

Enter your password

Enter your Wi-Fi password and tap

‘CONNECT’. Press the O button

in the bottom Navigation bar to

navigate back to the Payment

screen

Process a transaction

Your customer presents their card

Enter the purchase

amount and select Purchase

Terminal will display

Approved or Declined

Select Print to print a second

receipt, or No Thanks to continue

Need help?

Scan the QR code below or visit

support.eftpos.co.nz/cm5-guide

for the full CM5 user guide

Get to know your Carbon Mobile 5 (CM5)

Card swipe

Card insert

Paper roll cover

USB-C charging port Headphone jack

Contactless card reading area

Notication bar

Accessibility mode button

Volume buttons

Power / Sleep button

Wake and

unlock the CM5

To save power, your CM5 goes

into sleep mode when you are

not using it. It will also lock after

6 hours of inactivity.

To wake the CM5

Press Power button

To unlock the CM5

Press Power button

and swipe up on

the screen

The Notication

bar at the top of

the screen displays

status icons on

the right side and

notication alerts on

the left. Swipe down

from the Notication

bar to see notication

cards and the Quick

Settings panel.

STATUS ICONS

Bluetooth

Aeroplane mode

Cellular signal

Wi-Fi

SIM card

Battery level

Battery charging

NAVIGATION KEYS

Back

Payment screen

Recent items

More options

Expand

Collapse

Icons on

the CM5

NOTIFICATION ICONS

Warning / attention

Important information

Download / update

in-progress

QUICK SETTINGS ICONS

App launcher

Torch

Auto rotate

Edit

Settings

Changing your paper roll

Remove used paper roll.

Insert new roll so the paper

feeds from the top, leaving

a length of paper sticking

out of the terminal

Open paper roll cover as

shown above. There are

small slots to aid opening if

required

Close the printer door, pressing

down gently until it clicks shut

Order more paper rolls online at

eftpos.co.nz/shop

Using the Charging Base

• Plug the power cable into the port on the side of the CM5 charging base

• Plug the power cable into a wall socket

• Place the CM5 on the charging base

• Look for this icon to make sure your CM5 is charging

Charging the Carbon Mobile 5
