Draft
www.verifone.com
V400m Terminal & Base
Installation Guide
DOC475-003-EN-A, Revision A02.1
Draft
Installation Guide V400m
2
© VeriFone Inc. All rights reserved.
V400m Terminal & Base Installation Guide
© 2023 VeriFone, Inc.
All rights reserved. No part of the contents of this document may be reproduced or transmitted in any
form without the written permission of VeriFone, Inc.
The information contained in this document is subject to change without notice. Although Verifone has
attempted to ensure the accuracy of the contents of this document, this document may include errors or
omissions. The examples and sample programs are for illustration only and may not be suited for your
purpose. You should verify the applicability of any example or sample program before placing the
software into productive use. This document, including without limitation the examples and software
programs, is supplied “As-Is.”
Verifone and the Verifone logo are registered trademarks of Verifone. Other brand names or trademarks
associated with Verifone’s products and services are trademarks of VeriFone, Inc.
All other brand names and trademarks appearing in this manual are the property of their respective
holders.
Comments? Please e-mail all comments on this document to your local Verifone Support Team.
VeriFone, Inc
1-800-Verifone
www.verifone.com
Verifone Part Number DOC475-003-EN-A, Revision A02.1
Draft
Installation Guide V400m
3
© VeriFone Inc. All rights reserved.
Contents
Preface 7
Audience 7
Organization 7
Related Documentation 8
Conventions and Acronyms 8
1. Device Overview 11
Front Functions 12
Back Functions 12
V400m Bases 13
V400m Charging Base 13
V400m Full-Feature Base 13
Features and Benets 14
Ease of Use 14
Critical Security Protection 15
2. Setup 16
Selecting Location 16
Environmental Factors 17
Electrical Considerations 17
Contactless Considerations 18
PIN Protection Measures 18
Unpacking Shipping Carton 18
Installing MSAM, SIM and Micro SD Cards 19
Accessing Card Compartments 20
Draft
Installation Guide V400m
4
© VeriFone Inc. All rights reserved.
Changing or Installing an MSAM Card 21
Changing or Installing a SIM Card 21
Changing or Installing a Micro SD Card 23
Loading Printer Paper 24
Power Supply 25
Cable Connections 26
Cable Connections Using the Full-Feature Base 26
Smart Card Reader 28
Conducting a Smart Card Transaction 28
Magnetic Stripe Card Reader Use 29
Conducting a Credit/Debit Card Transaction 30
Contactless Transaction 30
Performing Contactless Transactions 31
Optional Accessories 31
FF Base 31
Charging Base 32
Periodic Inspection 32
3. Specications 33
V400m Terminal 33
Unit Power Requirements 33
Temperature 33
Humidity 33
External Dimensions 33
Weight 34
Processor 34
Memory 34
SD Memory 34
Security 34
Draft
Installation Guide V400m
5
© VeriFone Inc. All rights reserved.
Display 34
SAM Card Reader 34
CTLS Reader 34
Magnetic Card Reader 35
Primary Smart Card 35
Speaker 35
Communication 35
Battery Pack 36
Power Pack 36
Integrated Printer 36
Security 37
V400m Bases 37
Unit Power Requirements 37
Temperature 37
Humidity 37
Communication 37
Security 38
4. Troubleshooting Guidelines 39
Display Panel Does Not Work 40
Keypad Does Not Respond 40
Transactions Fail to Process 40
5. Service and Support 42
Maintenance and Cleaning 42
Service Returns 43
Accessories and Documentation 46
Cables 46
Base 46
Draft
Installation Guide V400m
7
© VeriFone Inc. All rights reserved.
Preface
This guide is the primary source of information for setting up and installing the V400m and V400m
Bases.
Audience
This guide provides simple descriptions of the product features and information for installing and
conguring V400m terminals and the V400m Charging and Full-Function Bases.
Organization
This guide is organized as follows:
•Chapter 1, Device Overview. Provides an overview of the V400m device.
•Chapter 2, Setup. Explains how to set up and install the V400m and establish connections with other
devices.
•Chapter 3, Specications. Discusses the power requirements and dimensions of V400m.
•Chapter 4, Troubleshooting Guidelines Provides troubleshooting tips.
•Chapter 5, Service and Support Provides information on contacting your Verifone service provider,
ordering accessories or documentation from Verifone, and maintaining the V400m unit.
•Appendix A, Caution and Warning Messages Shows the UL/cUL certication-compliant translations
of all Warning and Caution messages in this installation guide.
Draft
Installation Guide V400m
8
© VeriFone Inc. All rights reserved.
Related Documentation
To learn more about the V400m and V400m Bases, please refer to the following documents and their
associated Verifone Part Numbers (VPN):
•V400m Quick Installation Guide DOC475-002-EN
•V400m Reference Guide DOC475-004-EN
•V400m B-Charging Quick Installation Guide DOC475-006-EN
•V400m B-FF Quick Installation Guide DOC475-007-EN
•V400m Base C and FF Certications & Regulations Sheet DOC475-011-EN
•V400m Plus 4G Certications and Regulations DOC475-031-EN
Conventions and Acronyms
This section describes the conventions and acronyms used in this guide.
Various conventions are used to help you quickly identify special formatting. Table 1 describes these
conventions and provides examples of their use.
Table 1: Document Conventions
Convention
Meaning
Example
Blue
Text in blue indicates terms that
are cross referenced.
See Conventions and
Acronyms.
The light bulb icon is used to
highlight important information.
If exchanging cables use a
Verifone-approved cable.
Draft
Installation Guide V400m
9
© VeriFone Inc. All rights reserved.
The caution symbol indicates
possible hardware or software
failure, or loss of data.
Avoid placing metallic objects
at the front of the card reader
The lightning symbol is used as
a warning when bodily injury
might occur.
For safety, do not string cables
or cords across a walkway.
Various acronyms are used in place of the full denition. Table 2 presents acronyms and their denitions.
Table 2: Acronym Denitions
Acronym
Denitions
3DES
Triple Data Encryption Algorithm
AC
Alternating Current
ANSI
American National Standards Institute
cUL
Underwriters' Laboratories of Canada
DC
Direct Current
DUKPT
Derived Unique Key Per Transaction Method as dened in the
VISA’s POS Equipment Requirement: PIN processing and Data
Authentication, International Version 1.0, August 1988
ECR
Electronic Cash Register
EMV
Europay, MasterCard, and Visa
HSPA
High Speed Packet Access
ISO
International Organization for Standardization
Draft
Installation Guide V400m
10
© VeriFone Inc. All rights reserved.
MRA
Merchandise Return Authorization
MSAM
Multiple Secure Access Module
LAN
Local Area Network
LCD
Liquid Crystal Display
LED
Light-Emitting Diode
LTE
Long-Term Evolution
PED
PIN Entry Device
PIN
Personal Identication Number
POS
Point-of-Sale
RS-232
Recommend Standard number 232
SAM
Secure Access Module
SD
Secure Digital
UL
Underwriters Laboratories
USB
Universal Serial Bus
VPN
Verifone Part Number
