NetBackup 5330

Appliance overview

This chapter includes the following topics:

■About the NetBackup 5330 Appliance

■NetBackup 5330 Appliance system features

■About NetBackup 5330 Appliance storage shelves

■Best practices for rack installation

Chapter

About the NetBackup 5330 Appliance

Fibre channel (FC) cables connect the NetBackup 5330 Appliance compute node

to the Primary Storage Shelf. SAS cables connect the Primary Storage Shelf to the

Expansion Storage Shelf.

See “ NetBackup 5330 Appliance system features” on page 7.

NetBackup 5330 Appliance system features

Table 1-1 NetBackup 5330 Appliance system features

DescriptionFeature

Red Hat Enterprise Linux 7.4Operating system

7NetBackup 5330 Appliance overview

About the NetBackup 5330 Appliance

Table 1-1 NetBackup 5330 Appliance system features (continued)

DescriptionFeature

Processors

■Two Intel Xeon 10 core 2.80GHz E5-2680 v2 CPUs

Two Intel Xeon 10 core 3.00GHz E5-2690 v2 CPUs

■Supports high-performance processors with low-power

consumption.

■Provides high-capacity intra-appliance switching

bandwidth, along with high I/O throughput.

Performance

Up to 960 TiB (1,056 TB) for MSDP deduplication data

storage, and up to 1.374 PB for AdvancedDisk and Copilot

non-deduplicated data storage. The amount of MSDP or

AdvancedDisk/Copilot data storage you want to allocate

depends on the amount of storage that you purchase with

the NetBackup 5330 Appliance.

You can allocate the usable storage capacity in part or

completely to an MSDP deduplication pool, or to an

AdvancedDisk or Copilot non-deduplicated storage pool.

Note the following:

■Maximum usable storage capacity for an MSDP data

pool is 960 TiB (1,056 TB), even if the system supports

1.374 PBs of total usable storage capacity.

■Total usable storage capacity for an AdvancedDisk or

Copilot data can be up to 1.374 PB.

Note: Creating an MSDP deduplication pool may cause

the usable space that is available for the AdvancedDisk

or Copilot data pool to fluctuate. The amount of space

fluctuation depends on how much space the MSDP pool

uses.

Storage capacity

16 GB x 24; total RAM: 384 GBSystem memory configuration

(DIMMs)

24 GBRAID cache

The deduplication engine provides up to 100 times reduction

in storage. The client-side plug-in provides similar levels of

bandwidth reduction.

Space reduction

See “Available appliance storage options” on page 20.Scalable architecture

8NetBackup 5330 Appliance overview

NetBackup 5330 Appliance system features

Table 1-1 NetBackup 5330 Appliance system features (continued)

DescriptionFeature

Supports redundant hot-swappable disks and power

modules.

High availability

Provides separate out-of-band management network

interfaces. You can remotely turn on, turn off, and reset

appliances through the network.

Supports the SNMP traps and automatically reports alarms.

Reports disk information through the out-of-band

management channel.

Easy management

RAID1 (striping and mirroring) and RAID6 (block level

striping with double distributed parity) are used as follows:

■NetBackup 5330 compute node system disks: RAID1

■Storage shelf data storage disks: RAID6

RAID levels

The NetBackup 5330 compute node can be ordered with

two, three, five, or six Fibre Channel (FC) HBA cards

already installed. Each card includes two standard Fibre

Channel ports. If less than six FC HBA cards are ordered,

a 10 Gb Ethernet card with two standard ports can be

ordered. The compute node uses the QLE2562, a QLogic

8 Gb FC PCIe dual port adapter.

Fibre Channel support

One 1 Gb/s IPMI remote network port

One VGA port

Four 1 GbE network ports, with an RJ-45 connector, and

link and activity LEDs. Two of the ports are reserved for

private networks.

Two 10 GbE network ports, with Small Form-factor

Pluggable (SFP) modules, and link and activity LEDs.

See “About the NetBackup 5330 Appliance compute node

rear panel” on page 14.

Rear panel ports

See “NetBackup 5330 Appliance compute node disk drive configurations”

on page 11.

See “NetBackup 5330 Appliance compute node disk drive LED descriptions”

on page 12.

See “NetBackup 5330 Appliance compute node control panel information”

on page 13.

9NetBackup 5330 Appliance overview

NetBackup 5330 Appliance system features

See “About the NetBackup 5330 Appliance compute node rear panel” on page 14.

See “NetBackup 5330 Appliance compute node PCIe slot I/O configuration options”

on page 15.

See “NetBackup 5330 Appliance compute node Ethernet port configurations”

on page 17.

See “Dual-port 8 Gb Fibre Channel Host Bus Adapter (FC HBA) specifications”

on page 19.

Serial number locations

A vertical bar on the rear panel of the compute node contains the serial number.

The serial number of the storage shelves is located in two places.

■The front of the shelf contains the serial number, on the lower right-hand corner.

■The top of the storage shelf includes the serial number label, near the rear of

the unit. The number is outlined in red.

10NetBackup 5330 Appliance overview

NetBackup 5330 Appliance system features

Andere Handbücher für NetBackup 5330

Inhaltsverzeichnis

Andere VERITAS Netzwerkspeicherserver Handbücher

VERITAS

VERITAS 5350 Bedienungsanleitung

VERITAS

VERITAS 5U84 Handbuch

Beliebte Netzwerkspeicherserver Handbücher anderer Marken

HP NetStorage 6000 Bedienungsanleitung

Seagate

Seagate U10 ST320423A Bedienungsanleitung

Synology

Synology RackStation RS816 Handbuch

D-Link

D-Link ShareCenter Pro DNS-1200-05 Bedienungsanleitung

Avid Technology

Avid Technology VideoRAID ST Sicherheitsleitfaden

Western Digital

Western Digital My Cloud Home Duo Bedienungsanleitung

PrimeArray

PrimeArray 4xxx Bedienungsanleitung

Buffalo

Buffalo TeraStation WSS WSH5010N6 Bedienungsanleitung

Planex

Planex MZK-NAS01SG Bedienungsanleitung

Intel

Intel SS4000-E - Entry Storage System NAS Server Bedienungsanleitung

Synology

Synology RS2212+ Bedienungsanleitung

Allnet

Allnet ALL69000 Bedienungsanleitung

Adaptec

Adaptec 5325301580 Bedienungsanleitung

Motorola

Motorola EXORdisk II Bedienungsanleitung

Sony

Sony XDAAI1PK Bedienungsanleitung

Cisco

Cisco Linksys NAS200 Original Betriebsanleitung

Sans Digital

Sans Digital MR4UT6G Bedienungsanleitung

AIC

AIC FB128-LX Bedienungsanleitung
