Installation instructions

for contractors

VIESMANN

Vitocell 100-B

Type CVBA

Dual mode DHW cylinder 400/500 l

with Solar-Divicon

VITOCELL 100-B

5838690 GB 2/2019 Dispose after installation.

Please follow these safety instructions closely to

prevent accidents and material losses.

Safety instructions explained

Danger

This symbol warns against the risk of injury.

!Please note

This symbol warns against the risk of material

losses and environmental pollution.

Note

Details identified by the word "Note" contain additional

information.

Target group

These instructions are exclusively intended for quali-

fied contractors.

■Work on electrical equipment may only be carried

out by a qualified electrician.

Regulations to be observed

■National installation regulations

■Statutory regulations for the prevention of accidents

■Statutory regulations for environmental protection

■Codes of practice of the relevant trade associations

■Relevant country-specific safety regulations

Working on the system

■Isolate the system from the power supply (e.g. by

removing the separate fuse or by means of a mains

isolator) and check that it is no longer live.

■Safeguard the system against reconnection.

■Wear protective clothing.

!Please note

Electronic assemblies can be damaged by elec-

trostatic discharge.

Prior to commencing any work, touch earthed

objects such as heating or water pipes to dis-

charge static loads.

Danger

Hot surfaces can cause burns.

■Before maintenance and service work, switch

OFF the appliance and let it cool down.

■Never touch the hot surfaces of uninsulated

pipes and fittings.

Danger

Floors which are wet, damp or covered in fluids

containing glycol present a risk of injury through

slipping and falling.

■When carrying out installation and mainte-

nance work, ensure that the floor is kept clean

and dry.

■Wear non-slip shoes.

Danger

Breathing in or swallowing broken-off fragments

of insulating material may result in death by

asphyxiation.

■Do not allow children to play in the installation

room.

■Clean the installation room after installation

and maintenance work.

Repair work

!Please note

Repairing components that fulfil a safety func-

tion can compromise the safe operation of the

system.

Replace faulty components only with genuine

Viessmann spare parts.

Safety instructions

5838690

1. Information Disposal of packaging ............................................................................ 4

Symbols ................................................................................................. 4

Intended use .......................................................................................... 4

Product information ................................................................................ 5

■Vitocell 100-B, type CVBA ................................................................ 5

2. Installation information Product information ................................................................................ 6

■Connections ........................................................................................ 6

■Siting information ................................................................................ 6

3. Installation sequence Siting the DHW cylinder ......................................................................... 8

Fitting the Solar-Divicon and thermal insulation .................................... 8

■Removing the Solar-Divicon cover ..................................................... 8

■Fitting threaded studs and spacer sleeves ......................................... 9

■Fitting the thermal insulation jacket .................................................... 10

■Fitting the profile bracket .................................................................... 11

■Fitting the overflow pipe ...................................................................... 11

■Fitting the Solar-Divicon ..................................................................... 12

■Fitting the thermal insulation mat at the top ........................................ 12

■Route the cable. ................................................................................. 13

■Closing the thermal insulation ............................................................ 13

Connecting the immersion heater EHE ................................................. 15

Connecting the heating water side and solar side ................................. 15

■System scheme with solar collectors and boiler ................................. 16

Connections on the DHW side ............................................................... 17

■Safety valve ........................................................................................ 18

Install high limit safety cut-out (STB) ..................................................... 19

■Electrical connections ......................................................................... 19

■Setting the response temperature ...................................................... 20

■Reset high limit safety cut-out (STB) .................................................. 20

Connecting the equipotential bonding ................................................... 20

Commissioning ...................................................................................... 20

4. Specification ................................................................................................................ 21

Index

5838690

Please dispose of packaging waste in line with statu-

tory regulations.

Symbols

Symbol Meaning

Reference to other document containing

further information

Step in a diagram:

The numbers correspond to the order in

which the steps are carried out.

Warning of material losses and environ-

mental pollution

Live electrical area

Pay particular attention.

■Component must audibly click into place.

■Acoustic signal

■Fit new component.

■In conjunction with a tool: Clean the sur-

face.

Dispose of component correctly.

Dispose of component at a suitable collec-

tion point. Do not dispose of component in

domestic waste.

Intended use

The appliance is only intended to be installed and

operated in sealed unvented systems that comply with

EN 12828 / DIN 1988, or solar thermal systems that

comply with EN 12977, with due attention paid to the

associated installation, service and operating instruc-

tions. DHW cylinders are only designed to store and

heat water of potable water quality. Heating water buf-

fer cylinders are only designed to hold fill water of pot-

able water quality. Only operate solar collectors with

the heat transfer medium approved by the manufac-

turer.

Intended use presupposes that a fixed installation in

conjunction with permissible, system-specific compo-

nents has been carried out.

Commercial or industrial usage for a purpose other

than heating the building or DHW shall be deemed

inappropriate.

Any usage beyond this must be approved by the man-

ufacturer for the individual case.

Disposal of packaging

5838690

Incorrect usage or operation of the appliance (e.g. the

appliance being opened by the system user) is prohibi-

ted and results in an exclusion of liability.

Incorrect usage also occurs if the components in the

system are modified from their intended use (e.g.

through direct DHW heating in the collector).

Adhere to statutory regulations, especially concerning

the hygiene of potable water.

Product information

Vitocell 100-B, type CVBA

■Enamelled DHW cylinder with internal indirect coil for

heating domestic hot water in conjunction with the

following:

–Solar thermal systems

–Floorstanding boilers

–Wall mounted boilers

–Heat pumps for dual mode operation

–Additionally, the use of an immersion heater is pos-

sible.

■Capacity: 400 and 500 l

■Suitable for systems conforming to DIN 1988,

EN 12828 and DIN 4753

Intended use (cont.)

5838690

Connections

Fig. 1

AFemale connection for immersion heater

BDHW with high limit safety cut-out

CCylinder temperature sensor

DHeating water flow

EDHW circ.

FHeating water return

GConnection for thermometer sensor

HCold water/drain outlet

Siting information

!Please note

The thermal insulation must not be able to come

into contact with naked flames.

Exercise caution when welding and soldering.

!Please note

To prevent material losses, install the DHW cyl-

inder in a room free from draughts and risk of

frost.

When not in use, the DHW cylinder must be

drained if there is a risk of frost.

■Provide adequate clearance from the wall so that the

Vitosolic 100 can be operated (if installed).

■Use the adjustable feet to level the DHW cylinder.

Note

Never extend the adjustable feet beyond a total

length of 35 mm.

Product information

5838690

Installation dimensions

Fig. 2

a Wall clearance

AFemale connection for immersion heater

650

260

310

(200) (150)

(150)

Fig. 3

Immersion heater installation instructions

Maintain the minimum clearance.

Note

The unheated length of any threaded immersion

heater installed on site must be at least 100 mm.

The threaded immersion heater must be suitable for

installation in enamelled DHW cylinders.

Product information (cont.)

5838690

Level the cylinder and fit the thermal insulation mat at

the bottom.

Fig. 4

ABag with type plate

Note

If no immersion heater is installed, seal the front

female connection with the plug supplied.

Fitting the Solar-Divicon and thermal insulation

Removing the Solar-Divicon cover

Fig. 5

Siting the DHW cylinder

5838690

Fitting threaded studs and spacer sleeves

Fig. 6

1. Screw in threaded studs by hand as far as they will

go.

2. Slide on spacer sleeves.

Fitting the Solar-Divicon and thermal insulation (cont.)

5838690

Fitting the thermal insulation jacket

Fig. 7

Note

■2 people are required for the following work.

■Ensure that no fleece remnants enter the DHW cylin-

der through the cylinder connections.

1. At the back of the cylinder: Attach 6 clip fasteners

to the edges of the right and left sections of the

thermal insulation jacket. Place the thermal insula-

tion jacket around the cylinder body.

Note

Leave the clip fasteners in the first notch.

2. At the front of the cylinder: Attach 5 clip fasteners

to the edges of the right and left sections of the

thermal insulation jacket. 3 clip fasteners at the

top, 2 at the bottom. Leave space for the Solar-Div-

icon.

3. Fit the thermal insulation jacket evenly around the

cylinder body by patting it.

4. Push the clip fasteners at the front of the cylinder

as close together as possible.

5. Push the clip fasteners at the back of the cylinder

as close together as possible.

Fitting the Solar-Divicon and thermal insulation (cont.)

5838690

Andere Handbücher für VITOCELL 100-B

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Viessmann Kessel Handbücher

Viessmann

Viessmann VITODENS 200 WB2A Versionshinweis

Viessmann

Viessmann Vitomax LW M64 Series Bedienungsanleitung

Viessmann

Viessmann Vitodens 200-W System Betriebsanleitung

Viessmann

Viessmann Vitodens 222-F Kurzanleitung

Viessmann

Viessmann Vitocell 200 Cylinder Benutzerhandbuch

Viessmann

Viessmann Vitodens 222-F Bedienungsanleitung

Viessmann

Viessmann Vitodens 100-W Kurzanleitung

Viessmann

Viessmann VITODENS 300 WB3A Betriebsanleitung

Viessmann

Viessmann Vitodens 200-W System Kurzanleitung

Viessmann

Viessmann Vitodens 100-W Kurzanleitung

Viessmann

Viessmann Vitorondens 200-T Series Bedienungsanleitung

Viessmann

Viessmann Vitodens 200-W System Kurzanleitung

Viessmann

Viessmann Vitodens 300 Betriebsanleitung

Viessmann

Viessmann VITOCELL 100-VH Gebrauchsanweisung

Viessmann

Viessmann VITOCELL 300B Betriebsanleitung

Viessmann

Viessmann Vitodens 200-W System Bedienungsanleitung

Viessmann

Viessmann VITOCROSSAL 300 Bedienungsanleitung

Viessmann

Viessmann Vitoflex 300-UF 530 Bedienungsanleitung

Viessmann

Viessmann Vitodens 100-W B1HF Series Kurzanleitung

Viessmann

Viessmann Vitodens 100-W Bedienungsanleitung

Viessmann

Viessmann Vitogas 100 GS1 Series Bedienungsanleitung

Viessmann

Viessmann VITOCROSSAL CRU 800 kW Betriebsanleitung

Viessmann

Viessmann VITODENS 200 Bedienungsanleitung

Viessmann

Viessmann VITOMAX 200-HW Bedienungsanleitung

Beliebte Kessel Handbücher anderer Marken

Vaillant

Vaillant uniSTOR VIH SW GB 500 BES Bedienungsanleitung

Radijator

Radijator BIO max 23.1 Bedienungsanleitung

Brunner

Brunner BSV 20 Bedienungsanleitung

Buderus

Buderus Logamax GB062-24 KDE H V2 Bedienungsanleitung

Potterton

Potterton 50e Datenblatt

UTICA BOILERS

UTICA BOILERS TriFire Bedienungsanleitung

Joannes

Joannes LADY Series Handbuch

ECR International

ECR International UB90-125 Gebrauchsanweisung

Froling

Froling FHG Turbo 3000 Bedienungsanleitung

Froling

Froling P4 Pellet 8 - 105 Bedienungsanleitung

U.S. Boiler Company

U.S. Boiler Company K2 Bedienungsanleitung

Henrad

Henrad C95 FF Bedienungsanleitung

NeOvo

NeOvo EcoNox EF 36 Bedienungsanleitung

Potterton

Potterton PROMAX SL 12 Bedienungsanleitung

Eco Hometec

Eco Hometec EC 25 COMPACT Bedienungsanleitung

Baxi

Baxi Prime 1.24 Bedienungsanleitung

REXNOVA

REXNOVA ISA 20 BITHERMAL Bedienungsanleitung

Radiant

Radiant R2K 55 Handbuch
