Installation and service instructions
for contractors
VIESMANN
Vitodens 200-W
Type B2HA, B2KA, 3.2 to 35 kW
Wall mounted gas condensing boiler
Natural gas and LPG version
For applicability, see the last page
VITODENS 200-W
5772 980 GB 4/2013 Please keep safe.
2
Please follow these safety instructions closely to
prevent accidents and material losses.
Safety instructions explained
Danger
This symbol warns against the risk of injury.
!Please note
This symbol warns against the risk of material
losses and environmental pollution.
Note
Details identified by the word "Note" contain additional
information.
Target group
These instructions are exclusively intended for quali-
fied contractors.
■Work on gas installations must only be carried out by
a registered gas fitter.
■Work on electrical equipment must only be carried
out by a qualified electrician.
■The system must be commissioned by the system
installer or a qualified person authorised by the
installer.
Regulations
Observe the following when working on this system:
■Statutory regulations regarding the prevention of
accidents
■Statutory regulations regarding environmental pro-
tection
■Codes of practice of the relevant trade associations
■All current safety regulations as defined by DIN, EN,
DVGW, TRGI, TRF, VDE and all locally applicable
standards
■Gas Safety (Installation & Use) Regulations
– the appropriate Building Regulation either the
Building regulations, the Building Regulation (Scot-
land), Building Regulations (Northern Ireland),
– the Water Fittings Regulation or Water Bylaws in
Scotland,
– the current I.E.E. Wiring Regulations.
If you smell gas
Danger
Escaping gas can lead to explosions which may
result in serious injury.
■Do not smoke. Prevent naked flames and
sparks. Do not switch lights or electrical appli-
ances on or off.
■Close the gas shut-off valve.
■Open windows and doors.
■Evacuate any people from the danger zone.
■Notify your gas or electricity supply utility from
outside the building.
■Shut off the electricity supply to the building
from a safe place (outside the building).
If you smell flue gas
Danger
Flue gas can lead to life-threatening poisoning.
■Shut down the heating system.
■Ventilate the installation site.
■Close all doors in the living space.
Flue systems and combustion air
Ensure that flue systems are clear and cannot be
sealed, for instance due to accumulation of conden-
sate or other causes. Ensure a sufficient supply of
combustion air.
Instruct system users that subsequent modifications to
the building characteristics are not permissible (e.g.
cable/pipework routing, cladding or partitions).
Danger
Life-threatening poisoning caused by carbon
monoxide in the flue gas occurs as a result of
leaking or blocked flue systems or an insufficient
supply of combustion air.
Ensure the flue system is in proper working
order. It must not be possible to close apertures
for interconnected combustion air supply.
Extractors
Operating appliances that extract air to the outside
(cooker hoods, extractors, air conditioning units, etc.)
can create negative pressure. If the boiler is operated
at the same time, this can lead to reverse flow of the
flue gas.
Danger
The simultaneous operation of the boiler and
appliances that extract air to the outside can
result in life threatening poisoning due to
reverse flow of the flue gas.
Fit an interlock circuit or take suitable steps to
ensure a sufficient supply of combustion air.
Safety instructions
Safety instructions
5772 980 GB
3
Working on the system
■Where gas is used as the fuel, close the main gas
shut-off valve and safeguard it against unintentional
reopening.
■Isolate the system from the power supply (e.g. by
removing the separate fuse or by means of a mains
isolator) and check that it is no longer 'live'.
■Safeguard the system against reconnection.
!Please note
Electronic assemblies can be damaged by elec-
trostatic discharge.
Prior to commencing any work, touch earthed
objects, such as heating or water pipes to dis-
charge static loads.
Repair work
!Please note
Repairing components that fulfil a safety func-
tion can compromise the safe operation of your
system.
Defective components must be replaced with
genuine Viessmann spare parts.
Auxiliary components, spare and wearing parts
!Please note
Spare and wearing parts that have not been tes-
ted together with the system can compromise its
function. Installing non-authorised components
and making non-approved modifications or con-
versions can compromise safety and may inva-
lidate our warranty.
For replacements, use only original spare parts
supplied or approved by Viessmann.
Safety instructions
Safety instructions (cont.)
5772 980 GB
4
1. Preparing for installation Intended use .......................................................................................... 7
Product information ................................................................................ 7
■Vitodens 200-W, type B2HA, B2KA .................................................... 7
Preparing for installation ........................................................................ 8
■Cold water installation ........................................................................ 9
■Shock arrestor .................................................................................... 9
2. Installation sequence Mounting the boiler and making connections ........................................ 10
■Fitting the connections ........................................................................ 10
Flue gas connection ............................................................................... 10
Condensate drain connection ................................................................ 11
Gas connection ...................................................................................... 11
Opening the control unit enclosure ........................................................ 12
Electrical terminals ................................................................................. 13
■Outside temperature sensor ! .......................................................... 14
■External demand via switching contact .............................................. 14
■External demand via 0 – 10 V input .................................................... 14
■External blocking via switching contact .............................................. 15
■Power supply for accessories at plug lH (230 V~) ............................. 16
■Power supply fÖ ................................................................................. 17
■Routing connecting cables ................................................................. 17
Closing the control unit enclosure and inserting the programming unit . 18
Fitting the front panel ............................................................................. 19
3. Commissioning, inspec-
tion, maintenance
Steps - commissioning, inspection and maintenance ............................ 20
4. Code 1 Calling up coding level 1 ........................................................................ 43
■Calling up coding level 1 ..................................................................... 43
"General"/Group 1 ................................................................................ 43
■Coding ................................................................................................ 44
"Boiler"/Group 2 ................................................................................... 45
■Coding ................................................................................................ 45
"DHW"/Group 3 ..................................................................................... 46
■Coding ................................................................................................ 46
"Solar"/Group 4 .................................................................................... 46
"Heating circuit ..."/Group 5 ................................................................ 47
■Coding ................................................................................................ 48
5. Code 2 Calling up coding level 2 ........................................................................ 52
■Calling up coding level 2 ..................................................................... 52
"General"/Group 1 ................................................................................ 52
■Coding ................................................................................................ 53
"Boiler"/Group 2 ................................................................................... 57
■Coding ................................................................................................ 58
"DHW"/Group 3 ..................................................................................... 58
■Coding ................................................................................................ 59
"Solar"/Group 4 .................................................................................... 60
■Coding ................................................................................................ 60
"Heating circuit ..."/Group 5 ................................................................ 62
■Coding ................................................................................................ 63
6. Diagnosis and service
scans
Service level .......................................................................................... 68
Diagnosis ............................................................................................... 68
■Operating data .................................................................................... 68
■Brief scan ............................................................................................ 69
Checking outputs (actuator test) ............................................................ 72
Index
Index
5772 980 GB
5
7. Troubleshooting Fault display ........................................................................................... 74
■Weather-compensated control unit ..................................................... 74
■Constant temperature control unit ...................................................... 74
Fault codes ............................................................................................ 75
Repair .................................................................................................... 83
■Checking the outside temperature sensor .......................................... 83
■Checking the boiler temperature sensor, cylinder temperature sen-
sor or low loss header flow temperature sensor ................................. 84
■Checking the outlet temperature sensor or comfort sensor (only for
gas condensing combi boilers) ........................................................... 85
■Checking the plate heat exchanger .................................................... 86
■Checking the flue gas temperature sensor ......................................... 86
■Checking the temperature limiter ........................................................ 87
■Checking the fuse ............................................................................... 87
■Extension kit, mixer ............................................................................ 88
■Checking the Vitotronic 200-H (accessory) ........................................ 89
8. Function description Constant temperature control unit ......................................................... 90
■Heating mode ..................................................................................... 90
■DHW heating with gas condensing combi boiler ................................ 90
■DHW heating with gas condensing boiler ........................................... 90
Weather-compensated control unit ........................................................ 91
■Heating mode ..................................................................................... 91
■DHW heating with gas condensing combi boiler ................................ 91
■DHW heating with gas condensing boiler ........................................... 91
■Boosting DHW heating ....................................................................... 91
Internal extensions (accessories) .......................................................... 92
■Internal extension H1 .......................................................................... 92
■Internal extension H2 .......................................................................... 93
External extensions (accessories) ......................................................... 94
■Extension AM1 ................................................................................... 94
■Extension EA1 .................................................................................... 95
Control functions .................................................................................... 96
■External heating program changeover ............................................... 96
■External blocking ................................................................................ 97
■External demand ................................................................................ 97
■Venting program ................................................................................. 98
■Fill program ......................................................................................... 98
■Screed drying ..................................................................................... 98
■Raising the reduced room temperature .............................................. 100
■Reducing the heat-up time ................................................................. 100
Allocating heating circuits to the remote control .................................... 101
Electronic combustion control unit ......................................................... 102
9. Designs Connection and wiring diagram – Internal connections ......................... 103
Connection and wiring diagram – External connections ........................ 104
10. Parts lists Ordering individual parts ........................................................................105
Overview of the assemblies ...................................................................105
Casing ....................................................................................................105
Heat cell .................................................................................................106
Burner .................................................................................................... 107
Hydraulics type B2HA ............................................................................108
■Aqua plate type B2HA ........................................................................ 109
Hydraulics type B2KA ............................................................................ 110
■Aqua plate type B2KA ........................................................................ 111
Control unit ............................................................................................ 112
Miscellaneous ........................................................................................ 113
Index
Index
5772 980 GB
6
11. Commissioning/service
reports
.................................................................................................................. 115
12. Specification .................................................................................................................. 116
13. Certificates Declaration of conformity ....................................................................... 118
Manufacturer's certificate according to the 1st BImSchV [Germany] .... 118
14. Keyword index .................................................................................................................. 119
Index
Index (cont.)
5772 980 GB
7
The appliance is only intended to be installed and
operated in sealed unvented heating systems that
comply with EN 12828, with due attention paid to the
associated installation, service and operating instruc-
tions. It is only designed for the heating of water that is
of potable water quality.
Intended usage presupposes that a fixed installation in
conjunction with permissible, system-specific compo-
nents has been carried out.
Commercial or industrial usage for a purpose other
than heating the building or DHW does not comply with
regulations.
Any usage beyond this must be approved by the man-
ufacturer for the individual case.
Incorrect usage or operation of the appliance (e.g. the
appliance being opened by the system user) is prohibi-
ted and results in an exclusion of liability. Incorrect
usage also occurs if the components in the heating
system are modified from their intended function (e.g.
if the flue gas and ventilation air paths are sealed).
Product information
Vitodens 200-W, type B2HA, B2KA
Preset for operation with natural gas E and
natural gas LL.
For conversion to LPG P (without conversion kit), see
"Commissioning, inspection, maintenance".
In principle the Vitodens 200-W may only be delivered
to countries listed on the type plate. For deliveries to
alternative countries, approved contractors must
arrange individual approval on their own initiative and
in accordance with the law of the country in question.
Preparing for installation
Intended use
5772 980 GB
Installation
8
!Please note
To prevent appliance damage,
connect all pipework free of load and torque
stress.
360
450
730
1925 H
850
100 215
50
a
A B C D EF K
G
Fig. 1
AHeating flow Rp¾
BDHW Rp½ (gas condensing combi boiler)
Cylinder flow G¾ (gas condensing boiler)
CGas connection
DCold water Rp½ (gas condensing combi boiler)
Cylinder return G¾ (gas condensing boiler)
EHeating return Rp¾
FFilling/draining
GWiring area
HDimension with DHW cylinder below
KCondensate drain
Rated heating output
kW
Dim. a
mm
3.2 - 19.0 136
6.5 - 26.0 158
8.8 - 35.0 158
Note
This boiler (IP rating: IP X4 D) is approved for installa-
tion in wet rooms inside safety zone 1 according to
DIN VDE 0100. Exposure to water jets must be pre-
vented.
Observe the requirements of DIN VDE 0100.
1. Fit the pre-plumbing jig or mounting frame provided
at the chosen installation site.
Pre-plumbing jig or mounting frame installa-
tion instructions
2. Prepare the connections on the water side for the
valves on the pre-plumbing jig or mounting frame.
Thoroughly flush the heating system.
3. Prepare the gas connection according to TRGI or
TRF [or local regulations].
Preparing for installation
Preparing for installation
5772 980 GB
Installation
9
4. Prepare the electrical connections. ■Power cable: NYM-J 3 x 1.5 mm2, max. fuse rat-
ing 16 A, 230 V, 50 Hz.
■Accessory cables: NYM with the required number
of cores for the external connections.
■All cables should protrude 1200 mm from the wall
near "G".
Cold water installation
Fig. 2
ACold water connection, boiler
BDrain outlet
CVisible discharge pipe outlet point
DSafety valve
ENon-return valve
FShut-off valve
GCold water
HSafety assembly
A safety assembly H to DIN 1988 and EN 806 is
required if the mains water supply pressure exceeds
10 bar (1.0 MPa), and no DHW pressure reducing
valve is installed (to DIN 4753).
Only use a non-return valve or a combined shut-off
and non-return valve in conjunction with a safety valve.
If the safety valve is used, the cold water shut-off valve
on the boiler must not be shut off.
Remove the toggle on the cold water shut-off valve (if
installed) to prevent it being shut off manually.
Shock arrestor
If draw-off points that could cause pressure peaks
(water hammer/shock) are connected to the same
pipework as the boiler (such as pressure washers,
washing machines or dishwashers), we would recom-
mend the installation of a shock arrestor near the
source of such pressure shocks.
g: Fit a small domestic expansion vessel if water
hammer occurs.
Preparing for installation
Preparing for installation (cont.)
5772 980 GB
Installation
10
2x
6.
7.
5.
3.
2x
2.
1.
4.
Fig. 3
Fitting the connections
A B C D E F
Fig. 4
AHeating flow
BDHW (gas condensing combi boiler)
Cylinder flow (gas condensing boiler)
CGas connection
DCold water (gas condensing combi boiler)
Cylinder return (gas condensing boiler)
EHeating return
FFilling/draining
Flue gas connection
Note
The labels "System certificate" and "Skoberne GmbH
flue system" enclosed with the technical documenta-
tion may only be used in conjunction with the
Viessmann flue system made by Skoberne.
Connecting the balanced flue
Flue system installation instructions
Installation sequence
Mounting the boiler and making connections
5772 980 GB
Installation
