VZ-MV802

MULTIVIEWER SYSTEM

HARDWARE MANUAL

VERSION 1.0

Dated Dec. 21, 2018

Driving Visual Innovation

All contents of this document may change without prior notice, and actual product appearance may differ from that depicted

herein

TABLE OF CONTENTS

COMPLIANCE INFORMATION....................................................................................................3

WARRANTY STATEMENT ..........................................................................................................3

Limitation of Liability.................................................................................................................4

Extended Warranty Options.....................................................................................................5

Services and Repairs outside the Warranty Period..................................................................5

Disclaimer.................................................................................................................................5

Operating Environment ............................................................................................................5

INTRODUCTION TO VZ-MV802 MULTIVIEWERS.......................................................................6

HARDWARE.................................................................................................................................6

VZ-MV802 PLATFORM PRODUCT LINE.....................................................................................6

TECHNICAL SPECIFICATIONS ..................................................................................................8

PHYSICAL SPECIFICATIONS...................................................................................................13

INSTALLATION..........................................................................................................................16

OPERATION...............................................................................................................................18

APPENDIX A: CONNECTORS ..................................................................................................20

APPENDIX B: REDUNDANT POWER SUPPLIES....................................................................26

CONTACT VIEWZ.....................................................................................................................28

COMPLIANCE INFORMATION

The ViewZ equipment has been tested to comply with the following.

•FCC - Class A

This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when the equipment is operated in a

commercial environment. This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in accordance with the instruction

manual, may cause harmful interference to radio communications. Operation of this

equipment in a residential area is likely to cause harmful interference in which case the

user will be required to correct the interference at his / her own expense.

•CE

•C-Tick

•RoHS

WARRANTY STATEMENT

ViewZ warrants to the original purchaser of the products manufactured by ViewZ (the “Product,”) will be

free from defects in material and workmanship for a period of three (3) year from the date of shipment

of the Product to the purchaser.

If the Product proves to be defective during the three (3) year warranty period, the purchaser’s

exclusive remedy and ViewZ’s sole obligation under this warranty is expressly limited, at ViewZ’s sole

option, to:

(a) repair the defective Product without charge for parts and labor or

(b) provide a replacement in exchange for the defective Product or

Product in good working order

then the purchaser shall be entitled to recover damages subject to the limitation of liability set forth

below.

BLimitation of Liability

ViewZ’s liability under this warranty shall not exceed the purchase price paid for the defective product.

In no event shall ViewZ be liable for any incidental, special or consequential damages, including without

limitation, loss of profits for any breach of this warranty.

If ViewZ replaces the defective Product with a replacement Product as provided under the terms of this

Warranty, in no event will the term of the warranty on the replacement Product exceed the number of

months remaining on the warranty covering the defective Product.

Equipment manufactured by other suppliers and supplied by ViewZ carries the respective manufacturer’s

warranty. ViewZ assumes no warranty responsibility either expressed or implied for equipment

manufactured by others and supplied by ViewZ.

This hardware warranty shall not apply to any defect, failure or damage:

a) Caused by improper use of the Product or inadequate maintenance and care of the

Product;

b) Resulting from attempts by those other than ViewZ representatives to install, repair, or

service the Product;

c) Caused by installation of the Product in a hostile operating environment or connection of the

Product to incompatible equipment; or

d) Caused by the modification of the Product or integration with other products when the effect of

such modification or integration increases the time or difficulties of servicing the Product. Any

Product which fails under conditions other than those specifically covered by the Hardware

Warranty, will be repaired at the price of parts and labor in effect at the time of repair. Such

repairs are warranted for a period of ninety (90) daysfrom date of reshipment to customer.

2Extended Warranty Options

ViewZ offers OPTIONAL Extended Warranty plans that provide continuous coverage for the Product

after the expiration of the Warranty Period. Please contact an ViewZ sales representative for details

on the options that are available for your ViewZ equipment.

Services and Repairs outside the Warranty Period

ViewZ makes its best offer to repair products that are outside the warranty period, provided the

product has not reached its end of life.

Disclaimer

Use of this product is limited to the intended design purpose. Any damage caused by use other than the

design purpose will void the above warranty.

2Operating Environment

ViewZ VZ-MV802 Multiviewers should be operated in an environment that is safe for sensitive

electronic equipment. It should not be placed in hot, dusty, or humid locations without

adequate cooling, filtration, or ventilation.

INTRODUCTION TO VZ-MV802 MULTIVIEWERS

The ViewZ VZ-MV802 Multiviewer platform displays multiple auto-detecting video inputs at different

formats on a high resolution display up to resolutions of 2048x1080. The VZ-MV802 Platform

combines the display of video windows, audio meters, label/UMD, tallies, alarms and indicators in a

very space efficient package.

HARDWARE

The ViewZ VZ-MVxxx Multiviewer Platform consists of 2 different sizes of mechanical frames to serve

the needs of broadcast, professional AV and surveillance markets. Each multiviewer frame has a

unique IP address, which allows a PC/laptop to easily connect and configure the display layouts.

VZ-MVxxx PLATFORM PRODUCT LINE

Two types of mechanical frames are available for the VZ-MVxxx family:

1. VZ-MV802: The 1 RU VZ-MV802 accepts 8 video inputs including from HDMI*, DVI or VGA.

The VZ-MV802 has two flexible DVI/HDMI (1.2/1.3) with user selectable resolutions up to

2048x1080. Analog or AES audio options can be added at any time during or after the

purchase.

*Flexible Outputs – VZ-MV802 examples: *OPTIONS

Output(s)

1 2

Inputs 4 4

Inputs 8

2. VZ-MV1604: The 2 RU VZ-MV1604 accepts 16 video inputs including HDMI*, DVI or VGA.

The VZ-MV1604 has four flexible DVI/HDMI (1.2/1.3) with user selectable resolutions up to

2048x1080. Analog or AES audio options can be added at any time during or after the

purchase.

*Flexible Outputs –VZ-MV1604 examples: *OPTIONS

Output(s)

1 2 3 4

Inputs 4 4 4 4

Inputs 4 4 8

Inputs 8 8

Inputs 12 4

Inputs 16

TECHNICAL SPECIFICATIONS

•Auto detect HD-SD/SDI/CV 50/60Hz (available formats depends on the model)

•Auto detect HDMI/DVI/VGA/CV/YC/component (available formats depends on the model)

•Output resolution up to 2048x1080 (720x480 – 2048x1080)

•Digital and Analog clocks can be synchronized with NTP or LTC (time code)

•Up to 30 presets for display layout

•Presets can be recalled via GPI, front panel buttons or ASCII protocol via network or serial

•On Screen Display (OSD) for labels, border and alarms can be customizable via iSkin® with

industry standard graphical tools

•Auto-detect aspect ratio between 16x9 and 4x3

•Communication interface via IP or RS232

•Supports ViewZ eXtended Protocol (AXP)

•Supports direct TSL tally/UMD interface

•Supports multiple languages (including 2 byte characters)

•Supports SDI output (optional)

Table 1: Serial Video input (OPTION)

Standards Upgradeable to 3Gb/s (SMPTE

424M) HD-SDI (SMPTE 292M) SD-

SDI (SMPTE 259M-C) PAL/NTSC

Connector BNC

Equalization Automatic to 140m (Belden 1694A)

Return Loss 15db up to 270mb/s

Embedded Audio SMPTE 272-A

Table 2: Video Formats supported

480i 720p/30 1080p/23.98 2048x1080p/23.98

480p 720p/50 1080p/24 2048x1080p/24

576i 720p/59.94 1080p/25

576p 720p/60 1080p/29.97

720p/23.98 1035i/59.94 1080p/30

720p/24 1035i/60 1080sf/23.98

720p/25 1080i/50 1080sf/24

720p/29.97 1080i/59.94 1080sf/30

Table 3: Computer Formats supported (50/ 60Hz)

720x480 852x480 1024x768 1280x768

800x600 1280x960 1280x1024 1360x768

1280x800 1400x900 1400x1050 1600x1200

1366x768 1920x1080 1920x1200 1680x1050

Table 4: Audio input

Type Default Option

AES 75 Q unbalanced via BNC 110 Q balanced via XLR

Analog Stereo Unbalanced via BNC balanced via XLR

Table 5: Display Output

Standards HDMI 1.3 up to 2048x1080, SDI*

Connector HDMI

Impedance 100Q, 75Q

*OPTION

Table 6: Audio Outputs

Type Number/type/connector Location Adjustment

AES 1 / unbalanced / BNC Rear Panel None, Line Level

Stereo Analog 1 / unbalanced / phone jack Rear Panel None, Line Level

Stereo Analog 1 / unbalanced / phone jack Front Panel Front Panel knob

Table 7: Output Resolution (50 and 60Hz)

720x480 852x480 1024x768 1280x768

800x600 1280x960 1280x1024 1360x768

1280x800 1400x1050 1600x1200 1680x1050

1366x768 1920x1080 1920x1200 2048x1080

TabLE-8: General Purpose Interface I/ O

Number On VPM On CPM

Inputs 8, assignable to input or

output 8, assignable to input or

output

Outputs 8, assignable to input or

output 8, assignable to input or

output

Connector DB9 RJ50 to DB9
