R E V I S E D 5 / 1 1 / 1 1

PLANNING AND DESIGN GUIDE

V I K I N G R A N G E . C O M • 1 - - V I K I N G 1

Both ovens include

• Capacity—1.5 cu. ft. interior cavity

o 16-1/ ”W. x 9-5/ ”H. x 16-1/ ”D.

o 15-3/ ” diameter turntable

• Commercial-type styling and design

• Instant sensor settings for cooking,

reheating, and popping popcorn

• Four convection settings use high-

speed fan that circulates air past the

heat source and around the food;

allows multiple-rack baking

o ConvecBroil

o ConvecRoast

o ConvecBake

o Manual convection

• Low Mix Bake and High Mix Roast

settings offer use of convection heat

to seal and brown outside of foods

while using microwave energy to

ensure the interior is cooked

• Add-A-Minute allows you to add a

minute of extra cooking time with the

touch of one button

• Child Lock safety feature locks the

control panel to prevent unwanted

operation

• Cookbook included

• Interior light

• Suitable for placement on counter-

top, or installed as a built-in using a

trim kit. (Trim kits sold separately—

see Installation Notes &

Accessories for part numbers.)

FINISH DETAILS FOR PROFESSIONAL MODEL

• Stainless Steel (SS), Black (BK), White

(WH), Metallic Silver (MS), Graphite Gray

(GG), Stone Gray (SG), Taupe (TP),

Biscuit (BT), Cotton White (CW), Oyster

Gray (OG), Golden Mist (GM),

Lemonade (LE), Sage (SA), Mint Julep

(MJ), Sea Glass (SE), Iridescent Blue (IB),

Viking Blue (VB), Pumpkin (PM), Racing

Red (RR), Apple Red (AR), Burgundy

(BU), Plum (PL), Chocolate (CH), and

Cobalt Blue (CB).

Standard Features & Accessories

Model Options

COOKING

Professional Custom Convection Microwave Oven

*Shown with tri kit. See Installation Notes & Accessories for details.

ORDERING INSTRUCTIONS

First specify model number, and then color code (VMOC206SS).

VMOC206

Professional Custo

Convection Microwave Oven

VMOC206*

w/Tri Kit

PLANNING AND DESIGN GUIDE

V I K I N G R A N G E . C O M • 1 - - V I K I N G 1

R E V I S E D 5 / 1 1 / 1 1

COOKING

Professional Custom Convection Microwave Oven

✪

Please see

Installation Notes

and Accessories for

important information,

including trim kits.

All models

Overall width 2 -5/8” (62.5 cm)

Overall height from bottom) 1 -7/8” (37.7 cm)

Overall depth from rear) 19” ( 8.3 cm)

Interior each oven)

Width 16-1/8” ( 0.9 cm)

Height 9-5/8” (2 . cm)

Depth 16-1/8” ( 0.9 cm)

Approx. ship weight 60 lbs. (27.2 kg)

Dimensions & Specifications

PRODUCT DIMENSIONS

19”

(48.3cm)

24-5/8”

(62.5cm)

14-7/8 ”

(37.7cm)

VMOC206

Professional Custo

Convection Microwave Oven

VMOC206

w/Tri Kit

PROFESSIONAL

CUSTOM

PLANNING AND DESIGN GUIDE

V I K I N G R A N G E . C O M • 1 - - V I K I N G 1

R E V I S E D 5 / 1 1 / 1 1

18-11/16”

(47.5cm)min.

18-11/16”

(47.5cm)min.

11-1/2”

(29.2cm)

11-1/2”

(29.2cm)

25”

(63.5cm)min.

20-1/8”

(51.1cm)min.

5”

(12.7cm)

5”

(12.7 cm)

5”

(12.7cm)

Outlet

location

area

All Models

Cutout width 25” (63.5 cm) min.

Cutout height 18-11/16” ( 7.5 cm) min.

Cutout depth 20-1/8” (51.1 cm) min.

COOKING

Professional Custom Convection Microwave Oven

UTILITY

REQUIREMENTS

GAS

•Not applicable

ELECTRICAL

• 3.5-foot power cord

included

• 120 VAC/60 Hz

• Maximum amp

usage—

13 (1.55 kW)

PLUMBING

Not applicable

Installation Requirements

ACCESS REQUIREMENTS

VMOC206

Professional Custo

Convection Microwave Oven

VMOC206

w/Tri Kit

COOKING

Professional Custom Convection Microwave Oven

PLANNING AND DESIGN GUIDE

V I K I N G R A N G E . C O M • 1 - - V I K I N G 1

R E V I S E D 5 / 1 1 / 1 1

Built-In Trim Kits

• Stainless Steel (SS)

• Designed to match with corresponding ovens and warming drawers

•Trim gives finished look to ovens installed as built-in units

• Kit includes frame assemblies, exhaust duct assembly, and metal fasteners

Compliance Information

WARRANTY INFORMATION*

• Three-year full warranty—complete product (Professional Series)

• One-year full warranty—complete product (Designer Series)

• Five-year limited warranty—magnetron tube (Professional and Designer)

• Ninety-day limited warranty—cosmetic parts such as glass, painted, and decorative items (Professional and Designer)

*For complete warranty see Use & Care Guide. Warranty valid on Viking products shipped within the United States and Canada.

✪Installation Notes & Accessories

Model Description Approx. ship wt. lbs. (kg))

VMTK277 26-1/2”W./19-13/16”H. Professional microwave trim 14 6.5)

VMTK307 29-1/2”W./19-13/16”H. Professional microwave trim 15 6.9)

VMTK367 35-1/4”W./19-13/16”H. Professional microwave trim 16 7.2)
