VK2 -600PTZ
Configuration and User manual
II
VK2-600PTZ User manual
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT
TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECTS THROUGH THE
VENTILATION GRILLS OR OTHER OPENINGS ON THE EQUIPMEMT.
CAUTION
EXPLANATION OF GRAPHICAL SYMBOLS
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of uninsulated
“dangerous voltage” within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral is intended to alert the user
to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
III
VK2-600PTZ User manual
CE COMPLIANCE STATEMENT
WARNING
THIS IS A CLASS A PRODUCT. IN A DOMESTIC ENVIRONMENT THIS
PRODUCT MAY CAUSE RADIO INTERFERENCE IN WHICH CASE THE USER
MAY BE REQUIRED TO TAKE ADEQUATE MEASURES.
IV
VK2-600PTZ User manual
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide blade or the third prong are
provided for your safety. If the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified
by the manufacturer, or sold with the apparatus. When a cart is
used, use caution when moving the cart/apparatus combination
to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused
for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been moisture, does not operate normally, or has been
dropped.
15. CAUTION –THESE SERVICING INSTRUCTIONS ARE FOR USE BY
QUALIFIED SERVICE PERSONNEL ONLY. TO REDUCE THE RISK OF
ELECTRIC SHOCK DO NOT PERFORM ANY SERVICING OTHER THAN THAT
CONTAINED IN THE OPERATING INSTRUCTIONS UNLESS YOU QRE
QUALIFIED TO DO SO.
16. Use satisfy clause 2.5 of IEC60950-1/UL60950-1 or Certified/Listed Class 2
power source only.
V
VK2-600PTZ User manual
Table of Contents
Chapter 1 —Introduction...........................................................................................................1
1.1 Features.............................................................................................................................................1
Chapter 2 —Installation and Configuration.........................................................................2
2.1 Package Contents............................................................................................................................2
2.2 Installation.........................................................................................................................................3
2.3 Basic Configuration of Dome Camera System........................................................................4
2.4 Setting Dome Camera Address (ID)............................................................................................5
2.5 Connections......................................................................................................................................5
2.6 IP Assignment..................................................................................................................................6
2.7 Getting Started.................................................................................................................................7
Chapter 3 —Operation by Web Browser ..............................................................................8
3.1 Access from a browser..................................................................................................................8
3.2 Access from the internet...............................................................................................................9
3.3 Setting the admin password over a secure connection........................................................9
3.4 Live View Page.................................................................................................................................9
3.5 Network Camera Setup ................................................................................................................11
3.5.1 Basic Configuration...............................................................................................................12
1) Users..........................................................................................................................12
2) Network......................................................................................................................13
3) Video & Image ........................................................................................................... 14
4) Audio..........................................................................................................................16
5) Date & Time ............................................................................................................... 17
3.5.2 Video & Image.........................................................................................................................18
3.5.3 Audio .........................................................................................................................................19
3.5.4 Event..........................................................................................................................................19
1) Event-In......................................................................................................................19
2) Event-Out...................................................................................................................23
3) Event Map.................................................................................................................. 29
3.5.5 System ......................................................................................................................................31
1) Information ................................................................................................................31
2) Security......................................................................................................................31
3) Date & Time ............................................................................................................... 34
4) Network......................................................................................................................35
5) Language...................................................................................................................42
6) Maintenance ..............................................................................................................42
7) Support......................................................................................................................43
VI
VK2-600PTZ User manual
3.6 PTZ Control.....................................................................................................................................44
3.7 Help...................................................................................................................................................45
3.8 Resetting to the factory default settings.................................................................................46
3.9 System Requirement for Web Browser ...................................................................................46
Chapter 4 —Program and Operation (RS485 telemetry)................................................47
4.1 How to control the On-Screen Menu........................................................................................47
4.2 Accessing the On-Screen Menu................................................................................................47
4.3 Auto Scan ........................................................................................................................................48
4.4 Preset................................................................................................................................................50
4.5 Quick setting a Preset..................................................................................................................52
4.6 Tour ...................................................................................................................................................52
4.7 Pattern (Learn Tour)......................................................................................................................53
4.8 Area Title..........................................................................................................................................54
4.9 Privacy Zone...................................................................................................................................55
4.10 Camera Menu................................................................................................................................56
• FOCUS CONTROL.......................................................................................................56
• WB (White Balance) CONTROL..................................................................................57
• AE CONTROL ..............................................................................................................57
• DNR CONTROL............................................................................................................ 58
4.11 Dome Setup...................................................................................................................................59
• LANGUAGE SETUP.....................................................................................................59
• HOME FUNCTION SETUP ........................................................................................... 59
• OSD DISPLAY.............................................................................................................. 60
• VIEW ANGLE SETUP...................................................................................................61
• INITIALIZE DATA .........................................................................................................62
• ORIGIN OFFSET ..........................................................................................................63
• DOME RESET .............................................................................................................. 64
• SYSTEM MENU............................................................................................................64
• SYSTEM INFORMATION ............................................................................................. 66
4.12 Factory Setup...............................................................................................................................66
5 - Dome Communication (RS485 Addressing etc)..........................................................67
Appendix A —Specifications.................................................................................................68
Appendix B —Troubleshooting.............................................................................................71
Appendix C —Glossary...........................................................................................................71
1
VK2-600PTZ User manual
Chapter 1 —Introduction
1.1 Features
Dual video streams simultaneously at full frame rate in all resolutions up to D1 (720X480 in
NTSC, 720X576 in PAL) using Motion JPEG and H.264 (or MPEG-4).
Built-in 22:1 optical zoom with True Day/Night operation
Intelligent capabilities such as enhanced video motion detection
The encoder’s external inputs and outputs can be connected to devices such as sensors and
relays, enabling the system to react to alarms and activate lights or open/close doors.
Supports two-way audio
Logs all user access, and lists currently connected users. Also, full frame rate video can be
provided over HTTPS.
Interface Protocol: TCP/IP, UDP, IPv4/v6, HTTP, HTTPS, QoS, FTP, SNMP, uPnP, RTP,
RTSP, RTCP, DHCP, ARP.
120 Preset positions with the individual Camera AE setup
4 Tours consist of Presets, Patterns, Auto Scan and other Tours can be programmed with over
150 functions and Preset locations. While moving, each Preset scan can be watched in smooth
Vector Scan mode.
1 Auto Scan with the normal, the vector, and the random mode with 13 speed steps
4 Patterns (up to 200 second) and 4 Privacy Zones
8 Area Titles
1 Alarm input / 1 Alarm output
Variable speed from 0.1/sec to 380/sec
Three Variable speed (SLOW, NORMAL, TURBO)
Pan / Tilt speed is inversely proportional to the zoom ratio with the option.
Maximum speed is 380/sec when Preset command.
Auto Calibration from 0.1to 6(Tilt range is 0to 180).
Programmable user preferences (alarm, preset, title, etc.).
180Digital Flip
Up to 255 selectable camera addresses.
Multi-language Menu Display, Password Confirmation
Built-in RS-485 receiver driver
12VDC operation
Use satisfy clause 2.5 of IEC60950-1/UL60950-1 or Certified/Listed Class 2 power source only.
2
VK2-600PTZ User manual
Chapter 2 —Installation and Configuration
2.1 Package Contents
VK2-600PTZ is design to be a compact, vandal resistant dome camera.
The housing is constructed of aluminum, steel and plastic. The housing is designed to be
mounted both wall and ceiling type.
The housing meets the Protection Classification IP66 standards for dust and moisture resistance.
* Dome Camera ................................................................1
* Installation Guide/CD ....................................................1
* Template Sheet ..............................................................1
* Mounting Bracket ..........................................................1
* Safety Lanyard ..............................................................1
* Accessory Kit .................................................................1
1) Mounting screws (PH6 x 35.0) ..........(4)
2) Plastic anchors ..................................(4)
3) O-Rings ..............................................(4)
4) Torx wrench .......................................(1)
* Accessory Connector ....................................................1
1) 2Pin Terminal Block ...........................(1)
2) 3Pin Terminal Block ...........................(1)
3) 6Pin Terminal Block ...........................(1)
3
VK2-600PTZ User manual
2.2 Installation
VK2-600PTZ is for use in surface or pendent mounting applications and the mounting member
must be capable of supporting loads of up to 1.6kg. (Pendent mounting must use pendent mount
accessory.)
VK2-600PTZ’s mounting bracket should be attached to a structural object, such as hard wood,
wall stud or ceiling rafter that supports the weight of VK2-600PTZ.
CAUTION: Before installing the bracket to surface, adjust the four mounting screws "A"
on the base of the dome camera to best match the mounting bracket locked
position. Unscrew the locking screw on the side of the dome's base and fit the
tab of the mounting bracket into the locking slot. Screws "A" should not be too
tight or too loose when the dome is in the locked position. After setting the
proper positions of screws "A" remove the mounting bracket and install the
bracket onto the required surface. If it is difficult to lock the dome in position
after the mounting bracket has been installed, readjust the screws "A" by
unscrewing them a small amount and try to install dome camera again.
4
VK2-600PTZ User manual
2.3 Basic Configuration of Dome Camera System
No.
Wire Color
Description
1
Red: 12V DC+
White: 12V DC-
Main Power: 2pin terminal
2
Pink, Brown
Heater Power(Option): 3pin terminal
3
Black: GND
Gray: Alarm Input
Yellow: GND
Black&White: Alarm Output
Green: RS485+
Blue: RS485-
Alarm Input/Output, RS485: 6pin terminal
4
Black
Ethernet: RJ45 Modular Jack
5
Yellow
Video Composite Output: BNC Jack
6
Red
Audio line output: RCA Jack
7
White
Audio line input: RCA Jack
VK2-600PTZ must be installed by qualified service personnel in accordance with all local
electrical and building codes.
AC+
AC-
AC+
AC-
FGND
(Rx+)
(Rx-)
Rx(Tx)+
Rx(Tx)-
GND
Dieses Handbuch passt für folgende Modelle
1
Inhaltsverzeichnis
Andere Vip2 Sicherheitskamera Handbücher
