VOLT®Low Voltage Landscape Lighting

VOLT®G2 Arch Brass Path & Area Light

VPL-1048-4-BBZ

INSTALLATION INSTRUCTIONS

Specications and product details subject to change without notice.

[email protected] • 813.978.3700

Help Hotline:

1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)

- 1 -

Important: Please Read Before Installation

INSTALLATION INSTRUCTIONS

www.voltlighting.com

Important Safety Instructions

- 2 -

G2 Arch Brass Path & Area Light

VPL-1048-4-BBZ

This luminaire is intended for installation in accordance with local codes

and the National Electric Code (NEC). Failure to adhere to these codes and

instructions may result in serious injury, property damage and void the

warranty.

These instructions do not intend to cover all variations in installation,

operation maintenance or mounting situations.

1. Make sure that the power is turned OFF before installing or servicing

this xture.

2. Warning: this xture is not intended to be installed within 10 feet [3

meters] of a pool, spa or fountain.

3. This xture is intended to be used only with a power supply

(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.

4. Underground Low Energy Cable must not be buried over 6” (15.2 cm) in

order to connect to the main low voltage cable.

5. Wiring connections must be made with UL Listed wire connectors that

are suitable for the application.

6. Position the wire connector so that it is located within 6 inches (15.2

cm) from a building structure, a luminaire, or tting.

INSTRUCTIONS PERTAINING TO A RISK OF FIRE, OR INJURY TO PERSONS

Lighted lamp is HOT!

WARNING – To reduce the risk of FIRE OR INJURY TO PERSONS.

1. Turn off/unplug and allow to cool before reducing lamp.

2. Lamp gets HOT quickly!

3. Do not touch the hot lens, guard or cowl.

4. Keep lamp away from materials that may burn.

5. Do not touch lamp at any time.

6. Use a soft cloth.

7. Oil from skin may damage lamp.

8. Do not operate the xture with a damaged or missing lens or shield.

[email protected] • 813.978.3700

- 3 -

Package Contents

A. (1) Fixture Body

Product Dimensions

Parts Required

A. (1) Mounting Accessory

B. (1) GU4 Bi-Pin

24.43”

3.39”

5.44”

11.81”

INSTALLATION INSTRUCTIONS

www.voltlighting.com

- 4 -

Remove Lens

Install Bulb

Install Lens

G2 Arch Brass Path & Area Light

VPL-1048-4-BBZ

Loosen the lens and remove it

from the xture body.

Fixture Body

Lens

Insert the bulb with the correct

wattage and type marked on the

xture label and push into place.

CAUTION: Do not exceed

maximum wattage marked on

xture label.

Socket

Bulb

Thread the lens back onto the

xture body and hand tighten

until snug.

Fixture Body

Lens

[email protected] • 813.978.3700

- 5 -

Install Stake

Install Fixture Body to Stake

Determine the desired location

for mounting the stake mount.

Hammer the stake into the

ground until ange of stake

is ush to grade. To avoid

damage to the stake, place a

board on top of the stake while

hammering.

Note: If the ground is hard and

the stake is difcult to install,

make a crosscut in the ground

using a at shovel.

Board

Ground

Soil

Stake

Pass the supply wires through

the center hole of the stake

and thread the stem onto

the stake. Hand tighten until

snug. Clear away an area in

the ground and lay the supply

wires into the wireway slot.

Ground

Stem

Supply Wires

Soil

Stake

INSTALLATION INSTRUCTIONS

www.voltlighting.com

- 6 -

Wire Connections

Adjust Shade Direction

G2 Arch Brass Path & Area Light

VPL-1048-4-BBZ

Strip both leads from the xture wires. Using two UL listed wire

connectors (sold separately), connect the leads from the xture wires to

the main supply cable leads.

Main Supply Cable

Fixture Wires

Wire Connectors

There are two methods to adjust the shade direction.

NOTE: Do not rotate the shade a full 3600. This will damage the internal

wiring.

A. Loosen the knuckle on the stem to adjust the shade to your desired

angle. Once your desired angle is achieved, hand tighten the knuckle

to secure the shade direction.

B. Using the Allen wrench, loosen the set screw on the stem and adjust

the shade to your desired angle. Once your desired angle is achieved,

tighten the set screw using the Allen wrench to secure the shade

direction.

Shade

Knuckle Allen Wrench Set Screw

ROTATE

OPTION A OPTION B

ROTATE

[email protected] • 813.978.3700

- 7 -

Install/Replace Bulb

Reverse Step 2 - Step 3 to expose the bulb and replace it with the correct

wattage and type marked on the xture label. Then, reinstall the lens.

IMPORTANT: The bulb must be protected from moisture and dust at all

times. Always reinstall the lens when removed.

- 8 -

Specications and product details subject to change without notice.

[email protected] • 813.978.3700

www.voltlighting.com

IS-VPL-1048-4-BBZ.pdf

Help Hotline:

1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
