Vulcan-Hart 2GPC12 Bedienungsanleitung

VULCAN-HART COmpANy, p.O. BOX 696, LOUISVILLE, Ky 40201, TEL. 1-800-814-2028

502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602

A2780

ISO9001

Vulcan-Hart Co.

Item # __________________________

C.S.I. Section 11420

F-32921 (6-07)

MODEL: 2GPC12 DOUBLE PASTA COOKER

STANDARDFEATURES

Stainless steel front and sides.

16 gauge 316 stainless steel tanks, 12 gallon capacity.

Set of Four 6" adjustable casters (2 locking).

Overflow dam with skim port for starch removal and overflow

protection.

1" full port drain valve.

90,000 BTU/hr. input each tank.

Temperature control adjusts from 190 to 212F. Power "ON",

"HEATING" and "HI-LIMIT" indicators.

Hi-limit shut-off.

Electronic pilot ignition system.

1/2" rear gas connection.

Hot and cold water mixing valve with swivel head (mounts on

rinse station only).

Tank cleaning brush.

One year limited parts and labor warranty. Twelve year limited

tank warranty.

ACCESSORIES

Fine mesh stainless steel bulk cook basket.

Twelve section retherm basket with a set of twelve plastic

retherm portion cups. NSF approved.

Set of six individual 51/4" round fine mesh stainless steel cook

and retherm baskets with base screen.

11/4" x 4 ft. flexible gas hose with quick disconnect and

restraining device.

MODEL 2GPC12

DOUBLE GAS PASTA COOKER

SPECIFICATIONS:

Double Gas pasta cooker with two cook tanks, Vulcan-Hart

Model No. 2GPC12. 12 gallon capacity each cook tank . Hot water

valves at the rear. Stainless steel front and sides. Set of four 6"

adjustable casters (2 locking). 16 gauge 316 stainless steel

tank with rear water fill. Overflow dam with skim port. 1" full port

ball type drain valve with common drain manifold for one connec-

tion. 90,000 BTU/hr. input. Temperature control adjusts from

190 to 212F. Power "ON", "HEATING" and "HI-LIMIT" indicators.

Hi-limit shut-off. Electronic pilot ignition system. 11/4" common

rear gas connection. Tank cleaning brush.

Overall dimensions: 31"w x 343/4"d x 361/4"h. Working height

361/4".

CSA design certified. NSF listed.

SPECIFY TYPE OF GAS WHEN ORDERING.

SPECIFYALTITUDEWHENABOVE 2,500FT.

2GPC12 shown

OPTIONS

Second year extended limited parts and labor warranty.

CERTIFIED

VULCAN-HART COmpANy, p.O. BOX 696, LOUISVILLE, Ky 40201, TEL. 1-800-814-2028

502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602

NOTE: In line with its policy to continually improve its products, Vulcan-Hart Company reserves the right to change materials and

specifications without notice.

F-32921 (6-07)

MODEL 2GPC12

DOUBLE GAS PASTA COOKER

IMPORTANT

1. A combination valve with pressure regulator is provided with this unit.

Natural Gas 4.0" (102 mm) W.C.

Propane Gas 10.0" (254 mm) W.C.

2. An adequate ventilation system is required for Commercial Cooking

Equipment. Information may be obtained by writing to the National

Fire Protection Association, Batterymarch Park, Quincy, MA 02269.

When writing refer to NFPA No. 96.

3. All models require a 6" (152 mm) clearance at both sides and rear

adjacent to combustible construction.

4. All models require a 6" (152 mm) minimum clearance to adjacent

open top burner units.

5. This appliance is manufactured for commercial installation only and

is not intended for home use.

SERVICE CONNECTIONS: (casters fully extended)

P1 11/4" NPT pipe gas connection, 9" above floor.

P2 11/4" NPT drain connection, 117/8" above floor.

P3 Two 3/4" garden hose watter connection 111/4" above floor.

E1 Two Electrical connection, 120/60/1, 181/2" above floor.
