WE-EF FLB141 #2 LED Bedienungsanleitung

Surge Protection

This product features built-in surge protection circuitry in compliance

with applicable standards.

For comprehensive protection of a luminaire installation against lightning

and electrical surges,it is essential to cover mains supply and data input

lines at the distribution board level,by using respective primary (Type 1)

and secondary (Type 2) surge arrestors in compliance with EN61643-11/

IEC61643-1.

Warning

Ensure that all required surge protection measures are in place and

activated prior to luminaire installation.Also,disconnect luminaires

before operating high-power devices such as, for example,electrical

arc welders.

Do not open during installation

This product is factory-sealed.

Refer to the instructions contained

in this document for details.

WE-EF LIGHTING

Installation and Maintenance

Instructions

Floodlight

FLB141 #2 LED

Floodlight

FLB141 #2

IP66, IK08. Class I. ta = 40°C

Weight lb

for FLB141 #2 LED 8.4

Windage area ftə2

for FLB141 #2 LED 0.545

Orientation: all directions

Light Source

LED

Maintenance

Apart from cleaning the product’s exterior surfaces,no special maintenance work is required.

Do not use high-pressure cleaners.

In case of component failure due to abnormal circumstances or at end of life, replacement must be carried

RXWE\DVXLWDEO\TXDOLĥHGDQGWUDLQHGSURIHVVLRQDO

Warning: Do not open luminaire while mains supply is switched on.

Installation

The product must be installed and maintained by a VXLWDEO\TXDOLĥHGSURIHVVLRQDOLQFRPSOLDQFHZLWKODWHVW

building/construction and/or electrical regulations and relevant legislation.

Warning: 6ZLWFKRĪPDLQVHOHFWULFDOVXSSO\SULRUWRLQVWDOOLQJDQGFRQQHFWLQJWKHOXPLQDLUH

Notice:,IWKHOXPLQDLUHLVPRGLĥHGE\DQ\ERG\RWKHUWKDQWKHRULJLQDOPDQXIDFWXUHUWKHQWKHZDUUDQW\ZLOO

no longer be valid and shall become the full responsibility of the modifying person/organisation.Claims

based on defects attributable to improper installation and/or application, and the consequences thereof,

are excluded.

The installation on site must comply with local and/or national health and safety regulations.

Important: When mounting luminaires on concrete or surfaces containing limestone content, WE-EF

recommends using mounting accessories – a short post or a ground spike to prevent galvanic corrosion.

In areas where mounting accessories are not applicable, ensure the luminaire’s aluminium base is separated

from concrete and limestone using a plastic or rubber sheet. Allow concrete to cure before installation –

DO NOT INSTALL ON WET CONCRETE!

Handling:(QVXUHWKHPRXQWLQJĦDQJHSODWHVDUH

handled with care,scratches and damage to the coated surface can result in galvanic corrosion.

A WE-EF warranty does not cover any adverse reaction or damage,due to improper installation and

requests that our recommendations are followed.

 6ZLWFKRĪPDLQVHOHFWULFDOVXSSO\

Installation Procedure

 6HSDUDWHPRXQWLQJĦDQJHAfrom junction box

mounting plate Hby removing fasteners D.

Mount plate over junction box with mains

supply cable G.

Warning: Ensure not to damage any electrical

cable, water pipe or other items during

installation.

 5HPRYHPRXQWLQJĦDQJHAby loosening

screws B.

2) Check that rating shown on luminaire label

conforms with mains electrical supply.

(example)

FLB141-LED 120-277V / 60Hz

161-XXXX SOE XXXXXXX

LED 3000K 18W item no.XXX

07/18 IP66

5) Feed mains supply cable Gthrough the

junction box mounting plate I,while setting

PRXQWLQJĦDQJHALQSRVLWLRQ7Rĥ[PRXQWLQJ

ĦDQJHA, insert and tighten screws D.

7) Loosen screws Mslightly.Aim luminaire in

desired direction, retighten screws M.

6) Ensure that all surface are clean and dry.

3RVLWLRQOXPLQDLUHRYHUPRXQWLQJĦDQJHA

and make electrical connections (L= Phase,

N = Neutral,G = Ground, D+/Dŝ= 0-10 V) C.

Turn luminaire towards object to be illuminated.

Tighten screw B.

www.we-ef.com

WE-EF LIGHTING

United States of America

Tel +1 724 742 0030

Fax +1 724 742 0035

[email protected]

TO9249W0522 © WE-EF 2022

Technical specifications are

subject to change.
