Whirlpool 8280527 Bedienungsanleitung

A Note to You ................2

Dryer Safety ..................3

Parts and Features........5

Checking Your Vent ......6

Using Your Dryer ..........8

Starting your dryer........8

Loading ......................10

Selecting a cycle

and temperature

setting ........................10

Cycle descriptions ....11

Fluff Air cycle ............13

Using the drying

rack ............................14

Caring for Your Dryer..15

Troubleshooting ..........18

Assistance

or Service ....................20

Warranty ......................24

1-800-461-5681

Call us with questions or comments.

8280527

Electric and

Gas Dryers

www.whirlpool.com/canada

A NOTE TO YOU

Thank you for buying a WHIRLPOOL*appliance.

The Whirlpool Brand is committed to designing quality products that consistently perform for you to make your

life easier. To ensure that you enjoy years of trouble-free operation, we developed this Use and Care Guide. It is

full of valuable information about how to operate and maintain your appliance properly and safely. Please read

it carefully.

Also, complete and mail the Ownership Registration Card provided with your appliance. The card helps us

notify you about any new information on your appliance.

Please record your model’s information.

Whenever you call to request service for your

appliance, you need to know your complete model

number and serial number. You can find this informa-

tion on the model and serial number label/plate (see

diagram in the “Parts and Features” section).

Please also record the purchase date of your appliance

and your dealer’s name, address, and telephone number.

Keep this book and the sales slip together in a safe place for future reference.

The Consumer Relations Center number is toll-free.

Model Number ________________________________

Serial Number __________________________________

Purchase Date ________________________________

Dealer Name __________________________________

Dealer Address ________________________________

Dealer Phone __________________________________

1-800-461-5681

To find detailed product information, the location of the nearest Whirlpool dealer or designated servicer, to

purchase an accessory item, or register your appliance on-line, please visit our Web site at

www.whirlpool.com/canada

DRYER SAFETY

You will be killed or seriously injured if you don’t

follow instructions.

You can be killed or seriously injured if you don’t

follow instructions.

Your safety and the safety of others is very important.

We have provided many important safety messages in this manual and on your appliance. Always read and

obey all safety messages.

This is the safety alert symbol.

This symbol alerts you to hazards that can kill or hurt you and others.

All safety messages will be preceded by the safety alert symbol and the word “DANGER” or

“WARNING”. These words mean:

wDANGER

wWARNING

All safety messages will identify the hazard, tell you how to reduce the chance of injury, and tell you what can

happen if the instructions are not followed.

WARNING: For your safety the information in this manual must be followed to

minimize the risk of fire or explosion or to prevent property damage, personal

injury or death.

– Do not store or use gasoline or other flammable vapors and liquids in the vicinity

of this or any other appliance.

– WHAT TO DO IF YOU SMELL GAS

•Do not try to light any appliance.

•Do not touch any electrical switch; do not use any phone in your building.

•Clear the room, building or area of all occupants.

•Immediately call your gas supplier from a neighbor’s phone.

Follow the gas supplier’s instructions.

•If you cannot reach your gas supplier, call the fire department.

– Installation and service must be performed by a qualified installer, service agency

or the gas supplier.

continued on next page

WARNING: To reduce the risk of fire, electric shock, or injury to persons when using the

dryer, follow basic precautions, including the following:

•Read all instructions before using

the dryer.

•Do not place items exposed to cooking

oils in your dryer. Items contaminated

with cooking oils may contribute to a

chemical reaction that could cause a

load to catch fire.

•Do not dry articles that have been

previously cleaned in, washed in, soaked

in, or spotted with gasoline, dry-cleaning

solvents, other flammable, or explosive

substances as they give off vapors that

could ignite or explode.

•Do not allow children to play on or in

the dryer. Close supervision of children

is necessary when the dryer is used

near children.

•Before the dryer is removed from service

or discarded, remove the door to the

drying compartment.

•Do not reach into the dryer if the drum

is moving.

•Do not install or store the dryer where

it will be exposed to the weather.

•Do not tamper with controls.

SAVE THESE INSTRUCTIONS

IMPORTANT SAFETY INSTRUCTIONS

•Do not repair or replace any part of the

dryer or attempt any servicing unless

specifically recommended in this Use and

Care Guide or in published user-repair

instructions that you understand and

have the skills to carry out.

•Do not use fabric softeners or products

to eliminate static unless recommended

by the manufacturer of the fabric softener

or product.

•Do not use heat to dry articles containing

foam rubber or similarly textured rubber-

like materials.

•Clean lint screen before or after each

load.

•Keep area around the exhaust opening

and adjacent surrounding areas free from

the accumulation of lint, dust, and dirt.

•The interior of the dryer and exhaust vent

should be cleaned periodically by

qualified service personnel.

•See Installation Instructions for grounding

requirements.

DRYER SAFETY

LARGE CAPACITYLARGE CAPACITY

3 CYCLE 3 TEMP3CYCLE 3TEMP

AUTOMATICDRY MISERAUTOMATICDRY MISER

ENERGYEFFICIENTENERGYEFFICIENT

OFFOFF

TUMBLEPRESSTUMBLEPRESS

DAMPDRYDAMPDRY

AUTOMATICAUTOMATIC

PERMANENT

PRESSPRESS

HEAVY DUTYHEAVY DUTY

OFFOFF

OFF

COOLDOWNCOOLDOWN

LESSDRYLESSDRY

VERYDRYVERYDRY

LESSDRYLESSDRY

TIMED DRYINGTIMED DRYING

AUTOMATICAUTOMATIC

REGULAR

PUSH TO STARTPUSH TO START

TEMPERATURE SELECTORTEMPERATURE SELECTOR

FLUFFFLUFF

AIR PERM'TPERM'T

PRESSPRESS

HEAVY

HIGH

GENTLEGENTLE

LOWLOW

FABRICFABRIC

TEMPTEMP

KNITSKNITS

PARTS AND FEATURES

The drawings in this book may vary from your dryer model. They are designed to show the

different features of all models covered by this book. Your model may not include all features.

Small side-swing door†

Large side-swing door†

(Reversible door – see Installation

Instructions)

Other doors: Additional features your dryer may have:

End of cycle signal selector (p. 9)

FINISH GUARD* selector (p. 9)

FINISH GUARD* Plus selector (p. 9)

ACCUDRY* electronic sensor (p. 11)

DRY MISER* automatic sensor (p. 11)

Drying rack (p. 14)

Lint signal (p. 16)

Drum light (p. 17)

†On some models

Cycle control

knob

(pp. 8-13)

Model and

serial number

label

(p. 2)

Dryer drum

(p. 16) Wide-opening

hamper door†

Exhaust grill

(p. 18)

Start button

(p. 9)

Lint screen

(p. 15)

Super wide-opening door†

(Reversible door – see Installation

Instructions)

Temperature selector†

(p. 8)

CHECKING YOUR VENT

If the dryer is not properly installed and vented, it will

not be covered under the warranty.

NOTE: Service calls caused by improper venting will

be paid for by the customer, whether it was a paid

installation or self-installed. For paid installation, call

the company that installed the vent for adjustment.

1. Do not use plastic vent or flexible metal foil vent.

Use 4 in (10.16 cm)

heavy metal or flexible

metal vent. Do not kink

or crush flexible metal

vent. It must be

completely extended to

allow adequate exhaust

air to flow. Check vent

after installation. Refer

to your Installation

Instructions for proper

length requirements of vent.

3. The exhaust vent can be routed up, down, left,

right, or straight out the

back of the dryer. Space

requirements are listed

in your Installation

Instructions.

2. Use a 4 in (10.16 cm) exhaust hood. Smaller

hoods increase drying

times.

wWARNING

Fire Hazard

Use a heavy metal vent.

Do not use a plastic vent.

Do not use a metal foil vent.

Failure to follow these instructions can

result in death or fire.

Your dryer must be properly installed and vented to achieve maximum drying efficiency and

shorten drying times. Use the minimum recommended installation clearances (found in your

Installation Instructions) to avoid blocking the flow of combustion and ventilation air. Install

your dryer in a well-ventilated room where the temperature is always above 45ºF (7ºC). Also

make sure that your dryer is leveled. Refer to your installation Instructions for more

information.

4 in

(10.16 cm)

4 in

(10.16 cm)

4 in

(10.16 cm)

CHECKING YOUR VENT

VENTING (CONT.)

6. Clean exhaust vent periodically, depending on use,

but at least every 2

years, or when installing

your dryer in a new

location.

•Disconnect vent from

the dryer and clean one

section at a time until

you reach the exhaust

hood.

•Use the hose attach-

ment on your vacuum,

or a pole or wire with a feather duster or rag

attached, to clean out lint.

•Be sure the flapper on the outside end of vent

moves freely.

•When cleaning is complete, be sure to follow the

Installation Instructions supplied with your dryer

for final product check.

4. Use the straightest path possible when routing

the exhaust vent. Use

the fewest number of

elbows and turns. Allow

room when using

elbows or making turns.

Bend vent gradually to

avoid kinking.

5. Use duct tape to seal all joints. Do not use

screws to secure vent.

Lint may catch on

screws.

Before using your dryer, wipe the dryer drum with

a damp cloth to remove dust from storing and

shipping.

1. Load clothes loosely into the dryer and close

the door. Do not pack

the dryer; allow space

for clothes to tumble

freely.

2. Turn the Cycle Control knob to the recom-

mended cycle for the

type of load being dried.

•Use the Energy

Preferred Automatic

Setting (*) to dry

most loads.

NOTE: On some

models, the Tempera-

ture selector is part of

the Cycle Control knob.

3. If your dryer has a Temperature selector, set it to

the recommended setting for the type of fabric

being dried. The cycle descriptions on the

following pages include temperature setting

suggestions.

USING YOUR DRYER

STARTING YOUR DRYER

wWARNING

Explosion Hazard

Keep flammable materials and vapors,

such as gasoline, away from dryer.

Do not dry anything that has ever had

anything flammable on it (even after

washing).

Failure to follow these instructions can

result in death, explosion, or fire.

wWARNING

Fire Hazard

No washer can completely remove oil.

Do not dry anything that has ever had any

type of oil on it (including cooking oils).

Items containing foam, rubber, or plastic

must be dried on a clothesline or by using an

Air Cycle.

Failure to follow these instructions can result

in death or fire.

4. (OPTIONAL STEP) Some dryers have an On/Off

FINISH GUARD®selector, or an Off/30 min. or

90 min. FINISH GUARD®Plus selector. These

features protect your clothes from wrinkling when

you do not remove them from the dryer as soon

as it stops.

•Set the FINISH GUARD selector to On to

tumble the load without heat every few minutes

up to 45 minutes after the drying cycle ends.

•The FINISH GUARD Plus selector lets you

choose up to 30 or 90 minutes of periodic

unheated tumble time after the drying cycle

ends.

•A signal will sound every few minutes while

FINISH GUARD (FINISH GUARD Plus) is

running if the Cycle Signal (End of Cycle

Signal) feature is set to On. The signal and

cycle end when you open the dryer door.

•Set the FINISH GUARD (FINISH GUARD Plus)

selector to Off if you do not want to run this

feature.

NOTE: Some dryers have a FINISH GUARD feature

that cannot be turned On or Off. See page 13.

5. (OPTIONAL STEP) If your dryer has a Cycle

Signal (End of Cycle Signal) selector, set the

selector to On if you want the dryer to sound

a signal when a cycle is finished.

•The signal is helpful when you are drying

permanent press, synthetics, and other items

that should be removed from the dryer as

soon as it stops.

•On some models, the End of Cycle Signal is

part of the Start (Push to Start) button.

•On some models, the signal volume can be

adjusted from Softer to Louder.

6. Push the Start (Push to Start) button.

NOTE: Your dryer stops automatically when a

cycle ends.

Stopping and restarting your dryer

You can stop your dryer anytime during a cycle.

To stop your dryer:

Open the dryer door or turn the Cycle Control knob

to Off.

NOTE: The Cycle Control knob should point to an

Off area when the dryer is not in use.

To restart your dryer:

Close the door, select a new cycle and temperature

(if desired), and push the Start (Push to Start)

button.

USING YOUR DRYER

SELECTING A CYCLE AND TEMPERATURE SETTING

The following pages describe the drying cycles

on your dryer. The descriptions include suggested

temperature settings and drying times for various

loads.

Cycle and temperature tips

•Make sure you have selected the correct cycle

and temperature for your load.

•Dry most loads using the Energy Preferred

Automatic Setting (*).

•Use an air cycle (or temperature setting), or line

dry rubber, plastic, delicate, and heat-sensitive

fabrics.

•If some types of loads in the cycle descriptions

on the following pages have more than one

suggested temperature setting, choose the

lowest setting available on your dryer.

•The last few minutes of all cycles are without

heat to make the load cooler to handle.

Drying tips

•Always follow care label directions when they are

available.

•If you use fabric softener sheets, always use soft-

ener sheets that are labeled as dryer safe and fol-

low package instructions carefully.

•Remove the load from the dryer as soon as

tumbling stops to reduce wrinkling. This is

especially important for permanent press, knits,

and synthetic fabrics.

Loading suggestions

The chart below provides some guidelines on various types of drying loads. Load clothes loosely into the

dryer. Do not pack the dryer; allow space for clothes to tumble freely.

Heavy Work Clothes

3 pair pants

3 shirts

4 pair jeans

1 coverall

1 overall

Towels

10 bath towels

10 hand towels

14 wash cloths

1 bath mat

Mixed Load

3 double sheets

4 pillowcases

8 T-shirts

6 pair shorts

2 shirts

2 blouses

8 handkerchiefs

Delicates

3 camisoles

1 quilted robe

4 slips

4 panties

2 bras

2 nighties

1 baby’s dress

Inhaltsverzeichnis

Sprachen:

Andere Whirlpool Trockner Handbücher

Whirlpool

Whirlpool LI._7681XM Bedienungsanleitung

Whirlpool

Whirlpool L0412123 Bedienungsanleitung

Whirlpool

Whirlpool W10858726A Bedienungsanleitung

Whirlpool

Whirlpool 3XLEC8647 Bedienungsanleitung

Whirlpool

Whirlpool LE6800XS Bedienungsanleitung

Whirlpool

Whirlpool WED7500G Bedienungsanleitung

Whirlpool

Whirlpool LE7680XS Bedienungsanleitung

Whirlpool

Whirlpool YWED92HEFC2 Bedienungsanleitung

Whirlpool

Whirlpool WED9400SB - 27" Electric Dryer Bedienungsanleitung

Whirlpool

Whirlpool LE5750XK Bedienungsanleitung

Whirlpool

Whirlpool MEDB955FW Bedienungsanleitung

Whirlpool

Whirlpool FFT M22 9X2B UK Bedienungsanleitung

Whirlpool

Whirlpool WGD8800YC Bedienungsanleitung

Whirlpool

Whirlpool AWG 367 Bedienungsanleitung

Whirlpool

Whirlpool AWZ10CDS/PRO Installationsanleitung

Whirlpool

Whirlpool Duet Steam WED9270X Bedienungsanleitung

Whirlpool

Whirlpool Duet Sport W10151581A Bedienungsanleitung

Whirlpool

Whirlpool Exhausting Dryers Bedienungsanleitung

Whirlpool

Whirlpool 3HLER5437JQ0 Bedienungsanleitung

Whirlpool

Whirlpool YWED9500E Bedienungsanleitung

Whirlpool

Whirlpool LE5790XS Bedienungsanleitung

Whirlpool

Whirlpool W10529641A Bedienungsanleitung

Whirlpool

Whirlpool CSP2760TQ2 Bedienungsanleitung

Whirlpool

Whirlpool WED5800BC Bedienungsanleitung

Beliebte Trockner Handbücher anderer Marken

Bosch

Bosch WTA79200GB Bedienungsanleitung

Amana

Amana W10233410A Bedienungsanleitung

Miele

Miele TWH 780 WP Bedienungsanleitung

Asko

Asko T760 Bedienungsanleitung

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Bedienungsanleitung

Bosch

Bosch Logixx 10 WTB76556GB Technisches Datenblatt

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Bedienungsanleitung

Electrolux

Electrolux EW2H328R2 Bedienungsanleitung

Beko

Beko DS8433RX1M Bedienungsanleitung

Dawlance

Dawlance Spinner DS 6000 C Bedienungsanleitung

Electrolux

Electrolux TP5080TW Bedienungsanleitung

AEG

AEG TR838P4OB Bedienungsanleitung

Indesit

Indesit IDV 75 Bedienungsanleitung

Infiniton

Infiniton SD-DG85C Bedienungsanleitung

BOMANN

BOMANN WT 5019 Bedienungsanleitung

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Bedienungsanleitung

Asko

Asko T793C Bedienungsanleitung

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Bedienungsanleitung
