Installation Guide

PRO 710i

Industrial Class In-Building Cell Signal Ampliﬁer

Supporting Band 71 (600MHz)

Package Contents 1

About The Pro 710i 2

Key Features 4

Post Install Setup 5

Menu System 7

Safety Guidelines 11

Warranty 13

Index

PRO 710i INDUSTRIAL CLASS IN-BUILDING CELL SIGNAL AMPLIFIER

Package Contents

Pro 710i

Kit 460064

INDUSTRIAL CLASS IN-BUILDING CELL SIGNAL AMPLIFIER PRO 710i

Up to +25 dBm uplink power and 85

dB gain for maintaining connections

with far-away cell towers

Up to +25 dBm downlink

power for improved indoor cell

coverage area

Color touch screen, for easy

installation and displaying detailed

ampliﬁer status

eXtended Dynamic Range (XDR)

for Continuous Connectivity

Industrial Class In-Building Cell Signal Ampliﬁer

Supporting Band 71 (600MHz)

Pro 710i

PRO 710i INDUSTRIAL CLASS IN-BUILDING CELL SIGNAL AMPLIFIER

The Pro 710i industrial class, in-building, cell

signal ampliﬁer provides signiﬁcantly enhanced

band 71 (600MHz) signal strength, supporting

4G LTE and 5G technology. The Pro 710i can

be installed as either a “stand-alone” ampliﬁer

providing exclusive band 71 ampliﬁcation, or

it can be combined with a new or existing

WilsonPro ampliﬁer system, supporting multiple

bands. Because the Pro 710i is an industrial

class ampliﬁer, local band 71 carrier approval

must be obatined for every installation.

The Pro 710i also incorporates Wilson Electronics’ state-of-the-art XDR (eXtended

Dynamic Range) technology that prevents signal overload conditions which can, in

accordance with regulations, force the ampliﬁer to shut down. When the Pro 710i

senses that any incoming cell signal is too strong and threatens to overload the

system, XDR automatically reduces ampliﬁer gain to compensate while maintaining

signal coverage throughout the building. The Pro 710i incorporates an easy-to-use

color LCD touch screen, and both antenna ports are located on the top of the unit for

simple installation. Like all WilsonPro cell signal boosters, the Pro 710i ampliﬁer system

is universal: it works for all cellular devices, all services and all U.S. and Canada cell

phone carriers using band 71 (600MHz).

INDUSTRIAL CLASS IN-BUILDING CELL SIGNAL AMPLIFIER PRO 710i

Industrial Class Ampliﬁcation: Up to 100,000 sq. ft. of band 71

(600MHz) coverage with a single ampliﬁer (local carrier approval

required for each installation).

Extended Dynamic Range (XDR) for continuous connectivity:

XDR lets the Pro 710i system work with an incoming signal and

never shuts down due to a strong outside signal.

Onboard Software for Better Control: The ampliﬁer is

automatically controlled with automatic onboard software,

ensuring great connectivity throughout large spaces and multi-

story buildings. The ampliﬁer will adjust its gain level up or down

as required by the conditions of the immediate signal environment.

Color LCD Touch Screen: The Pro 710i utilizes a color LCD

touch screen, for assessing ampliﬁer performance, making

adjustments to the outside antenna, and turning bands on and o.

Key

Features

PRO 710i INDUSTRIAL CLASS IN-BUILDING CELL SIGNAL AMPLIFIER

The Pro 710i is designed with advanced internal programming, which allows it to

automatically adjust for a variety of conditions, while still amplifying weak signals.

Once the antenna cables are connected, turn the unit on by connecting the

power supply cord, at the bottom.

hand tighten ONLY

Inside Antenna

Outside Antenna

power supply

with locking feature

slot for installer

business card

Post Install

Setup

INDUSTRIAL CLASS IN-BUILDING CELL SIGNAL AMPLIFIER PRO 710i

PRO 710i

ENTERPRISE 1300

Stand-alone installation, providing cell coverage for band 71 only.

Pro710i and Enterprise 1300 (Common Mode) combined.

A Wilson Lightning Surge Protector is recommended for all building installations. Make

sure the protector is installed outside the building. Connect it to suitable ground and in

line, between the Outside Antenna and the Signal Ampliﬁer.

Combiner

Inside Dome

Antenna

Inside Dome

Antenna

Band 71, 600 MHz

Cell Tower

Band 71, 600 MHz

Cell Tower

Outside Antennas

Outside Antenna

Bands 4/5/12/13/25

Cell Tower

Installation

Diagram

Combined

Stand Alone

PRO 710i INDUSTRIAL CLASS IN-BUILDING CELL SIGNAL AMPLIFIER

The Pro 710i takes about 5 seconds to boot up. Once boot up is complete, the home

screen will appear, showing the ampliﬁcation and status of each port and band.

A solid green color indicates that a band

is operating correctly with maximum

allowable gain.

A solid yellow color indicates band gain

reduction because of an oscillation

condition. Reposition antennas (increase

separation between indoor and outdoor

antennas, and point in opposite directions)

and then reboot (turn the unit o & on)

the Pro 710i to reactivate the band and

maximize performance. When adequate

separation is achieved, the yellow color

will return to green upon reboot.

Note: when the colro is yellow, the band

is operational; however, performance

is reduced.

Start Up Screen

Band Menu Color Description

Menu System

INDUSTRIAL CLASS IN-BUILDING CELL SIGNAL AMPLIFIER PRO 710i

A red color indicates a band has

been shut down because of a severe

oscillation condition or repeated

oscillation. Reposition antennas

(increase separation between indoor and

outdoor antennas, and point in opposite

directions) and then reboot (turn the unit

o & on) the Pro 710i to reactivate the

band and maximize performance. When

adequate separation is achieved, the red

color will return to green upon reboot.

(MENU SYSTEM cont.)
