Winix NK300 Bedienungsanleitung

WINIX AIR CLEANE

NK300

User Manual

xPlease read and follow all safety rules and instructions in

this manual before operating.

xThe product warranty is printed on the back of this guide,

so please keep it in a safe place for future use.

Model

Use & Care

Guide

English

NK300

CONTENTS

Set Up

Where to use 5

Filter Anatomy 7

Installing the filters 8

Safety Instructions

Safety and Cautions 10

Operation

Initial Operation 11

Modes of Operation 12

Features and Settings 13

Care and Maintenance

Filter Care 15

Cleaning Care 19

Troubleshooting

Frequently Asked Questions 20

Unit Specifications 22

Product Warranty 23

XThis product is suitable for 220-240V only.

4-Stage Air Purification 3

Controls 4

French 25

Spanish 49

German 73

Italian 97

Dutch 121

English

NK300

VOC Smart Sensor

PACKAGE CONTENTS

Back panel Power cord with plug(This product is suitable for 220-240V only.)360o All-in-One True HEPA Filter➊ Pre-Filter➋ True HEPA➌ CD Carbon Filter➍ PlasmaWave󳜅4-STAGE AIR PURIFICATION

Unit360

All-in-One True HEPA FilterUser Manual

63

=[MZ5IV]IT

Model ・8TMI[MZMILIVLNWTTW_ITT[INM\aZ]TM[IVLQV[\Z]K\QWV[QV\PQ[

UIV]ITJMNWZMWXMZI\QVO

・<PMXZWL]K\_IZZIV\aQ[XZQV\MLWV\PMJIKSWN\PQ[O]QLM[W

XTMI[MSMMXQ\QVI[INMXTIKMNWZN]\]ZM][M

・<PQ[XZWL]K\Q[UIV]NIK\]ZMLNWZ][MWVTaQV=;)+)

Use&

Care

Guide

WINIX AIR CLEANE

Power cord with plug

English

NK300

CONTROLS

Reset ButtonAfter replacing a filter, press the RESET button for at least 5 seconds.PlasmaWave󳜅 Indicator Indicates whether PlasmaWave󳜅 is enabled or disabled.Mode Button - Press to cycle through manual fan speeds (Low, Medium, High, Turbo). - Pressing will also cycle through Auto and Sleep Modes. - When sleep mode is selected the Air Quality Indicator light will be turned off. - Press and hold for at least 3 seconds to enable or disable PlasmaWave󳜅.Power ButtonTurns the unit on or off.

Light SensorDetects the amount of ambient light within the environment, to adjust the brightness of the LED indicators.Child Lock ButtonPress and hold for 3 seconds to enable or disable the Child Lock mode.

Change Filter Indicator LED light indicates when it is time to change the filter.Air Quality Indicator

Color-coded LED indicates one of three levels of air quality.

Air Outlet Vent

English

NK300

WARNING Follow these instructions to reduce the risk of serious

injury or death and to reduce risk of damaging the unit.

WHERE TO USE

Do not use around mist or fumes from

industrial oil or around large quantities of

metallic dust

Do not install in any sort of motor or

transport vehicle (trucks, boats, ships, etc.)

Do not place near any flammable materials

(aerosols, fuel, gases etc.)

Do not place below any electrical outlet

Do not place around heating elements

Do not place in an area with excessive

amounts of noxious gases

Do not have unit facing into wind or draft

Do not place in excessively humid areas

where unit may become wet

Allow 30-45 cm. of space between TVs, radios, and other electronic products

electromagnetic interference from certain electronics may cause product malfunction.

Place indoors away from direct sun light

direct exposure may cause product malfunction or failure.

Only place on hard, flat surfaces

flimsy or slanted surfaces may result in abnormal noise and vibrations.

ÚThis unit is not intended to be used to preserve documents or in art conservation.

30~45 cm

English

NK300

360o All-in-One True HEPA Filter

➊ Pre-Filter➋ True HEPA➌ CD Carbon Filter

English

NK300

360o All-in-One True HEPA Filter ANATOMY➊ Pre-Filter➋ True HEPA➌ CD Carbon Filter➊ Pre-Filter designed to catch larger airborne particles found indoors.➋ True HEPA captures 99.97%* of airborne allergens including; pollen, Mould spores, dust, pet dander, microbes, and smoke. *particles as small as 0.3 microns in size➌ CD Carbon Filter reduces VOCs and household Odours from cooking, pets, and smoke.• The 360o All-in-One True HEPA Filter is one unit and the individual components of the filter cannot be purchased separately.Note

English

NK300

INSTALLING FILTERS

This product comes with all required filters. The protective plastic wrap must be removed from the filter before use.※ Operating the unit without removing the plastic wrap may result in product failure.※ Unplug and make sure the unit is turned off before installing filter.

③ Remove the 360

All-in-One True HEPA filter from the unit. Remove the plastic wrap from the filter. • Operating the unit without removing filters from plastic wrap may cause abnormal noise, deformation, or fire as a result of overheating.

② Once the back panel is removed, grasp the handle near the bottom of the unit, and pull towards yourself to lower and release the filter.① Remove the back panel by grasping handle and pulling back, towards yourself.

Latch• Refer to pages 17 - 19 for details on how to replace filters. Note

English

NK300

※ Intervals between filter replacement may vary depending on environment. ※ For optimal use, the filter can be cleaned once every 14 days.※ To clean the filter, vacuum the outside of the filter with a soft brush.※ THIS FILTER CANNOT BE WASHED④ Install the filter, top side up, into the unit until it is fully inserted. Grasp lower handle near bottom of the unit and push in until the filter locks into place. •

The top of the filter shows the opening into the filter. Whereas the bottom is solid, with no opening.

•

When installing the filter you will know it is fully inserted because it will no longer be able to be pushed further.

⑤ Replace the back panel by first inserting the latch at the bottom edge into the base of the unit, then rotate the panel upward toward the top of the unit until the panel snaps into the unit.

⑥ When to service and replace filter:

Latch

Filter Indicator Light When to

service

When to replace

360󱈀All-in-OneTrueHEPAFilterClean once

every 14 days

Lasts up to

12 months

To purchase replacement

Winix filters:

contact your local dealer

INSTALLING FILTERS

this unit

is compatible

with this

filter

FILTER

item: 112180

English

NK300

SAFETY AND CAUTIONS

Before operating this equipment, carefully read and follow these safety cautions

WARNING Follow these instructions to reduce the risk of serious

injury or death and to reduce risk of damaging the unit.

Ensure filter is inserted before running unit

running unit without the filter can shorten the units life and cause electric shock or injury.

Be sure foreign objects are NOT inserted into the vents on the unit

objects can include pins, rods, and coins.

Do not touch any part of the interior of the unit with wet hands

the high voltage may cause electric shock.

Ensure unit intake and outlet vents do not become blocked

blockage may lead to increased internal termperatures causing product failure and derformation.

Do not use the unit as a step stool or place heavy objects on it

personal injury may occur or product failure and deformation.

Do not pull on the power cord when

unplugging the unit

Do not touch the plug with wet hands

Do not plug additional appliances into the

same outlet or power supply

Unplug unit when not in operation for

extended periods of time

Do not tie or knot power cord when unit

is in operation

Do not unplug or move the unit while in

operation

If the unit becomes submerged in water,

unplug it and contact customer service

Cord can become damaged by forcefully

bending, pulling, twisting, bundling,

pinching or placing heavy objects on it

ÚIf the supply cord is damaged, it must be replaced by a special cord or assembly

available from the manufacturer or its service agent.

ÚThis appliance is not intended for use by a person (including children) with reduced

physical sensory or mental capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction concerning use of the appliance by

a person responsible for their safety.

ÚChildren should be supervised to ensure that they do not play with the appliance.
