Work Smart DC2990V Bedienungsanleitung

DC2990/DC2990V

PNEUMATIC DRAFTING CHAIR

OPERATING INSTRUCTIONS

LIMITED WarranTy

Work Smart chairs are warranted from the date of purchase against failure due to material and workmanship as follows:

• 15 Years on all non-moving metal parts.

• 5 Years on component parts including Control mechanisms, pneumatic cylinders, wood, plastic parts, base and casters.

• 3 Years on upholstery fabric and foam against wear and deterioration.

To make a warranty claim, contact Parts Department. Provide model number, proof of purchase, description of the problem and

obtain return authorization. At it’s option Ofﬁce Star Products will:

(a) Supply compatible components of current manufacture.

(b) Repair the customer’s component. The customer must prepay freight on any components returned to the factory. Return

freight on components still in warranty will be paid by Ofﬁce Star Products.

*All warranties are limited to the original purchaser for normal commercial usage deﬁned as a standard forty hour work week by persons weighing 250 lbs. or

less. This warranty will not cover labor, freight or damage from misuse, abuse, negligence, alteration, accident, vandalism, rusting, acts of nature or any other

event beyond the control of Ofﬁce Star Products. The warranty does not cover cosmetic damage that may result from normal use. Liability for incidental or

consequential damages is excluded. The user assumes all risk of injury resulting from use of this product. When usage is more than 40 hours per week, a two

year warranty on all parts applies. Fabric and foam is warranted for one year. This warranty gives you speciﬁc legal rights, and you may also have other rights

which vary from state to state.

Our quality standards are among the highest in the industry. Sometimes, no matter how hard we try, there are times when parts

are damaged or missing. Our Parts Department will do everything possible to promptly remedy the problem. Contact us via e-mail

parts@ofﬁcestar.net, by Fax 1-909-930-5629, or toll free parts number 1-800-950-7262, Monday through Friday 8:00 a.m. - 5:00

p.m. Paciﬁc Time.

WarnInG

1. Use this product only one person at a time.

2. Do not use this chair unless all bolts screws and

knobs are securely tightened.

3. Check that all bolts screws and knobs are tight every

three months or as needed.

4. Dispose of packing material properly. Do not use

plastic cover as head covering. It may cause

suffocation.

5. Do not use chair as a stepladder.

6. Use this chair for its intended purpose only.

7. Use mild detergent only for cleaning.

FEaTUrE

• PNEUMATIC SEAT HEIGHT ADJUSTMENT

To raise seat remove pressure from seat and lift lever (1) up. To

lower seat height sit on chair and lift lever (1) up.

• FOOTRING HEIGHT ADJUSTMENT

To adjust footring height, loosen knob (2) adjust footring to

desired height, and tighten knob (2) completely to secure

footring into position.

DC2990/DC2990V

PNEUMATIC DRAFTING CHAIR

ASSEMBLY INSTRUCTIONS

PART QTY

1. Base .......................1

2. Casters .....................5

3. Pneumatic Cylinder . . . . . . . . . . . . 1

4. Bellows .....................1

5. Seat Plate ...................1

6. Seat Cushion . . . . . . . . . . . . . . . . . 1

7. Back Assembly . . . . . . . . . . . . . . . 1

8. Footring .....................1

9. Screws ......................6

10. Small Adjustment Knob . . . . . . . . 1

11. Large Adjustment Knob . . . . . . . . 1

12. Star Washer .................1

13. Flat Washer .................1

14. Back Support . . . . . . . . . . . . . . . . 1

15. Allen Wrench (not shown) . . . . . . 1

Remove all parts from carton, separate by part numbers indicated on parts list, and verify part quantities.

STEP 1 Insert ﬁve Casters (2) into Base (1), push hard until you feel or hear the Caster (2) snap into place. Slide Pneumatic Cylinder (3) through

Footring (8) and into Base (1), slip Bellows (4) over Pneumatic Cylinder (3).

STEP 1 Attach Seat Plate (5) to Seat Cushion (6) using six Screws (9), FULLY TIGHTEN ALL SCREWS USING ALLEN WRENCH (15).

STEP 3 Attach Back Support (14) to rear of Seat Plate (5) using Large Adjustment Knob (10), one Star Washer (12) and one Flat Washer (13), attach

Back Assembly (7) to Back Support (14) using Small Adjustment Knob (10).

STEP 4 Place the assembled seat on top of Pneumatic Cylinder (3) and apply downward pressure.

ATTENTION: MAKE SURE ALL SCREWS ARE FULLY TIGHTENED BEFORE USING CHAIR.
