WowWee Robosapien X Handbuch

Using the Robosapien™ remote controller with Femisapien™

You cam use the WowWee™ Robosapien™ remote controller (included) to control

Femisapien.

Battery details

The remote controller requires 3 x “AAA” size batteries. To install the batteries, do

the following:

Open the battery compartment located on 1.

the underside of the remote controller using a

Phillips screwdriver (not included) to remove

the screws on the battery compartment cover.

Insert the batteries according to the diagram. 2.

Ensure that the positive and negative polarities

match the illustrations inside the battery

compartment.

Replace the battery compartment covers and 3.

replace the screws using the screwdriver. Do

not over-tighten.

Shift levels

The remote controller has 3 shift levels. You can change levels by pressing the

Select button SELECTSELECT. The LED on the remote controller indicates the shift level as

explained in Table 1, below.

Table 1

LED Color Shift level

Level 1

Green Level 2

Red Level 3

IMPORTANT: After you send a command the remote controller will reset to Shift

level 1. That is, if you require Shift level 2 or 3, you need to select the shift level each

time you send a command.

1.5V "AAA"

LR03 UM4

1.5V "AAA"

LR03 UM4

1.5V "AAA"

LR03 UM4

Battery

compartment

door

Remote controller overview

LED shift indicator

LED transmitter

Shift select

SWEEP

THUMP

SWEEP

THUMP

HIGH 5

SELECT

PICK UP

STRIKE 2

SLEEP

STRIKE 2

LISTEN

STRIKE

STRIKE 3

LEFT

DANCE

SONIC

RIGHT

STRIKE1

LEAN

STRIKE 1

LEAN

BURP

THROW

WHISTLE

THROW

TALKBACK

PICKUP

ALL DEMO

EXECUTE

POWER OFF

WAKE

SELECT

Remote controller functions

The control functions for each level are explained in the following table (Table 2).

NOTE: Right refers to Femisapien’s right and left refers to her left.

Table 2

Button Icon Shift level 1 Shift level 2 Shift level 3

1Right arm moves up

one stop.

Right arm moves

up.

2Left arm moves up

one stop.

Left arm moves

up.

3Right arm moves

down one stop.

Right arm moves

down.

4Left arm moves

down one stop.

Left arm moves

down.

5Right arm moves up,

left arm moves back.

Right arm moves

out, left arm

moves up.

6Left arm moves up,

right arm moves

back.

Left arm moves

out, right arm

moves up.

7Leans to the right,

one stop.

8Leans to the left, one

stop.

9Both arms move up. Leans forward.

10 Both arms move

down.

Leans backward.

11 Forward walk

(without avoidance).

Slow forward

walk with

avoidance.

Forward strut with

avoidance.

Button Icon Shift level 1 Shift level 2 Shift level 3

12 Clockwise pivot turn. Clockwise step

turn.

Forward, clockwise,

circular walk.

13 Stop. Stop. Stop

14 Counter-clockwise

pivot turn.

Counter-

clockwise step

turn.

Forward, counter-

clockwise, circular

walk.

15 Backward walk Backward walk Backward strut

with avoidance.

16 Turns the volume

down.

“Beep” routine.

17 “Are you talking

to me?” routine.

18 Turns the volume up. “Hey, look at

me!” routine.

19 Enters Learning

Mode.

NOTE: You do not

need to change

Femispien’s head

position.

20 Plays back the last

saved program.

To learn more about the functions, refer to the Femisapien user manual.
