Your EyeOne Pro

Thank you for purchasing an X-rite EyeOne Pro spectrophotometer from SpectraCal.

This page explains the parts you will find in your EyeOne Pro kit.

Meter and Base Plate

Each EyeOne Pro is uni uely paired with

its own base plate. They should remain

together. At the tip of the base plate is a

white dot, of reference material

conforming to a standard. Your EyeOne

was calibrated at the factory to this white

dot, and should you ever need to run

EyeOne Pro diagnostics, they will expect

this same dot.

Ambient Filter

The small black box contains the ambient filter. Note that

there are actually two pieces inside the black box: the filter

and a cap. The filter is inside the cap. To put it on your

EyeOne Pro, snap the cap on the meter head, rotate slightly,

and pull directly off. The filter will remain on the meter. Use

the filter when reading directly from a projector. You can use

the cap to perform a dark calibration

USB Cable

The EyeOne Pro draws a substantial amount of power, which some USB hubs and USB

extension cables will not supply. Before trying to use a hub or an extension cord, first

plug your EyeOne Pro directly into your computer.

Suspension Strap and Tripod Holder

The suspension strap is for hanging an EyeOne Pro on a display. For most applications,

we recommend the tripod holder instead. (The tripod holder is an optional accessory,

sold separately). Slide the two prongs on the tripod holder into the two holes on the

bottom of the EyeOne Pro, and wrap the Velcro strap around the EyeOne to secure it.

Empty Spaces in Carrying Case

You will note that the carrying case has empty spaces. In addition to its leading role as

the preferred instrument for video display calibration, the EyeOne Pro is sold into many

other industries as well. Some of these other applications re uire other accessories, and

rather than design a different carrying case for each industry, X-rite provides one case to

serve all.

Using t e EyeOne Pro wit CalMAN

1. Download and install the CalMAN Device Driver Kit

a. Browse to www.spectracal.com . From the navigation bar at the top of the

page, choose Downloads and select Other Downloads.

b. From the Downloads page, under "Other Resources," find Device Driver Kit,

and press the Download Now button. (You may need to answer security prompts

from your web browser to verify that you wish to download a file.)

c. Choose Run from the download prompt or double-click on

DeviceDriversV1.msi to install the device driver kit.

2. Plug the EyeOne Pro into a U B port in your system and install the driver.

When you plug in your EyeOne Pro, Windows will pop up a Found New

Hardware Wizard. Select the option, "Install from a list or specific location." Use

the Browse button to locate the directory where you installed the Device Driver

Kit, then select the i1Pro directory.

3. tart CalMAN and select the EyeOne Pro.

On the Select Meter page, choose the EyeOne Pro from the Meter drop-down list.

If you do not see the EyeOne Pro in the drop-down list, press the Refresh button.

The CD

CalMAN does not re uire the installation of any software from the CD in the

EyeOne Pro box.

Initializing the EyeOne Pro

Each time you start CalMAN, and after a period of continued use, you will be

asked to initialize the EyeOne Pro. Follow the on-screen prompts. The EyeOne

initialization is a dark calibration which depends on stopping light from entering

the head. Putting the EyeOne in its base plate will accomplish this; so will putting

the black cover on the ambient head.
