User’s Manual
XDSR380HD
Full HD
Digital Satellite Receiver
Please read this User’s Manual carefully before installing the receiver.
4
Index
INDEX ...................................................................................................4
Precautions.............................................................................................6
1. Important Safety Instructions ..........................................................6
2. Notice..............................................................................................6
3. Copyright ........................................................................................7
4. Disclaimer .......................................................................................7
5. Trademarks.....................................................................................7
Before You Begin ....................................................................................8
1. Main Features.................................................................................8
2. Accessories ....................................................................................9
Hardware Description...........................................................................10
1. Front Panel Conguration.............................................................10
2. Rear Panel Conguration ............................................................. 11
3. Remote Control Unit .....................................................................12
Connecting diagram.............................................................................14
1. Receiver to A/C power ..................................................................14
2. Receiver to TV with Digital A/V Output .........................................14
3. Receiver to TV with Analog A/V Output ........................................16
4. Connecting to Antenna Cable .......................................................16
5. Guide to mounting an STB on TV back panel (Optional)..............18
Guide of Functions ...............................................................................19
1. Selecting a Service .....................................................................19
1.1 Using CH UP/DOWN buttons .......................................................19
1.2 Using Service List .........................................................................19
1.3 Using Simple Service List .............................................................19
5
1.4 Using Recent Service List.............................................................20
2. Information Window ...................................................................20
3. Multi-Picture Display...................................................................20
4. Electronic Program Guide (EPG) ..............................................20
5. Favorite Group ............................................................................21
6. Volume Control ...........................................................................21
7. Pause ...........................................................................................21
8. Subtitle.........................................................................................22
9. Audio Control..............................................................................22
10. Teletext.........................................................................................23
11. PIP (Picture in Picture) ...............................................................23
PVR (Personal Video Recorder) Function ..............................................24
1. Recording ....................................................................................24
1.1 Recording methods.......................................................................24
1.2 Recording Edit ..............................................................................25
1.3 Long Time recording .....................................................................26
1.4 Pause during recording.................................................................26
2. Time Shifting ...............................................................................27
3. Playback (Play List) ....................................................................28
3.1 Recorded Files..............................................................................29
3.2 Imported Files ...............................................................................29
3.3 Music ............................................................................................29
3.4 Photo ............................................................................................29
4. Bookmark ....................................................................................30
5. Trick mode...................................................................................30
Menu Map.............................................................................................31
Main Menu of Guide .............................................................................32
1. System Tools...............................................................................32
1.1 Storage Manager ..........................................................................32
1.2 Timer Settings...............................................................................33
1.3 Service List Manager ....................................................................33
1.4 Data Transfer ................................................................................34
2. Conguration ..............................................................................35
2.1 Recording Option..........................................................................36
2.2 Parental Control............................................................................37
2.3 Display Setting..............................................................................37
2.4 Time Setting..................................................................................38
2.5 Language Setting..........................................................................38
2.6 A/V Output Setting ........................................................................39
3. Installation...................................................................................40
3.1 Dish Setting ..................................................................................40
3.2 Positioner Setting..........................................................................41
3.3 Service Search .............................................................................42
3.4 Network Setting ............................................................................43
3.5 System Recovery..........................................................................44
3.6 System Information.......................................................................45
4. Utility............................................................................................44
4.1 Calculator......................................................................................44
4.2 Calendar .......................................................................................45
4.3 CAS (Conditional Access System)................................................45
4.4 Plugin............................................................................................46
4.5 Free TV+.......................................................................................47
Troubleshooting...................................................................................48
Specications .......................................................................................49
6
1. Important Safety
Instructions
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near
water.
Clean only with dry cloth.
Do not block any ventilation
openings. Install in accordance
with the manufacturer’s
instructions.
Do not install near any heat
sources such as radiators,
heat registers, stoves, or other
apparatus (including ampliers)
that produce heat.
Do not reverse the safety
purpose of the polarized
or grounding-type plug. A
polarized plug has two blades
with one wider than the other.
A grounding type plug has two
blades and a third grounding
prong. The wide blade or third
prong is provided for your safety.
If the provided plug does not
t into your outlet, consult an
electrician for replacement of
the obsolete outlet.
Protect the power cord
from being walked on or
pinched particularly at plugs,
convenience receptacles, and
the point where they exit from
the apparatus.
Only use attachments/
accessories specied by the
manufacturer.
Use only with the cart, stand,
tripod, bracket, or table specied
by the manufacturer, or sold
with the apparatus. When a
cart is used, use caution when
moving the cart/apparatus
combination to avoid injury
from tip-over.
Unplug this apparatus during
lightning storms or when
unused for long periods of time.
Refer all servicing to qualied
service personnel. Servicing is
required when the apparatus
has been damaged in any way,
such as power-supply cord or
plug is damaged, liquid has been
spilled or objects have fallen into
the apparatus, the apparatus
has been exposed to rain or
moisture, does not operate
normally, or has been dropped.
WARNING: To Prevent re or shock hazard
do not expose the set to rain or moisture.
2. Notice
These servicing instructions
are for use by qualied service
personnel only. To reduce the
risk of electric shock, do not
perform any servicing other than
that contained in the operating
instructions unless you are
qualied to do so.
The apparatus shall not be
exposed to dripping or splashing
and that no objects lled with
liquids, such as vases, shall be
placed on the apparatus.
Precautions
7
The mains plug is used as the disconnect
device. The disconnect device shall
remain readily operable.
To reduce the risk of electric shock, do not remove the cover (or back).
No user serviceable parts are inside.
Refer servicing to qualied service personnel.
The Lightning Flash with arrowhead symbol within an
equilateral triangle, is intended to alert the user to the presence
of un-insulated “dangerous voltage” within the product
enclosure that may be of sucient magnitude to constitute a
risk of shock to persons
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature accompanying
the product
3. Copyright
This manual is protected by copyright
laws.
Copy, use and reproduction of this
manual in part or whole without
Manufacturer’s prior written approval are
prohibited.
4. Disclaimer
The manufacturers, distributors and
agents are not liable to any kind of
damage caused by the use of the
information contained in this manual.
The instruction and descriptions which
this manual contains are based on the
time of this manual’s production.
The manufacturer constantly updates it
with new functions and technology.
All the specications are subject to
change without prior notice.
5. Trademarks
HDMI, the HDMI logo and High-
Denition Multimedia Interface are
trademarks or registered trademarks of
HDMI Licensing LLC
8
Before You Begin
1. Main Features
Full HD Satellite PVR receiver
Supports H.264/MPEG4/MPEG-2 (HD/SD), DVB-S2
Compliant
Powerful Compatibility through Embedded Linux
OS
Time Shifting, Recording & Playback with External
Storage Devices ( USB 2.0 )
Simultaneous Recording of 3 Services and
Watching 2 others (PIP)
USB 2.0 Host ports (MP3 Player & JPEG Viewer)
Powerful Extended EPG with Event Recording
Picture-in-Picture (PIP) Supported
HDMI Video & Audio Output (576i, 576p, 720p,
1080i, 1080p)
10/100 base Tx Ethernet port
Supports Wi-Fi via external USB device
1 Smart card reader and 1 Common Interface
Slots
Supports Various Media File Format Playback
(Xvid le Playback)
Intelligent Blind scan for both SD and HD TV &
Multi Satellite Search
Multi-LNB Controlled by DiSEqC Control Version
1.0, 1.1, 1.2 and USALS
Support EPG (Electronic Program Guide)
High Denition On-Screen Display with Full Color
& Resolution
Favorite Service Groups
Powerful Service Control by Favorites, Lock, Skip,
Move and Delete
Service Sorting by Alphabet, Transponder and
CAS
Multi-language Supported ( OSD & Menu )
Teletext / Subtitles Support
Maximum 10,000 Services Programmable
Parental Lock / System Lock / Installation Lock
CVBS Video & Audio Output via RCA
Optical Output for Digital Audio(SPDIF)
Software & Service Database update via USB and
Ethernet port
9
6. Accessories
User’s Manual Remote Controller RCA cable (Option)
AAA size batteries X2 HDMI cable USB hub
Adaptor TV mount bracket (Optional) IR extension (Optional)
NOTE: If any accessories listed above are missing, contact the sales representative where you purchased this unit.
It is ready to be mounted behind of the TV. Use the screws provided to hold the components in place.
10
1. Front Panel Conguration
Hardware Description
1. POWER Button:
Press to switch between STANDBY and POWER ON
modes.
2. CH Up/Down Button:
Press to change services in normal mode, to move
the highlighted-bar UP/DOWN in menu mode.
3. STANDBY / REMOTE Indication LED (RED / GREEN):
The LED (RED) lights on in standby mode. / The LED
(GREEN) lights on when a key on the Remote Control
is pressed.
4. Remote Sensor:
Receives signal from remote controller.
11
2. Rear Panel Conguration
1. IR extension: The 2.5mm mini plug
is connected to the “IR Rec” jack to
use IR extension when HS 7110 is
mounted with optional bracket.
(Front remote sensor will not be
operated when IR Extension is
connected)
2. PCMCIA: To receive other pay-
tv service you need a CA-
Module(Viaccess, Irdeto, Nagravison,
etc.) and a smart card from the
service provider.
3. SMART CARD READER: Insert smart card
for encrypted service access.
4. LNB IN: Use to connect a satellite
antenna.
5. LNB OUT: Use it when connecting to
another STB for loop-through.
6. RS-232C: Serial port for rmware
update and data transfer.
7. Ethernet: Local area network port for
direct computer connection.
8. USB: Use it when connecting to
external USB storage device.
9. HDMI: Connects to the TV by using
a HDMI cable for the best quality
picture and audio.
10.A/V OUT: Connects to the TV or
VCR using a optional RCA cable
(Stereo audio output / White, Red,
Composite video output / Yellow)
11.SPDIF: Connects to the audio system
using a S/PDIF cable. (digital audio)
12.A/C power cable socket: Connects to A/C
power cord.
12
3. Remote Control Unit 1. POWER: Turns the STB On/O.
2. MUTE / Resolution: Turns the sound On/O. / To select the
resolution format press and hold Resolution button. You will
see the resolution menu. Each time you press the Resolution
button, the resolution changes in the following sequence:
576i > 576p > 720p > 1080i > 1080p by pressing the Exit button it
turns the sound On/O again.
3. Numeric: Controls the numerical operation and service
numbers directly.
4. Subtitle: To show multilingual subtitle.
5. Teletext: To show the digital teletext.
6. OK or Service List: Show the service list in non-menu mode and
select an item or conrm in menu mode.
7. ARROW Buttons
a. Up & Down Buttons: To change the value of a selected item with
preprogrammed values in menu.
b. Left & Right Buttons: To move the cursor left and right in menu.
8. Menu: To enter the main menu or to move to the previous
menu.
9. EXIT: Exit from the menu or pop-up window.
10. Play List: To show the le list in the USB Storage Device or
Network Storage Device.
Dieses Handbuch passt für folgende Modelle
1
Inhaltsverzeichnis
Andere Xcruiser Empfänger Handbücher
Xcruiser
Xcruiser XDSR200HD Bedienungsanleitung
Xcruiser
Xcruiser XDSR385HD Bedienungsanleitung
Xcruiser
Xcruiser XDSR600HD Bedienungsanleitung
Xcruiser
Xcruiser XDSR4000HD Bedienungsanleitung
Xcruiser
Xcruiser XDSR57FTA Bedienungsanleitung
Xcruiser
Xcruiser XDSR385HDPlus Bedienungsanleitung
Xcruiser
Xcruiser XDSR78HDPVR Bedienungsanleitung
