YS170/YS1700 and HyperTerminal

Tech note TN12009

- 2 -

Overview

This tech note describes how to configure

the YS170/YS1700 controllers and

HyperTerminal to communicate with each

other.

Follow Slide 3 for YS170 settings.

Follow Side 4&5 for YS1700 settings.

HyperTerminal settings are identical for

both controllers.

- 3 -

YS170 Settings

Go to the CONFIG1 screen and set COMM

parameters

1. ADRS: Controller Address

2. STBIT: Stop Bits

3. PAR: Parity

4. BPS: Communication Speed

Example: ADRS-1, STBIT-1, PAR-NO,

BPS-9600.

NOTE: These values must match

the settings used in HyperTerminal.

- 4 -

YS1700 Settings (part 1)

Go to the COMM screen and set COMM

parameters

1. PSL: Protocol Select (Must be set

to YS)

2. ADRS: Controller address

3. STBIT: Stop Bits

4. PAR: Parity

5. DLEN: Data Length

6. BPS: Communication Speed

- 5 -

YS1700 Settings (part 2)

Setting example:

PSL: YS

ADRS: 1

STBIT: 1 bit

PAR: NONE

DLEN: 8 bit

BPS: 9600

NOTE: These values must match the

settings used in HyperTerminal.

- 6 -

COM Port Settings

Flow control must be set to

Xon/Xoff

HyperTerminal Settings

NOTE: These values must match the

settings on the controller.

- 7 -

Terminal Settings

HyperTerminal Settings

- 8 -

ASCII Setup

HyperTerminal Settings

- 9 -

Data Commands

Data command must be sent to the YS as

a string.

Construct the command in Notepad or

Wordpad and then CUT/PASTE into

HyperTerminal.

Follow this

IMMEDIATELY

by

hitting the

ENTER key.

- 10 -

Data Commands

Example

CUT/PASTE DG 01 01 SV1 into

HyperTerminal.

Follow this

IMMEDIATELY

by hitting the

ENTER key.

The is will retrieve (DG or data get), from

controller address 01 (01), one byte of

data (01) which is the set point (SV1).
