Zagg Cover-Fit Bedienungsanleitung
Keyboard Instructions
*WARRANTY REGISTRATION
Your ZAGG Cover-Fit Bluetooth® keyboard comes with a one-year manufacturer’s
warranty. Please keep your purchase receipt and register your Cover-Fit on our
website www.zagg.com (purchases made on our website are automatically registered).
Replacement products must be mailed back as soon as your new product arrives; you may
incur postage fees as a result. See our website FAQs for further details.
INTRODUCTION:
ATTACHING/REMOVING YOUR TABLET
Thank you for being the proud new owner of the ZAGG Cover-Fit. This
amazing keyboard is ultra-slim and packed with a ton of features that
make typing fast, easy, and comfortable. To get the most from your new
keyboard, please read the following instructions. Keep these instructions
for future reference.
Your ZAGG Cover-Fit attaches to your Samsung tablet via a unique
compression fit. To attach your tablet to the Cover-Fit:
1. Place your Cover-Fit on a clean, flat surface.
2. With its screen facing the Cover-Fit’s keys,
place the bottom of your tablet (in
landscape mode) so that it fits snugly
against the back edge of the Cover-Fit.
3.
Press your tablet onto the Cover-Fit. Ensure the
clasps on the side of the Cover-Fit are secure
onto your tablet. You are now ready to take your
work and play everywhere you go.
4. To remove your Cover-Fit, simply grasp it at
the groove on the front of the keyboard and lift up.
a. If lifting from the groove does not supply enough
force to separate your keyboard, lift
it as instructed above, but then slide your
finger/s to each side closer to the corners.
2
POSITIONING YOUR TABLET
POWERING ON AND OFF
The Cover-Fit features a patented channel
that holds your tablet at an ideal viewing
angle so you can work and play in comfort. To
position your tablet:
1. Place your tablet in landscape mode into
the Cover-Fit’s channel.
2. Lean your tablet back until it catches
in the channel; the channel’s custom
design perfectly balances your tablet
at an ideal angle. Note: The channel’s
unique design and gravity are what hold
your tablet in place. If you hold your
Cover-Fit at an extreme angle, you risk
having your tablet fall.
Your Cover-Fit comes charged with approximately 80% of its total capacity. That’s
enough power to keep you typing for over two months of regular use*. To turn
your Cover-Fit on, switch the Power button to the ON position. The LED indicator
will illumine blue for two seconds to indicate it is powered on.
*Regular use of two hours per day.
To turn your Cover-Fit o, switch the
Power button to the OFF position.
3
PAIRING YOUR COVER-FIT
CHARGING
Pairing your Cover-Fit to your tablet is quick and easy. It should only need to
be paired once using the following instructions. If the connection between your
tablet and the Cover-Fit is ever lost, repeat these steps.
1. Ensure the Bluetooth® settings on your tablet are on and you are at the pairing
screen (Select SETTINGS—WIRELESS & NETWORKS—BLUETOOTH—ON).
2. Press the Pair button (located next to the Power switch).
The CAPS LOCK indicator will begin flashing letting
you know your keyboard is ready to pair.
3. Wait until your tablet finds the Cover-Fit and then
select it from the list of available devices to complete
pairing. It will display as “ZAGG Cover-Fit”.
Your ZAGG Cover-Fit comes ready to go out of the box with about 80% of its
maximum charge; enough to deliver over two months of normal use*. Charge your
keyboard fully for longer performance. To charge your ZAGG Cover-Fit:
1. Connect the micro USB cable to the Cover-Fit’s corresponding port.
2. Connect the USB end of the cord to your preferred charging device (a ZAGG
Sparq, your computer, a wall outlet converter, etc.).
3.
The LED indicator will illuminate red while the Cover-Fit charges and then turn o
when it is completely charged. It typically takes three to four hours to charge fully.
4. Enjoy your Cover-Fit for up to three months of regular use*.
*Regular use of two hours per day.
4
CHARGING PORT
SPECIAL FUNCTION KEYS
Your ZAGG Cover-Fit features a variety of special function keys that help
you get more done from the convenience of your keyboard. Here is a list
of those special function keys and what they do.
HOME - Opens your tablet’s Home screen.
RETURN - Returns to the last open app or program.
MENU -Opens your tablet’s menu options.
LOCK -Activates and deactivates your tablet’s sleep mode.
MAIL -Opens the primary email provider on your tablet.
CUT - Removes a highlighted section of copy from a document and stores it on
your tablet’s clipboard to be pasted later or deleted.
COPY -Copies highlighted text and saves it on your tablet’s internal clipboard to
be deleted or pasted back in another location.
PASTE -Pastes the most recently cut or copied text into the specified section of
your document.
VOICE -Activates your tablet’s voice recognition feature.
PREVIOUS TRACK -Skips to the last track played on your current playlist.
PLAY/PAUSE -Starts or pauses your current playlist. To resume playing from
pause, simply press the PLAY/PAUSE button again.
NEXT TRACK -Skips to the next track of your current playlist.
MUTE - Mutes the audio on your tablet. To resume playing audio, simply press the
MUTE button again.
VOLUME DOWN -Decreases your tablet’s volume.
VOLUME UP -Increases your tablet’s volume.
GOOGLE CALENDAR -
Launches Google Calendar Application
.
DELETE -Deletes text from right to left.
INTERNET -Opens your tablet’s primary internet browser.
ALT GR -Alternate Graphic button allows you to access special characters.
WORLD SYMBOL - Toggles between international keyboards (when activated in
your tablet’s settings).
SEARCH - Opens your tablet’s search function.
5
Del
Internet
Alt Gr
6
The Function (fn) Key - The fn key operates all key functions that appear in blue.
To activate these functions, hold the fn key down and press the desired key. A list of
special fn keys and their operations is listed below.
BATTERY - Signals the LED indicator to display remaining battery life. When
pressed, the LED indicator will do one of the following:
• Flash Green Four Times: Indicates your Cover-Fit has a full charge.
•
Flash Green Three Times: Indicates your Cover-Fit has approximately 75% charge.
• Flash Yellow: Indicates your Cover-Fit has approximately 50% charge.
• Flash Red: Indicates your Cover-Fit has less than 25% charge remaining.
PAGE UP -Moves your view up a page.
PAGE DOWN -Moves your view down a page.
HOME -Returns your cursor to the beginning of a document.
END -Moves your cursor to the end of a line on a document.
LED Indicators - Your Cover-Fit features two LED indicators. Both are located on
the right side. The following is an explanation of each and what it indicates.
TOP LED -The top LED lights to indicate charging and battery life. When
charging it will light red and then turn o when your Cover-Fit has 100% charge.
When you hold the fn button and press the BATTERY key, it displays your Cover-
Fit’s remaining charge. See the BATTERY button description for charge
indicators.
BOTTOM LED -The bottom LED lights to indicate CAPS LOCK and pairing.
When the CAPS LOCK function is on, it will light blue until CAPS LOCK is turned
o. When pairing, it will light blue and flash until pairing is complete.
Fn
PgUp
PgDn
Home
End
7
BATTERY
TROUBLESHOOTING
Your ZAGG Cover-Fit is fitted with a powerful lithium ion battery that will
last up to three months of normal use* on a single charge. The battery has
no memory eect and can be charged whenever you like without reducing
its life. When you do not plan on using your keyboard for an extended
period, we recommend turning it o to preserve battery life.
* Normal use is approximately 2-3 hours of use per day.
If your tablet does not respond to your ZAGG Cover-Fit there may be
a simple explanation such as a dead battery or an unsuccessful pairing.
Please use the following to help troubleshoot your situation. If none of the
following solve your issue, then please contact ZAGG customer service
and one of our trained professionals will be happy to assist you.
1. Restart your tablet. Sometimes simply resetting your tablet will clear
any issues so that your Cover-Fit can pair and function properly.
2. Turn your ZAGG Cover-Fit o and back on. You should see the LED
status light illuminate briefly, if not, charge your keyboard.
3. After charging, turn your ZAGG Cover-Fit on. If the LED status light
does not illuminate, and your keyboard doesn’t operate correctly,
please contact ZAGG’s customer service.
4. Forget and re-pair your Cover-Fit. Select SETTINGS—WIRELESS
& NETWORKS—BLUETOOTH and then select to have your tablet
forget the ZAGG Cover-Fit. After it is forgotten, try pairing your
Cover-Fit again.
5. If your tablet gives you an error message, repeat the pairing process.
6. If you still can’t get your ZAGG Cover-Fit to pair, please contact
ZAGG customer service.
Need more help? Please see our FAQ section at: www.zagg.com
©2005 - 2013 ZAGG Inc | All Rights Reserved
PATENT PENDING | NASDAQ: ZAGG | MADE IN CHINA
Samsung™ is a trademark of Samsung.
Bluetooth® is a registered trademark of Bluetooth SIG.
ZAGG® is a registered trademarks of ZAGG Inc.
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions:
1: This device may not cause harmful interference, and
2: This device must accept any interference received, including
interference that may cause undesired operation
8
