Zavio F210A Gebrauchsanweisung
F210A User Manual
0
F210A User Manual
1
F210A IP Camera
Hardware User Manual
-Contents-
CHAPTER 1. SAFETY INSTRUCTION........................................................................................2
CHAPTER 2. INTRODUCTION.....................................................................................................4
CHAPTER 3. PACKAGE CONTENTS ..........................................................................................5
CHAPTER 4. PHYSICAL DESCRIPTION....................................................................................6
4.1 FRONT VIEW............................................................................................................................................................6
4.2 BOTTOM VIEW.........................................................................................................................................................7
CHAPTER 5. BASIC CONNECTION ............................................................................................8
CHAPTER 6. APPLICATION..........................................................................................................9
F210A User Manual
2
Hardware User Manual
Chapter 1. Safety Instruction
Before you use this product
This product has been designed with safety in mind. However, the electrical products can cause
fires which may lead to serious body injury if not used properly. To avoid such accidents, be sure to
heed the following.
Legal Caution
Video and audio surveillance can be forbidden by laws that vary from country to country. Check the
laws in your local region before using this product for surveillance purposes.
Don't open the housing of the product
Don't try to open the housing or remove the covers which may expose yourself to dangerous voltage
or other hazards.
Don't use the accessories not recommend by the manufacturer
Heed the safety precautions
Be sure to follow the general safety precautions and the “Operation Notice.”
Operation Notice - Operating or storage location
Avoid operating or storing the camera in the following locations:
Extremely hot or cold places
(Operating temperature: 0 °C to + 50 °C [32 °F to 122°F] )
Exposed to direct sunlight for a long time, or close to heating equipment (e.g., near heaters)
Close to water (e.g.,near a bathtub, kitchen sink, laundry tub)
Close to sources of strong magnetism
Close to sources of powerful electromagnetic radiation, such as radios or TV transmitters
Locations subject to strong vibration or shock
F210A User Manual
3
In case of a breakdown
In case of system breakdown, discontinue use and contact your authorized dealer.
In case of abnormal operation
If the unit emits smoke or an unusual smell,
If water or other foreign objects enter the cabinet, or
If you drop the unit or damage the cabinet:1 Disconnect the cable and the connecting cables. 2
Contact your authorized dealer or the store where you purchased the product.
Transportation
When transporting the camera, repack it as originally packed at the factory or in materials of equal
quality.
Ventilation
To prevent heat buildup, do not block air circulation around the device.
Cleaning
Use a soft, dry cloth to clean the external surfaces of the device. Stubborn stains can be
removed using a soft cloth dampened with a small quantity of detergent solution, then wipe dry.
Do not use volatile solvents such as alcohol, benzene or thinners as they may damage the
surface.
F210A User Manual
Chapter 2. Introduction
The Zavio F210A is an ultra-compact IP Camera equipped with a high sensitivity progressive scan
CMOS sensor, achieving high image quality and low-light performance. Although it is one of the
world's smallest IP Cameras, it still provides all the powerful features and great quality.
Key Features:
Ultra-compact size
Maximum Resolution 640x480 (VGA) provides superior image quality
Simultaneous MPEG-4 and Motion JPEG video stream
Excellent Image Quality up to flexible 30 fps in all resolution for optimum bandwidth use
Superior Low-Light Performance with Automatic Night-mode
Two-way Audio with Built-In Microphone
Optimal Synchronization of Audio and Video
Support Live Video Viewing on Windows Live Messenger (WLM )
Control panel add-in, i.e. snapshot and image setup
Support Mac OS Browser
Support iPhone through Safari Browser
Mobile Phone Streaming Live Video through 3GPP/ ISMA/ RTSP
Mobile Phone Live Image through 2.5 WAP
Multi-level Password Protection for Restricting Camera Access
Built-In Multi-Window Motion Detection (3 detection areas)
Video Buffer makes the Streaming Smoother
UPnP and Bonjour for Fast and Easy Installation
DDNS Supported
Bundled 16 Channel Surveillance Software
User-friendly & Multi-lingual UI
4
F210A User Manual
Chapter 3. Package Contents
Camera - F210A Network Camera
Quick Installation Guide -To provide brief product information and quick installation and
wireless setting
Software CD - To provide IP Surveillance Software, Intelligence IP Installer, User Manuals, and
Language Packs
Mounting Bracket - There are three components including lock ring, brace, and base plate to
compose a bracket and three applied screws to fix the base plate to a flat surface (horizontal or
vertical)
Adaptor - 5V DC, max 3.5W
5
F210A User Manual
Chapter 4. Physical Description
4.1 Front View
Focus Adjustment Ring - Adjust focus manually to achieve the best image quality
Network LED Indicator - Network LED will light up after the IP Camera connected with
network
Power LED Indicator - Power LED will light up after the IP Camera completed the boot
process
Built-In Microphone - Built-In Microphone for Two-way Audio
6
F210A User Manual
4.2 Bottom View
Power Connector - For connection of 5V DC input
Network Connector - For connection to the Ethernet via RJ-45 standard
Reset - When the device is empowered, press the Reset Button to reboot the device, or
hold the Reset Button for 10 seconds to set the device settings back to factory default
Audio Out (Speaker) - To support audio out with earphones or speakers
7
F210A User Manual
Chapter 5. Basic Connection
F210A is for wire connection. You can follow the procedure below to connect the IP Camera with
power and Ethernet for wire connection.
Wire Connection
1. Connect the power adaptor to IP Camera.
2. Connect IP Camera’ Ethernet port to your Hub/ Switch/ Router
8
F210A User Manual
Chapter 6. Application
9
