Zebra-Tech UW-Caliper Operation Manual
| 1 |
1. Your UW-Calipers at a glance
The Zebra-Tech UW-Calipers are rugged field calipers designed to operate
accurately and reliably in harsh environments and underwater to a depth
of 40 meters.
At the push of a button the UW-Calipers record the caliper measurement,
together with the time and date as well as depth if the optional depth
sensor is installed.
Data collected by the UW-Calipers can be offloaded onto a PC and then
simply opened in an Excel spreadsheet.
UW-CALIPERS WITH OVERBITE, CHARGER AND COMS CABLE
Zebra-Tech UW-Caliper Operation Manual
| 2 |
Features
The UW-Calipers offer the following features:
Rugged design
Simple to operate, even while wearing thick dive gloves
One or two button operation
Rechargeable on-board battery with long operating capacity
Capacity to store 8000 records
Simple windows software for offloading collected data
USB communication
UW-CALIPERS WITH 60MM JAWS FITTED
Zebra-Tech UW-Caliper Operation Manual
| 3 |
2. UW-Caliper specifications
Specifications
Maximum depth:
30m
Maximum caliper measurement:
240mm
Caliper resolution:
0.5mm
Caliper accuracy:
Closing jaws +/-1mm or better between 0-40˚C
Depth resolution (optional):
0.1 meter
Memory:
8000 records (each record consists of Caliper
measurement, depth (if fitted), time, date. Data
is non-volatile; if the battery goes flat, data is
not lost).
Battery endurance:
+40 hours on a full charge
Options
Depth sensor:
Depth sensor which enables depth to be recorded with each
measurement
Jaw length:
Button:
60mm or 90mm jaw size
Custom jaw profiles available on request
Single button, or two button
FIELD SWAPPABLE 60MM AND 90MM JAWS
Zebra-Tech UW-Caliper Operation Manual
| 4 |
3. Charging your UW-Calipers
Unscrew the charging/coms cap from the end of the calipers.
Push on the charging plug. Tighten the locking sleeve.
Plug the charger into mains power; the red ‘Power’LED should be
continuously illuminated. For the first minute, the green ‘Ready’LED
should flash. This indicates the battery status is being tested. After one
minute the green ‘Ready’LED will stop flashing while the red ‘Charge’LED
will remain illuminated.
When charging is complete, the red ‘Charge’LED will go off, and the green
‘Ready’LED will flash (trickle charge).
After charging, disconnect the charger from the mains power.
Disconnect the charging cable from the UW-Calipers.
Clean and re-grease the O ring on the charging/coms cap.
Screw the cap back onto the UW-Caliper. Do not over tighten.
UW-CALIPERS WITH CHARGING/COMS CAP UNSCREWED
Zebra-Tech UW-Caliper Operation Manual
| 5 |
4. Operating your UW-Calipers
Switching On
Simply press the blue button to switch on your UW-Calipers. The green
light will light up briefly and the current caliper measurement will be
displayed.
Switching Off
The calipers automatically switch off if the outer jaw is not moved for
5 minutes.
Taking a measurement
Open the outer jaw of the UW-Caliper wider than the object being
measured. Then gently close the jaws on the object.
The UW-Calipers are calibrated for measuring on a closing jaw action. If
the jaw movement directly prior to a measurement is in the opening
direction, then the accuracy of the measurement will be reduced.
Logging a measurement
By simply pressing and releasing the blue button, the current caliper
measurement is logged, together with the current time and date, and the
water depth if the calipers incorporate the optional pressure sensor.
If your caliper has 2 buttons, whichever button is pressed is logged in the
data file. This enables measurement differentiation. For example, you can
differentiate between 2 species, or length and width measurements.
Zebra-Tech UW-Caliper Operation Manual
| 6 |
A break in the data file can be created by logging a closed jaw or fully open
jaw measurement. For example, if measurements are being made along a
transect, a zero measurement can be logged at the end of the transect.
This can then be identified in the data file.
TWO BUTTON UW-CALIPER
ONE
TWO
Zebra-Tech UW-Caliper Operation Manual
| 7 |
Tare the UW-Calipers
When the calipers are gently closed, they should display 0.0mm. If they
don’t, they can be tarred by pressing and holding the blue button. After
10 seconds ‘Tare’should appear on the display. The blue button can then
be released.
ONE BUTTON UW-CALIPER
Zebra-Tech UW-Caliper Operation Manual
| 8 |
5. Communicating with your UW-Calipers
Installing UW-Caliper software onto a PC
The UW-Calipers are supplied with a flash drive that carries the file ‘Install
UW-Caliper version #’.Simply double clicking this file should start the
installer which handles the installation of the software onto the PC.
The latest version of the software can also be downloaded from the Zebra-
Tech web site http://www.zebra-tech.co.nz/downloads
Connecting the UW-Caliper to a computer
Unscrew the charging/coms cap from the end of the calipers.
Push on the communication cable plug, and tighten the locking sleeve.
Plug the USB connector into the PC, and start ‘UW-Caliper’software.
NOTE!
It is recommended that the UW-Caliper software is
installed BEFORE the calipers are connected to the PC for
the first time.
