Zenner Multipulse Bedienungsanleitung

multipulse, multilog

Installation and

operating manual

Electronic pulse counter module

with 3 inputs for connection

of meters

with pulse outputs

EnergyMetering

All that counts.

ZE12B28_MA_Multipulse_EN_V2_D 1 10.10.12 17:24

General information

With multipulse resp. multilog you have acquired

one of the most up-to-date and modern electron-

ic pulse counter modules currently available on

the market.

Expressive symbols in the display and easy

menu navigation make readout simple. It can be

operated with one single button. The change of

pulse values and the setting of the data loggers

with multilog is being done via the software GMM.

The pulse counter module is equipped with a long-

life battery made for operation during a period of 5

years including a reserve of at least another year.

With a second battery you will reach 11 years.

Electro-magnetic interference

multipulse resp. multilog fulls the national and

international requirements for interference resis-

tance. To avoid malfunctions due to other inter-

ferences, do not install uorescent lamps, switch

cabinets or electric devices such as motors or

pumps in the immediate vicinity of the meter

(minimum distance 1 m). Cables leaving the

meter should not be laid parallel to live cables

(230V, minimum distance 0.2 m).

Cables leaving the meter should not be laid paral-

lel to live cables (230V, minimum distance 0.2 m).

The device complies with Directive 89/336/EEC

(electromagnetic compatibility).

Care instructions

Clean plastic surfaces with a damp cloth only.

Do not use any scouring or aggressive cleaning

agents! The device is maintenance-free during

the service life. Repairs can only be made by the

manufacturer. The most up-to-date information

about this product and of our installation notice

can be found at www.zenner.com.

ZE12B28_MA_Multipulse_EN_V2_D 2 10.10.12 17:24

Technical data

Dispay Multifunctional LCD, 8-digit, oating

Interface meter Models with contact pulsers or active pulsers (no

Namur or Opto) Reed max. 1Hz /active max. 100 Hz

Interfaces optical, optionally ZR-Bus, M-Bus, RS-232,

Ambient temperature °C 0 - 55

Power supply Battery 3.6 V Lithium, optionally mains supply 230 V

Battery lifetime 6 years, optionally 11 years

Protection class IP 54 / IP 65, acc. to DIN 40050

Mechanical/electro-magnetic class

M1/E1

ZE12B28_MA_Multipulse_EN_V2_D 3 10.10.12 17:24

pulse

52/

GND

pulse

VCC 2,5 … 3,6 V

U = 3 … 30 V

Imax = 20 mA

53/

52/

53/

52/

53/

GND

Uhigh = 2,5 … 3,6 V

Ulow = 0 … 0,3 V

pulse

52/

GND

pulse

VCC 2,5 … 3,6 V

U = 3 … 30 V

Imax = 20 mA

53/

52/

53/

52/

53/

GND

Uhigh = 2,5 … 3,6 V

Ulow = 0 … 0,3 V

pulse

52/

GND

pulse

VCC 2,5 … 3,6 V

U = 3 … 30 V

Imax = 20 mA

53/

52/

53/

52/

53/

GND

Uhigh = 2,5 … 3,6 V

Ulow = 0 … 0,3 V

pulse

52/

GND

pulse

VCC 2,5 … 3,6 V

U = 3 … 30 V

Imax = 20 mA

53/

52/

53/

52/

53/

GND

Uhigh = 2,5 … 3,6 V

Ulow = 0 … 0,3 V

pulse

52/

GND

pulse

VCC 2,5 … 3,6 V

U = 3 … 30 V

Imax = 20 mA

53/

52/

53/

52/

53/

GND

Uhigh = 2,5 … 3,6 V

Ulow = 0 … 0,3 V

1 Hz Version: fmax = 1 Hz, Pulse-duty factor 1:1 to 1:9 Input

capacitance: approx. 10 nF, Input resistance approx 850 kOhm

100 Hz Version: not allowed

fmax = 1 Hz,

Pulse-duty factor 1:1 to 1:9

Input capacitance: approx. 15 nF,

Input resistance approx 470 kOhm

1 Hz Version: fmax = 1 Hz, Pulse-duty factor 1:1 to 1:9 Input

capacitance: approx. 10 nF, Input resistance approx 850 kOhm

100 Hz Version: fmax = 30 Hz, Pulse-duty factor 1:1, Input

capacitance: approx. 2,5 nF, Input resistance approx. 850 kOhm

fmax = 1 Hz,

Pulse-duty factor 1:1 to 1:9

Input capacitance: approx. 15 nF,

Input resistance approx 470 kOhm

1 Hz Version: fmax = 1 Hz, Pulse-duty factor 1:1 to 1:9

Uhigh = 2,5 … 3,6V, Ulow = 0 … 0,3 V, Input capacitance:

approx. 10 nF, Input resistance approx 850 kOhm

100 Hz Version: fmax = 100 Hz, Pulse-duty factor 1:1

Uhigh = 2,5 … 3,6V, Ulow = 0 … 0,3 V, Input capacitance:

approx. 2,5 nF, Input resistance approx. 850 kOhm

Passive with

mechanical

contact (Reed)

Passive with

mechanical

contact (Reed)

Passive with

open drain FET

Passive with

open drain FET

Active f.ex. with

C-MOS Gate

Flow sensor input

Electrical connection Schematic diagram Connection data

Technical data additional inputs

Technical data ﬂow sensor input

ZE12B28_MA_Multipulse_EN_V2_D 4 10.10.12 17:24

If water meters with a potential free reed contact

are connected to the inputs the connection can

be made in any direction.

The connectors are given twice for the incoming

and outgoing of the M-bus wires.

Depending on the pulse counter module’s model

the version of the connection board can differ.

Note

You can download additional information in our

product area at www.zenner.com.

1 2 3 4 10 11 9 50 51 52 53 54 55 24 25 24 25

Version M-Bus

1 2 3 4 10 11 9 50 51 52 53 54 55

Version without interface

1 2 3 4 10 11 9 50 51 52 53 54 55 71 72 73 74

Version RS 232 / RS 485 (ZR-Bus)

Connector pin assignment

Main input

Volume pulse 10

Volume GND 11

Additional inputs

Input 1 pulse 52

Input 1 GND 53

Input 2 pulse 54

Input 2 GND 55

M-Bus

M-Bus A 24

M-Bus B 25

RS-232

DTR 71

GND 72

Tx 73

Rx 74

RS-485

+UB 71

GND 72

A 73

B 74

ZE12B28_MA_Multipulse_EN_V2_D 5 10.10.12 17:24

Dimensions

Height: H = 106 mm

Width: B = 126 mm

Depth: T = 54 mm

Communication

The pulse values can be programmed via

the software GMM. The pulse value can

be called up in the display (see the display

overview, Level 1).

The display resolution should be chosen in

such way that the display can not overow

within one years time.

M-Bus (optional)

The optional M-Bus interface complies

with the norm EN 1434-3 and operates

with 2400 baud xed. It can be set to

300/9600 baud if necessary.

Subject to modications and errors excepted. Any liability for misprints excluded. SAP124288_121010_EN

Römerstadt 6

D-66121 Saarbrücken

Telephone +49 681 99 676-30

Telefax +49 681 99 676-3100

E-Mail info@zenner.com

Internet www.zenner.com

ZENNER International GmbH & Co. KG

ZE12B28_MA_Multipulse_EN_V2_D 6 10.10.12 17:24

Installation instructions

Safety instructions

The installation has to be done by qualied per-

sonnel. Read the instructions carefully right up to

the end before starting to mount the device.

The current laws and regulations regarding the

installation have to be observed

At devices with communication interfaces or

mains supply the general technical rules and the

correspondent regulations have to be followed.

General Information

Take care of:

■the display of the module must readable at all

times,

■to avoid malfunctions due to other interfer-

ences do not install uorescent lamps, switch

cabinets or electric devices such as motors or

pumps in the immediate vicinity of the module

(minimum distance 1 m),

■the ambient temperature must not exceed

55°C,

■the pulse value of the meter must correspond

with the one from the module.

The module has 7 cable glands for wires with a

diameter between 4,2 and 10 mm. Keep unused

glands closed. multipulse resp. multilog is deliv-

ered ready for operation. It does not need any set-

tings or adjusting.

ZE12B28_MA_Multipulse_EN_V2_D 7 10.10.12 17:24

Installation pulse counting module

ZENNER recommends to mount the module on

the wall.

Do not mount the device at the pipe or attach it

directly on the meter. The mounting adapter at

the backside of the module can be used for rail

mounting or for wall mounting.

For wall mounting detach the adapter and turn it

180°, attach the adapter with at least two screws

to the wall and clip the module on it.

For rail mounting lift the adapter a little bit, place

the module on the rail and push the adapter

back until it locks.

Connection meter

With mechanical meters the connection order is

optional. Mind the polarity at electronic meters.

External power supply

A small vertical line appears in the display when

the optional external power supply is on service.

In case of a failure of the external power sup-

ply the devices switches automatically to battery

supply.

The battery lifetime can be checked in the dis-

play (level 3). After having reached the date the

battery has to be replaced if needed.

Rail mounting Wall mounting

ZE12B28_MA_Multipulse_EN_V2_D 8 10.10.12 17:24

Operation test

Check the pulse counter module for any error

codes in the display after installation (see table

for error codes).

Most of the errors can be deleted by pressing

the button. If the error appears permanently, it

will be detected at the next measuring cycle and

displayed again.

When attaching the top cover on the housing

pulses on the inputs can possibly be generated.

Check readings of the inputs and correct if nec-

essary.

Sealing

We recommend sealing the device with the in-

cluded seals to prevent unauthorized opening.

Maintenance

Repairs or overhaul are only allowed by the

manufacturer or companies authorized by the

manufacturer.

ZE12B28_MA_Multipulse_EN_V2_D 9 10.10.12 17:24

Status display / Error codes

The symbols in the table below show the pulse counting module’s operational status. The status

mes

sages only appear in the main display! The temporary display of the warning triangle can be caused

by special operating states and does not always mean that the device is malfunctioning. However,

should the symbol be displayed over a longer period of time you should contact the service company.

Error codes show faults detected by multipulse resp. multilog. If more than one error appears, the sum of

the error codes is displayed: Error 1100 = error 1000 and error 100.

Symbol Status Event

Flow existent -

Data transmission -

Emergency operation Exchange device

External power supply -

Code Error Event

100 Emergency operation Exchange device

1000 Battery life time exceeded Exchange device

> 8000 Internal hardware error Exchange device

ZE12B28_MA_Multipulse_EN_V2_D 10 10.10.12 17:24

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Zenner Messgerät Handbücher

Zenner

Zenner IUW Series Bedienungsanleitung

Zenner

Zenner WS Series Bedienungsanleitung

Zenner

Zenner zelsius C5-IUF Bedienungsanleitung

Zenner

Zenner zelsius C5-IUF Bedienungsanleitung

Zenner

Zenner zelsius C5-CMF Bedienungsanleitung

Zenner

Zenner zelsius C5-ISF Bedienungsanleitung

Zenner

Zenner zelsius C5 -ISF Bedienungsanleitung

Zenner

Zenner zelsius Bedienungsanleitung

Zenner

Zenner WSD Bedienungsanleitung

Zenner

Zenner zelsius C5-IUF Bedienungsanleitung

Zenner

Zenner Celsius WMZ compact Bedienungsanleitung

Zenner

Zenner ZSU02 Bedienungsanleitung

Zenner

Zenner Woltman WPD Bedienungsanleitung

Zenner

Zenner EnergieTechnik Bedienungsanleitung

Zenner

Zenner CO2 INDICATOR L868 ID A Bedienungsanleitung

Zenner

Zenner WSD Bedienungsanleitung

Zenner

Zenner Minolist ER2 Bedienungsanleitung

Zenner

Zenner Minomess micro Bedienungsanleitung

Zenner

Zenner Minolist Bedienungsanleitung

Zenner

Zenner zelsius C5-CMF Bedienungsanleitung

Zenner

Zenner RTKD Bedienungsanleitung

Zenner

Zenner MC Bedienungsanleitung

Zenner

Zenner WPD Bedienungsanleitung

Zenner

Zenner zelsius C5-ISF Bedienungsanleitung

Beliebte Messgerät Handbücher anderer Marken

Suaoki

Suaoki D40 Bedienungsanleitung

Elster

Elster BK-G1.6 Bedienungsanleitung

Endress+Hauser

Endress+Hauser Deltabar FMD71 Handbuch

Duratool

Duratool D03128 Bedienungsanleitung

Vega

Vega VEGAPULS 65 Bedienungsanleitung

Tonghui

Tonghui TH2618B Bedienungsanleitung

Tenmars

Tenmars TM-801 Bedienungsanleitung

MSR

MSR 145 Bedienungsanleitung

TPS

TPS WP-82 Bedienungsanleitung

ELMETRON

ELMETRON CP-511 Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics 003C30 Bedienungsanleitung

Tenma

Tenma 72-10465 Bedienungsanleitung

Endress+Hauser

Endress+Hauser Proline Promag 50 Technische Daten

Siemens

Siemens SITRANS F Coriolis FCT030 Stücklistenhandbuch

KLINGER

KLINGER CMF V Series Bedienungsanleitung

EXFO

EXFO FTB-2 Bedienungs- und Wartungshandbuch

Keysight

Keysight M8290A Bedienungsanleitung

ADTEK

ADTEK MW-5 Bedienungsanleitung

Zenner multipulse Bedienungsanleitung

Beliebte Messgerät Handbücher anderer Marken
