ZKTeco PL10 Series Bedienungsanleitung

User Manual

PL10/ML10

Version: 1.0

1. New lock is configured to grant ANY fingerprint access to unlock.

2. The lock is equipped with mechanical keys for manual unlocking. Remove mechanical keys from

the package and keep them in a safe place.

3. To power on the lock, four alkaline AA batteries (not included) are required. Non-alkaline and

rechargeable batteries ARE NOT RECOMMENDED.

4. Please avoid strong light direct to the fingerprint holder, otherwise the infrared sensor might be

disturbed.

5. The operation of setting lock has a stand-by time limit of 10 seconds; Without any activity, lock will

shut off after 10 seconds.

6. Keep your fingers clean when using this lock.

Note

Appearance

1 Infrared sensor hole

2LED

3Fingerprint Sensor

4 Handle

5 Mechanical key hole

6 Battery box cover

7 Battery Area

8Button / Temporary User

9Button / Admin user

10 Back LED

11 Button / Delete user

12 Button / Add user

13 Reset Button

14 Button / Normal User

15 9V Emergency battery interface

User Introduction

User Type

Capacity

Privilege

Admin user

Add/delete fingerprint; Enable Normal

Open; Unlock the door

Normal user

Unlock the door; Enable Normal Open

Temporary user

Unlock the door; Enable Normal Open

Button Definition

Buttons

Function

Other functions

Add Users

Delete Users

Admin User Group

Enable Normal Open

Normal User Group

Temporary User Group

Profile

Lock Status Indication

Lock Status

Indication

Operation success

1 Beep and LED blinks green

Operation failure

2 Beep and LED blinks red

Low battery

7 Beep and LED blinks red 7 times

Unlocking

1 Beep and electric engine makes a rolling sound for the first

time, which indicates that the door is open.

Locking

Electric engine makes a rolling sound for the second time,

which indicates that the door is closed.

Initialize Lock

Method 1 Method 2

Press the "Reset" button with

a pin.

Touch the infrared sensor hole

to power on the lock

Loosen the pin.

Press the button of "+", "1",

"2", "3" , "-".in order

Initialization succeed

One beep for each

pressing, back LED

blinks green

Fingerprint sensor is

power on LED blinks

green

A long beep, LED blinks

green for 1 second

Operating Steps

Indication of the lock

Operating Steps

Delete all Normal Users

Delete all Admin Users..

Reset successfully

Please see “Delete

Temporary Users”.

Delete all Temporary

Users.

Please see “Delete

Normal Users”.

Please see “Delete

Admin Users”.

Note: The lock will be restored to factory defaults after initialization, and the door can be opened

with any fingerprint.

How to use mechanical key?

How to use 9V emergency battery?

Hexagon Screw

Operating Steps

Indication of the lock

Touch the infrared sensor hole

to power on lock

Press button "+"

Place one finger 3 times on

the fingerprint sensor

Registration succeed

One Beep for the first two

fingerprints; A long beep

and LED blinks green 1

second for the third

fingerprint.

One beep

Fingerprint sensor is power

on, LED blinks green

Note: 1.The first user will be the firstAdmin automatically at default.

2. Admin group supports 10 users; you can still register 9 new Admins in next step.

3. The operating steps of Register new users: Press button 1/2/3 to select user group, then

place one new finger 3 times on the fingerprint sensor to continue register new user.

Operation Guide

Operating Steps

Indication of the lock

Touch the infrared sensor hole

to power on lock

Press button "+"

Place one finger 3 times on the

fingerprint sensor

Registration Succeed

Fingerprint sensor is power

on, LED blinks green

One beep

Place any admin finger 1 time to

verify Admin

Press button "1" to select Admin

group

One beep

One Beep for the first two

fingerprints; A long beep and

LED blinks green 1 second

for the third fingerprint.

Note: 1. Admin group supports 10 users; you can still register 9 new Admin in this step.

2. The operating steps of Register new users: Press button 1/2/3 to select user group, then

place one new finger 3 times on the fingerprint sensor to continue register new user.

Operation Guide

Operating Steps

Indication of the lock

Touch the infrared sensor hole to power

on the lock

Press button "+"

Place one finger 3 times on the

fingerprint sensor

Registration Succeed

Fingerprint sensor is power

on, LED blinks green

One beep

Place any admin finger 1 time to verify

Admin

Press button "2" to select normal user

group

One beep

One Beep for the first two

fingerprints; A long beep and

LED blinks green 1 second

for the third fingerprint.

Note: 1. Normal User group supports 60 users.

2. The operating steps of Register new users: Press button 1/2/3 to select user group, then

place one new finger 3 times on the fingerprint sensor to continue register new user.
