QUICK START GUIDE

ENTER AN ENVIRONMENT OF

PROFESSIONAL 3D PRINTING

Zortrax M2003D printer transforms virtual

projects into three-dimensional reality. It is used

to prototype and create various three-dimensional

models. 3D printing can be utilized to prototype

mechanical elements, structures, industrial molds

and templates, objects of everyday use

and promotional gadgets.

MEET THE ZORTRAX M200

M200

3D PRINTER

Z-SUITE

SOFTWARE

DEDICATED

FILAMENTS

TECHNICAL

SUPPORT

M200 PRINTER ENVIRONMENT

Preparing the Model

Work with the model can

be initiated in any 3D

program of choice which

creates 3D graphics and

supports .stl ﬁle format.

The next step is to export

the created CAD ﬁle to

this format.

Z-Suite Software

Z-Suite is an appliction which

prepares 3D models for

printing. It allows the actual

parameters of the model to

be adjusted, such as: size,

layer thickness or generating

reinforcement material

(support).

Z-Suite prepares the model

by generating a project and

saving it in z-code format,

which is then ready to be

printed using the M200

printer.

Transferring the Model

In order to export the

model to the printer, it is

suﬃcient enough to save

the z-code ﬁle generated

in Z-Suite onto an SD

card and insert it into the

reader on the printer.

Uploading the Filament

The following step is to

upload the ﬁlament

Dedicated Z-Filaments,

such as Z-ABS and

Z-ULTRAT, are available

in several color options.

New types of ﬁlaments

with diﬀerent physical

qualities are coming

soon.

Initiating the Printing

Process

Printing is initiated after

selecting a model from

the SD card inserted into

the reader. The printer

menu and ﬁle catalog are

brought up on the display

which is operated by the

control knob.

After choosing a ﬁle and

pushing the control knob

in, the printing process

begins.

HOW DOES ZORTRAX M200 WORK

Zortrax Filaments were created to ensure the

highest quality of prints in the Zortrax M200

environment.

The Z-ABS line of ﬁlaments is the eﬀect of work

with a material which would allow the full potential

of the M200 printer to be released. An ideal

proportion of polycarbonate and ABS material

combines the best qualities of each material.

Z-ABS is an elastic and durable material alike,

suitable for mechanical treatment. It is therefore

optimal for creating objects of everyday use,

architectural models, mechanical parts or

prototypes of home appliances or electronics.

Models printed using Z-ABS can be used as

prototypes of objects created further on using the

technology of injection molds.

Z-ULTRAT is a premium plastic ﬁlament for 3D

printing with Zortrax M200. Material with high

hardness level, high durability and low level of

deformation. Excellent for printing architectural

models, utility models and working parts in machine

prototypes.

Perfectly imitates the properties of materials used

in mass production. Available in ivory color.

Z-PCABS

resistant to high

temperatures

Z-NYLON

durable, elastic,

prone to staining

Z-FLEX

highly elastic,

shape memory

properties

Z-GLASS

transparent, high

level of hardness

Z-ALU

hard, addition

of aluminum alloy

Coming soon:

FILAMENTS

Extruder Extruder Cable

Filament

Guide

Power Connector

and Switch

Build Platform Display

Z Axis Screw Control

Knob

Filament Mount

HotendFilament

OVERVIEW

Zortrax M200

3D Printer

Filament Spool

Holder Filament Guide Filament Spool Build

Platform Power Cable

SD Card

SD Card Reader

Z-Suite*

Quick Start Guide

Safety

Gloves

Cutting Knife

Scalpel

Allen Keys

Nozzle Key

Nozzle Needle

Pliers

Spatula

Tweezers

Service Grease Safety Glasses

* online

IN THE BOX

Z- SUITE SOFTWARE INSTALLATION

You need a model in .stl ﬁle format to print it on Zortrax

M200 3D printer. Most CAD and 3D modeling software

allows you to convert 3D ﬁles to this format. To prepare

a ﬁle for 3D printing (in the z-code format) install the

Z- Suite Software on your computer. The latest version is

available to download from www.zortrax.com. To install

Z-Suite Software, you need a serial number, which you will

get with the printer.

Z- FIRMWARE UPDATE

To enjoy the highest print quality it is important to have

the latest version of ﬁrmware. Always update the printer’s

ﬁrmware when a new version is available. News about

Z-Suite changelogs can be found on www.zortrax.com

and you can also subscribe to Z-Newsletter – to be up-to-

date with all updates. The latest version of Z-Firmware

is available to download from www.zortrax.com/down-

loads. To update the ﬁrmware save its latest version onto

the SD Card (Update.bin ﬁle), insert the SD Card into

the printer and run the device. Z-Firmware will update

automatically.

M200 PRINTER ENVIRONMENT

1. Open the box, pull out the cushioning.

2. Cushioning from the front should be removed as the last one.

Now Zortrax M200 is ready to be taken out of the box.

3. Unbox Zortrax M200. Please use gloves.

4. Your Zortrax M200 is now unpacked. While lifting or moving

5. Zortrax M200 do not grab:

A. belts,

B. smooth rods,

C. extruder. Please use gloves.

UNPACKING
