ZTE MF112

USB Modem

User Manual

No part of this publication may be excerpted,

reproduced, translated or utilized in any form or by

any means, electronic or mechanical, including

photocopying and microfilm, without the prior written

permission of ZTE Corporation.

The manual is published by ZTE Corporation. We

reserve the right to make modifications on print errors

or update specifications without prior notice.

Edition 1st edition, Dec 2008

Contents

1 Modem Introduction....................................................5

1.1 Introduction.......................................................5

1.2 Warning and Notice ........................................5

1.3 Applicability Scope.........................................8

1.4 System requirements.....................................8

1.5 Functions ...........................................................8

2 Installation...................................................................11

2.1 Software Installation....................................11

2.2 Run the Application Software ...................13

2.3 Software Uninstall ........................................17

3 Functions & Operation.............................................18

3.1 Interface introduction..................................18

3.1.1 Main Interface.......................................................18

3.1.2 Description of Mini Icons .....................................19

3.2 Connecting Internet......................................20

3.3 SMS....................................................................20

3.3.1 Read SMS .............................................................21

3.3.2 Create new message..............................................21

3.3.3 The SMS box Operating Guide.............................22

3.4 Phonebook.......................................................22

3.4.1 Creating a new contact..........................................22

3.4.2 Modifying contacts................................................23

3.4.3 Deleting contacts...................................................23

3.4.4 Sending SMS to a contact.....................................23

3.4.5 Searching for a contact..........................................23

3.5 Settings ............................................................23

3.5.1 Connect Settings....................................................24

3.5.2 Network Selection.................................................24

3.5.3 Preference Network...............................................25

3.5.4 SMS Settings.........................................................25

3.5.5 Alert settings .........................................................26

3.5.6 Security Settings....................................................26

3.5.7 System Settings

.....................错误！未定义书签。

3.5.8 Speed Manager......................错误！未定义书签。

3.5.9 Upgrade Settings...................错误！未定义书签。

3.6 Data Record ....................................................26

3.8 MicroSD card ..................................................26

3.9 Help....................................................................26

4 FAQ & Answers...........................................................28

1 Modem Introduction

1.1 Introduction

Thank you for using ZTE USB Modem.

To guarantee the modem always in its best condition, please

read this manual carefully and keep it for further use.

The pictures, symbols and contents in this manual are just for

your reference. They might not be completely identical with your

modem. We operate a policy of continuous development. We

reserve the right to update the technical specifications in this

document at any time without prior notice.

The ZTE USB Modem is a type of multi-mode, 3G modem,

suitable for GSM/GPRS/WCDMA/EDGE/HSDPA network. It

adopts USB interface which provides an easy interface to laptop

and desktop PC. With the GSM/ GPRS/ EDGE/ UMTS/ HSDPA

mobile network, it can help you carry out SMS, data service and

will help you break away from the limit of time and zone, and

realize wireless communication at any moment everywhere.

1.2 Warning and Notice

To the owner

Some electronic devices are susceptible to electromagnetic

interference sent by modem if inadequately shielded, such as

electronic system of vehicles. Please consult the

manufacturer of the device before using the modem if

necessary.

Operating of laptop and desktop PC and modem may

interfere with medical devices like hearing aids and

pacemakers. Please always keep them more than 20

centimeters away from such medical devices when they are

turned on. Turn the modem off if necessary. Consult a

physician or the manufacturer of the medical device before

using the modem.

Be aware of the usage limitation when using a modem at

places such as oil warehouses or chemical factories, where

there are explosive gases or explosive products being

processed. Therefore, turn off your modem if required.

Don’t touch the inner antenna area if not necessary.

Otherwise it will affect your modem’s performance.

Store the modem out of the reach of little children. The

modem may cause injury if used as a toy.

Modem

Please use original accessories or accessories that are

authorized. Using any unauthorized accessories may affect

your modem’s performance, and violate related national

regulations about telecom terminals.

Avoid using the modem near metallic structure device or

establishment that can emit electromagnet wave. Otherwise it

may influence receiving signals.

The modem is non-waterproof type, please keep it dry and

store in shady and cool place.

Don’t use the modem immediately after a sudden

temperature change. In such case, it will produce dew inside

and outside the modem, so don’t use it until it becomes dry.

Take the modem carefully. Don’t lose, bend or cause it struck.

Otherwise it will lead to destruct damage.

No dismantling by non-professional and only qualified

maintainer can undertake repair work.

FCC Health and safety information

Radio Frequency (RF) Energy

This model USB Modem meets the government’s requirements for exposure

to radio waves.

This USB Modem is designed and manufactured not to exceed the emission

limits for exposure to radio frequency (RF) energy set by the Federal

Communications Commission of the U.S. Government:

The exposure standard for USB Modem employs a unit of measurement

known as the Specific Absorption Rate, or SAR. The SAR limit set by the

FCC is 1.6W/kg. *Tests for SAR are conducted using standard operating

positions accepted by the FCC with the USB Modem transmitting at its

highest certified power level in all tested frequency bands. Although the

SAR is determined at the highest certified power level, the actual SAR level

of the USB modem while operating can be well below the maximum value.

This is because the USB modem is designed to operate at multiple power

levels so as to use only the poser required to reach the network. In general,

the closer you are to a wireless base station antenna, the lower the power

output.

The highest SAR value for the model USB Modem as reported to the FCC is

1.14 W/kg on the body with 5mm separation between USB modem to SAR

phantom.

While there may be differences between the SAR levels of various USB

Modem and at various positions, they all meet the government requirement.

The FCC has granted an Equipment Authorization for this model phone with

all reported SAR levels evaluated as in compliance with the FCC RF exposure

guidelines. SAR information on this model phone is on file with the FCC and

can be found under the Display Grant section of

http://www.fcc.gov/oet/fccid after searching on

FCC ID: Q78-MF112.

FCC Compliance

This device complies with part 15 of the FCC Rules. Operation is subject to

the following two conditions: (1) This device may not cause harmful

interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

Caution: Changes or modifications not expressly approved by the

manufacturer could void the user’s authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interference

in a residential installation. This equipment generates, uses and can radiate

radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

—Reorient or relocate the receiving antenna.

—Increase the separation between the equipment and receiver.

—Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

—Consult the dealer or an experienced radio/ TV technician for help.

1.3 Applicability Scope

ZTE USB Modem supports the present mainstream types of

laptops and desktop PCs, such as HP, IBM, Toshiba, Lenovo,

Dell, Founder, etc.

1.4 System requirements

Operating System：

Windows 2000(SP4) / XP(SP2/3) / Vista SP1

Configuration (Recommended):

CPU 500MHz Pentium or above

Hard Disk 30M or above

RAM 128M or above

The performance of the modem may be influenced if

configuration is under the recommended requirement.

1.5 Functions

Functions: SMS service, data service, applied management,

data concurrence, support MicroSD card, etc.

1.6 Notification of private information

Security features protect you from illegal use of your Modem

and SIM card.

SIM password: The SIM password (PIN 1 code) can prevent

your SIM card from illegal use. Select ON/OFF to enable or

disable the SIM password protection; select Change PIN 1 to set

a new PIN 1 code.

Note:Three consecutive incorrect PIN 1 code entries will lock

the SIM card. Then, the PUK code is needed to unlock the SIM

card. The PIN 1 code and the PUK code may be provided to you

together with the SIM card. If not, please contact with your

network service provider. Please change it with your own private

password as soon as possible.

Network call bar: You can set any combination of the

following call restriction options to improve security level.

Please contact with the network service provider for detailed use.

The network service provider provides a 4-digit network

password to enable your call restrictions.

International calls: Bar all international calls.

All except home: Bar international calls except local call.

Incoming calls: Bar all incoming calls.

Incoming if abroad:Bar all incoming calls when roaming abroad.

Outgoing calls:Bar all outgoing calls.

After choosing one of the above options, choose

Select to restrict any of the following services:

All services:Restrictincoming calls, voice calls and short messages.

Voice calls: Restrict voice calls only.

Data: Restrict data only.

Fax:Restrict faxes only.

Messages: Restrict short messages only.

All except messages:Restrict all services except short messages.

After select one type of restriction services, the

following can be chosen:

Activate:The restriction is functional.

Deactivate: Delete the restriction.

Checking availability: Check the current status of the restriction

service.

Cancel all:Select Cancel all to cancel all call restrictions setting.

Note: You need to input the network password to set

or cancel network restrictions. Three consecutive incorrect

password entries will lock the call restrictions service.

Please contact network service provider to unlock it.

1.6Specification

Interface Type USB 2.0 high speed

Systems supported Supports most types of laptop and desktop PC.

Operating systems

supported Windows 2000, XP SP2, Vista

Apple MAC OS X 10.3, 10.4, 10.5

Functions SMS service, Data service, Applications

management, Data concurrent, support

MicroSD card, etc.

Network Standards HSDPA/UMTS/EDGE/GPRS/GSM

Transmission UMTS: 384Kbps UL

HSDPA: 3.6Mbps DL

Temperature

Storage: -20°C ~ +65°C

Operation: -10°C ~ +55°C

Dimension

84.8

25.0

10.9mm

Weight About 21.5g

T-Flash Capability

Support up to 4G microSD

Inhaltsverzeichnis

Andere Zte Modem Handbücher

Beliebte Modem Handbücher anderer Marken

Davicom

Davicom DM562AP Bedienungsanleitung

EpiValley

EpiValley TATA indicom SXC-1080 Bedienungsanleitung

Intelimax

Intelimax MA-2060 Bedienungsanleitung

SMC Networks

SMC Networks D3CM1604V Gebrauchs- und Pflegehandbuch

Telstra

Telstra Wi-Fi 4G Advanced Pro X Bedienungsanleitung

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Bedienungsanleitung

Samsung

Samsung AceLink SAM-335A Bedienungsanleitung

Enfora

Enfora Enabler-G Kurzanleitung zur Einrichtung

iRZ

iRZ ATM2-232 Bedienungsanleitung

Zhone

Zhone 6310 Bedienungsanleitung

Paradyne

Paradyne Hotwire 7976 Bedienungsanleitung

US Robotics

US Robotics 3453C Bedienungsanleitung

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Bedienungsanleitung

Four-Faith

Four-Faith F1403 Bedienungsanleitung

Sierra Wireless

Sierra Wireless AIRLINK MP595W Bedienungsanleitung

Gemtek

Gemtek WiMAX WIXFBR-103 Bedienungsanleitung

Zoom

Zoom 1070 Series Bedienungsanleitung

Aztech

Aztech HW831 Bedienungsanleitung
