Zte OPTUS MF920V Bedienungsanleitung
1
MF920V
Quick Start Guide
2
Getting to Know Your Device
Appearance
The following gure is for your reference only.
1. *External antenna connectors (not all the devices
support)
2. Charging/micro-USB jack
3. Indicator light
4. Power key
• Press and hold for about 3 seconds to power on/off
your device.
• Press and hold for about 10 seconds to restart your
device.
5. WPS key
Press and hold for 3 seconds to activate the WPS
function.
6. micro-SIM card slot and reset hole
3
Getting to Know Your Device
Indicator lights
Indicator Status Description
Battery
Red solid /
blinking
The battery is low. Please
charge the battery.
Green
blinking
The battery is being
charged.
Green solid The battery level is middle
or high.
Light off Your device is not being
charged.
Wi-Fi
Blue solid Wi-Fi is active.
Blue
blinking WPS is active.
Light off Wi-Fi is off.
SMS
Blue solid You have unread mes-
sages.
Blue
blinking You have new messages.
Light off There is no unread mes-
sage or new message.
4
Indicator Status Description
Network
Red
Error status. Not registered
to the mobile network, no
micro-SIM card inserted or
no network service avail-
able.
Green solid Registered to the 2G/3G
mobile network.
Green
blinking
Connected to the 2G/3G
mobile network and data is
being transferred.
Blue solid Registered to the 4G LTE
network.
Blue
blinking
Connected to the 4G LTE
network and data is being
transferred.
Getting to Know Your Device
5
Getting to Know Your Device
Connection Scenarios
The device allows multiple clients to surf on the Inter-
net at the same time. The following gure is for your
reference only.
4G Mode: A micro-SIM card can be used to access the
Internet.
6
Installing Your Device
1. Open the micro-SIM card cover.
NOTE:
Do not remove the cover roughly, because it is con-
nected with the device.
2. Install a micro-SIM card to the micro-SIM card slot.
WARNING!
Your device does not support SIM cards, nano-SIM
cards or any other non-standard micro-SIM cards. To
avoid damage to the device, do not use those cards or
any card holders.
3. Close the micro-SIM card cover.
7
Connecting to Your Device
Using Wi-Fi
1. Power on your device.
2. Ensure that your computer or other client devices
have enabled Wi-Fi, and search for available
wireless networks.
NOTE:
Refer to your Wi-Fi-enabled client device manual for
further details on how to search for wireless networks.
If you use a computer, you need to set your computer
to obtain an IP address automatically.
3. Select the Wi-Fi name (SSID) of your device, and
click Connect.
4. Enter the Wi-Fi password if necessary, and click
OK.
NOTE:
Refer to the chapter Getting to Know the Wi-Fi SSID
and Password to get the default Wi-Fi SSID and pass-
word.
5. Wait until the client device is connected to your
device successfully.
8
Connecting to Your Device
Using a USB Cable
1. Connect a computer to your device with a USB
cable.
2. Power on your device. The operating system
detects and identies new hardware, and
automatically installs the software.
NOTE:
If the system does not automatically launch installation,
you can double-click the device installation icon in My
Computer to install the software.
3. Wait until the computer is connected to your device
successfully.
Getting to Know the Wi-Fi SSID and
Password
You can view the label on the device to get the default
Wi-Fi SSID and password.
9
Logging in to the 4G Mobile Hotspot
Conguration Page
1. Ensure that the connection between your device
and the client device is correct.
2. Launch the Internet browser and enter
http://192.168.0.1 in the address bar.
3. Enter the password to log in to the 4G Mobile
Hotspot conguration page.
NOTE:
The default password is admin.
Changing the Wi-Fi SSID or Password
1. Log in to the 4G Mobile Hotspot conguration
page.
2. Select Wi-Fi Settings.
3. Change the Network Name (SSID) or the
Password in the Main SSID area.
4. Click Apply.
10
Accessing the Internet
After a client device is successfully connected to your
device, you can access the Internet in Automatic or
Manual mode. The default mode is Automatic.
Mode Operation
Automatic
Your device is automatically connected
to the Internet, and you can surf on the
Internet through the client.
Manual
1. Log in to the 4G Mobile Hotspot
conguration page.
2. In My router section, select LTE
(or other network type) Settings >
Connection Mode > Manual, and
then click Apply.
3. Click to return to the home page,
and then click or .
NOTE:
• To change current connection setting, please
disconnect from network.
• To modify the parameters of your device, log in to
the 4G Mobile Hotspot conguration page.
